Howdy folks. I have a quick question about the routing path for the passenger door speaker wire. Does it run behind the dash and connect into the same harness that has the driver side door speaker connected to it? I've run new wires for my driver side door and needs to do the same for my passenger door.

Bonus points for anyone that knows the color of the wires too.



Its a 99. Anyone have a schematic for where it mounts at/comes apart? I've only had the bezel off to put in a radio so far.

It sounds like a project that might have to wait until its warmer out. I got too much to do already lol.



Going to need to know the year of your XJ for that man... lol



I had Dash Rattle. A week later it the entire lower dash (Pre97) split in half.

My face when it happened.


Soz for slight offtopicness.



Sorry. I have a 2001 XJ Limited, no infinity system.



Crap. Hope that doesn't happen. I'll look more like this...



In my '01, none of my wiring colors matched up to what people told me. Just a heads up, I'd suggest verifying everything with a multimeter before cutting.



Here's what I look like seeing those faces



So far, on the driver side, the colors were correct from a video guide of fixing the shot wires. I'll just have to pull the passenger speaker out and see what colors they are, then go from there. I'm more concerned about the path of the wires. I prefer to run wires in their original location so it doesn't look ghetto.



I want to see the dash lol. Never seen a broke dash on an xj



It's in there somewhere





Nooooo



sad burning xj



It was totally my fault though. Didn't drill the hole when i mounted that outlet, so the crack started there. Then the mounts decided they didn't want to stay on one piece anymore.
