cheapest way to bumpstop rear
i have searched and found a lot of mixed answers.
i need a cheep way to bumpstop my rear, i have 4.5inch lift with a d44 rear axle
i need a cheep way to bumpstop my rear, i have 4.5inch lift with a d44 rear axle
#2
Senior Member
Join Date: Oct 2010
Location: Pagosa Springs, Colorado
Posts: 562
Likes: 0
Received 0 Likes
on
0 Posts
Year: 88-ish
Model: Cherokee
Engine: 4.0 I6
1. Are your rear fenders chopped?
2. What size tires/wheel offset are you running?
3. What brand lift is it?
4. Are you still running a stock rear sway bar?
5. How much rubbing are you getting?
Pictures help...
#3
CF Veteran
Join Date: Dec 2010
Location: Finger Lakes Region NY
Posts: 1,234
Likes: 0
Received 1 Like
on
1 Post
Year: 1990
Model: Cherokee
Engine: 4.o
MntsRCool... flex whatever set up you have till you rub. find distance from current bumpstops to 1/4" before rubbing. install spacers. Hockey pucks work great at 1" per puck and $2 a piece, longer blots a must obviously.
Last edited by Agent_Oragnge; 03-28-2013 at 12:18 PM.
#4
Senior Member
Join Date: Oct 2010
Location: Pagosa Springs, Colorado
Posts: 562
Likes: 0
Received 0 Likes
on
0 Posts
Year: 88-ish
Model: Cherokee
Engine: 4.0 I6
great that you memorized the 5 basic questions of almost every thread beginner but in this one instance it doesn't apply.
MntsRCool... flex whatever set up you have till you rub. find distance from current bumpstops to 1/4" before rubbing. install spacers. Hockey pucks work great at 1" per puck and $2 a piece, longer blots a must obviously.
MntsRCool... flex whatever set up you have till you rub. find distance from current bumpstops to 1/4" before rubbing. install spacers. Hockey pucks work great at 1" per puck and $2 a piece, longer blots a must obviously.
#5
Senior Member
Join Date: Feb 2013
Location: Kansas City, MO
Posts: 812
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1996
Model: Cherokee
Engine: 4.0
Done.
#6
CF Veteran
Join Date: Dec 2010
Location: Finger Lakes Region NY
Posts: 1,234
Likes: 0
Received 1 Like
on
1 Post
Year: 1990
Model: Cherokee
Engine: 4.o
he didn't generically ask how to stop the rubbing (in which case i would have asked the same questions you did) , he asked specifically how to stop rubbing using bumpstops, and do it cheaply.
#7
Senior Member
Join Date: Feb 2013
Location: Kansas City, MO
Posts: 812
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1996
Model: Cherokee
Engine: 4.0
great that you memorized the 5 basic questions of almost every thread beginner but in this one instance it doesn't apply.
MntsRCool... flex whatever set up you have till you rub. find distance from current bumpstops to 1/4" before rubbing. install spacers. Hockey pucks work great at 1" per puck and $2 a piece, longer blots a must obviously.
MntsRCool... flex whatever set up you have till you rub. find distance from current bumpstops to 1/4" before rubbing. install spacers. Hockey pucks work great at 1" per puck and $2 a piece, longer blots a must obviously.
Trending Topics
#8
CF Veteran
Join Date: Dec 2011
Location: PA KOTUFU!
Posts: 1,777
Likes: 0
Received 16 Likes
on
15 Posts
Year: 1998
Engine: 4.0L 162,000
With 4.5" lift, I tried the 2" spacer for the rear bump stop and was still short about 1.5". Will add these http://www.dirtboundoffroad.com/susp...p-cherokee-xj/
#9
Senior Member
Join Date: Oct 2010
Location: Pagosa Springs, Colorado
Posts: 562
Likes: 0
Received 0 Likes
on
0 Posts
Year: 88-ish
Model: Cherokee
Engine: 4.0 I6
This is the cheapest way I know of for a DIY longer bumpstop in the rear.
#11
Member
Thread Starter
Join Date: Nov 2012
Location: SL,UT
Posts: 227
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1996
Model: Cherokee
Engine: 4.0l
all i needed 2 know was cheap way to bumpstop because with 33s at 4.5inches of lift and trimmed fenders i still rub in the rear pretty badly i think its because of my ad a leaf, leaf pack is super duper flexy and the pack is flat
and FYI
4.5inch lift
33x12.50 tires
15x10 idk back spacing but they stick out ALOt!!
fenders are cut and folded
#12
CF Veteran
I run 33's on 10 in wide wheels,3 in. lift,cut fenders & mine is just about right with the spacer in there.
Last edited by Big David; 03-28-2013 at 07:41 PM.
#13
::Regional Moderator::
Join Date: Jul 2011
Location: Over here...
Posts: 2,912
Likes: 0
Received 6 Likes
on
6 Posts
Year: 1986
Model: Cherokee
Engine: 2.8
This is what I used at 3" with 33's. Scrap 1/4" plate and bump stops off a Chevy D44. If I had to do it again, I would of welded a stanchion on them. Ah well, they still work.
#15
Member
Join Date: Mar 2013
Location: Georgetown, KY
Posts: 123
Likes: 0
Received 1 Like
on
1 Post
Year: 1999
Model: Cherokee
Engine: 4.0L
....
