Aussie locker
#1
Banned
Thread Starter
Aussie locker
Looking to instal a locker in my 8.25 with 4.10 gears... Question is what will I all need and what spline?? Give me all the info you've got! And I am doing an aussie locker cause I don't have a whole lot of money and am only going to put that locker in so that's out of the picture!
#2
Beach Bum
An Aussie will cost you $300, their USA company LOKKA sells them for around $200.
What year is your jeep? the spline count changed in 96 for the 8.25.
All you will need is a specific set of feeler gauges to install the locker. And read the confusing directions three times before starting. Once you figure out how, they are easy.
What year is your jeep? the spline count changed in 96 for the 8.25.
All you will need is a specific set of feeler gauges to install the locker. And read the confusing directions three times before starting. Once you figure out how, they are easy.
#3
CF Veteran
Join Date: Jul 2013
Location: Monett, MO.
Posts: 7,554
Likes: 0
Received 14 Likes
on
14 Posts
Year: 1999
Model: Cherokee
Engine: 4.0
I do believe you will need a "Master Install Kit" for your 8.25 for the install. If so you need the kit you can get them for around $100 or so mine were that price when I re-geared and installed lockers those were for a D30/Chy 8.25. They came from Rustys Off Road and the installer did tell me it was a good kit for the price.
#6
Senior Member
Join Date: Mar 2011
Location: VA
Posts: 770
Likes: 0
Received 1 Like
on
1 Post
Year: 2000
Model: Cherokee (XJ)
Engine: 4L, 6 cylinder, 190 hp, 225 ft lp torque
Hey OneWheelWonder. The way your first sentence is written I will assume you have a Chrysler 8.25 rear axle with 4.10 gearing already installed. You will need this Aussie locker, http://www.aussielocker.com/index.ph...-xd-58229.html,
which is for a 97+ Chrysler 8.25 with 29 spline count.
If you have an older 8.25 with 27 spline count you won't be using an Aussie, they don't make one for that application. You could look at this locker, http://eastcoastgearsupply.com/i-879...ker-27spl.html, I have this locker in my 8.25 and have had no issues.
For a lunch box locker install only, you will need just basic tools. Good luck and have fun.
which is for a 97+ Chrysler 8.25 with 29 spline count.
If you have an older 8.25 with 27 spline count you won't be using an Aussie, they don't make one for that application. You could look at this locker, http://eastcoastgearsupply.com/i-879...ker-27spl.html, I have this locker in my 8.25 and have had no issues.
For a lunch box locker install only, you will need just basic tools. Good luck and have fun.
#7
CF Veteran
Join Date: Jul 2013
Location: Monett, MO.
Posts: 7,554
Likes: 0
Received 14 Likes
on
14 Posts
Year: 1999
Model: Cherokee
Engine: 4.0
Hey OneWheelWonder. The way your first sentence is written I will assume you have a Chrysler 8.25 rear axle with 4.10 gearing already installed. You will need this Aussie locker, http://www.aussielocker.com/index.ph...-xd-58229.html,
which is for a 97+ Chrysler 8.25 with 29 spline count.
If you have an older 8.25 with 27 spline count you won't be using an Aussie, they don't make one for that application. You could look at this locker, http://eastcoastgearsupply.com/i-879...ker-27spl.html, I have this locker in my 8.25 and have had no issues.
For a lunch box locker install only, you will need just basic tools. Good luck and have fun.
which is for a 97+ Chrysler 8.25 with 29 spline count.
If you have an older 8.25 with 27 spline count you won't be using an Aussie, they don't make one for that application. You could look at this locker, http://eastcoastgearsupply.com/i-879...ker-27spl.html, I have this locker in my 8.25 and have had no issues.
For a lunch box locker install only, you will need just basic tools. Good luck and have fun.
Trending Topics
#11
Banned
Thread Starter
#12
Senior Member
Join Date: Jul 2014
Location: St. Louis
Posts: 793
Likes: 0
Received 2 Likes
on
2 Posts
Year: 1998
Model: Cherokee
Engine: 4.0 Liter I6 PowerTech
Hey OneWheelWonder. The way your first sentence is written I will assume you have a Chrysler 8.25 rear axle with 4.10 gearing already installed. You will need this Aussie locker, http://www.aussielocker.com/index.ph...-xd-58229.html,
which is for a 97+ Chrysler 8.25 with 29 spline count.
If you have an older 8.25 with 27 spline count you won't be using an Aussie, they don't make one for that application. You could look at this locker, http://eastcoastgearsupply.com/i-879...ker-27spl.html, I have this locker in my 8.25 and have had no issues.
For a lunch box locker install only, you will need just basic tools. Good luck and have fun.
which is for a 97+ Chrysler 8.25 with 29 spline count.
If you have an older 8.25 with 27 spline count you won't be using an Aussie, they don't make one for that application. You could look at this locker, http://eastcoastgearsupply.com/i-879...ker-27spl.html, I have this locker in my 8.25 and have had no issues.
For a lunch box locker install only, you will need just basic tools. Good luck and have fun.
#13
Senior Member
Join Date: Mar 2011
Location: VA
Posts: 770
Likes: 0
Received 1 Like
on
1 Post
Year: 2000
Model: Cherokee (XJ)
Engine: 4L, 6 cylinder, 190 hp, 225 ft lp torque
Here you go, read through this catalog. http://www.powertrax.com/pdf/PowertraxCatalog.pdf
Now you have a few to choose from. I didn't catch where you are from but if you are in an area that gets ice and snow you should think twice before putting an auto locker in the rear. The only way I can get moving in slippery conditions is in 4wd. A limited slip works great on the ice and snow.
Good luck and have fun with the project.
Now you have a few to choose from. I didn't catch where you are from but if you are in an area that gets ice and snow you should think twice before putting an auto locker in the rear. The only way I can get moving in slippery conditions is in 4wd. A limited slip works great on the ice and snow.
Good luck and have fun with the project.
Last edited by Rockhead; 11-24-2014 at 12:20 AM.
