Oil pressure
02-06-2012, 01:13 PM
#2
CF Veteran
Join Date: May 2009
Location: Glen Burnie, MD
Posts: 1,844
Likes: 0
Received 3 Likes
on
3 Posts
Year: 1994
Model: Cherokee
Engine: 4.0 H.O. K&N, Borla headers, custom down pipe, magnaflow hi-flo cat, flowmaster to turn down tip
jeep states that anything above 13psi at idle is good, but really between 20-40 is good. on the street my jeep sits at 35-40 when i beat the **** out of it offroad, then it reads between 20-30
02-06-2012, 02:55 PM
#6
::CF Moderator::
Join Date: Aug 2011
Location: Prescott, Az
Posts: 43,875
Received 1,526 Likes
on
1,238 Posts
Year: 1990
Model: Cherokee (XJ)
Engine: 4.0
If you're worried, check the oil pressure with a manual test gauge from a parts store. Could be as simple as a faulty sending unit. Here's an interesting read:
http://www.jeepforum.com/forum/f19/4...fixed-1304679/
http://www.jeepforum.com/forum/f19/4...fixed-1304679/
02-06-2012, 06:35 PM
#7
CF Veteran
Join Date: Nov 2010
Location: In the middle of Minnesota!
Posts: 5,805
Received 99 Likes
on
88 Posts
Year: 1999
Model: Cherokee
Engine: 4.0
Oil pressure spec for the 4.0 is as follows:
*Not less than 13 psi at HOT idle
*Between 37-75 psi OVER 1600 rpms
If you are in this range, you are fine.
*Not less than 13 psi at HOT idle
*Between 37-75 psi OVER 1600 rpms
If you are in this range, you are fine.
Trending Topics
02-06-2012, 07:43 PM
#8
Senior Member
Join Date: Aug 2011
Location: OKC
Posts: 738
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1998
Model: Cherokee
Engine: Straight 6
Originally Posted by tjwalker
Oil pressure spec for the 4.0 is as follows:
*Not less than 13 psi at HOT idle
*Between 37-75 psi OVER 1600 rpms
If you are in this range, you are fine.
*Not less than 13 psi at HOT idle
*Between 37-75 psi OVER 1600 rpms
If you are in this range, you are fine.
02-06-2012, 10:28 PM
#11
Newbie
Join Date: Feb 2012
Posts: 5
Likes: 0
Received 0 Likes
on
0 Posts
Year: 2001
Model: Cherokee
Engine: 4.0 I6
not trying to jack this or anything like that but does anyone have an issue with there oil pressure dropping everytime they hit the brakes mine does it all the time now and when it drops it hits zero then the check guages light comes on. but as soon as i hit the gas it shoots back up and the guage light goes out.
02-06-2012, 11:35 PM
#12
Newbie
Join Date: Jan 2012
Posts: 9
Likes: 0
Received 0 Likes
on
0 Posts
Model: Cherokee
This oil thing is still weird for me 'cuz back in 98 my dad bought a brand new jeep grand cherokee in Brazil and I remember the oil pressure on his was 40 all the time.
I just got here in Canada my first grand cherokee it's 2000 and when I turn the car ON the pressure goes to 50 after awhile drops to 40 (right in the middle) however when I'm driving goes up to 50-60.
But as tjwalker said I guess I'm in the safe zone eh?
Is it better to be high or low?
I just got here in Canada my first grand cherokee it's 2000 and when I turn the car ON the pressure goes to 50 after awhile drops to 40 (right in the middle) however when I'm driving goes up to 50-60.
But as tjwalker said I guess I'm in the safe zone eh?
Is it better to be high or low?
02-06-2012, 11:43 PM
#13
Seasoned Member
Join Date: Dec 2011
Location: High Desert, CA
Posts: 319
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1987
Model: Cherokee
Engine: I6
Is it better to be high or low?
02-07-2012, 05:20 AM
#14
::CF Moderator::
Join Date: Aug 2011
Location: Prescott, Az
Posts: 43,875
Received 1,526 Likes
on
1,238 Posts
Year: 1990
Model: Cherokee (XJ)
Engine: 4.0
Only way to know gor sure is to check with a mechanical gauge that you can rent/borrow from the parts store. Oil pressure fluctuates with RPM. 13 psi at idle is okay. It seems that the later Cherokees had a much higher failure rate of sending units than the early ones FWIW.
