Gears... Help please!!!
Alright guys, so I am a total noob when it comes to diff assembly and whatnot... as much as I read, I think I begin to have it, but then I dont.
So instead of buying all new junk and attempting the assembly myself...
I thought about buying a 95 YJ dana 30 with 4.11s from a guy off CL for $300.
The question is... can I just swap guts with my diff and the YJ? Or are there tolerances that need to be taken into account when installing the carrier and whatnot back into the housing?
In a nutshell... Two complete axles, swap guts... anything I am missing?
So instead of buying all new junk and attempting the assembly myself...
I thought about buying a 95 YJ dana 30 with 4.11s from a guy off CL for $300.
The question is... can I just swap guts with my diff and the YJ? Or are there tolerances that need to be taken into account when installing the carrier and whatnot back into the housing?
In a nutshell... Two complete axles, swap guts... anything I am missing?
#5
Member
Thread Starter
Join Date: Dec 2009
Location: Missoula, MT
Posts: 189
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1995
Model: Cherokee
Engine: 4.0L
#6
Member
Join Date: Jan 2011
Location: Illinois
Posts: 230
Likes: 0
Received 0 Likes
on
0 Posts
Year: 98
Model: Cherokee
Engine: 4.0
I looked for a long time.. Was able to score an 8.25 with 4.10s at the yard for 100.. Only used it for the gears. The d30 gears and carrier I got from the E-auction with no reserve.
Most shops in my area wont install used gears.
Most shops in my area wont install used gears.
#7
CF Veteran
Join Date: Jun 2009
Posts: 5,383
Likes: 0
Received 4 Likes
on
1 Post
Year: 1988 limited
Model: Cherokee
Engine: 4.0 litre
The YJ - XJ swap won't work, you need reverse cut gears. Installation is pretty much straight forward, correct clearance adjustment is the most difficult part.
Here is a DANA writeup.
http://www2.dana.com/pdf/5717.pdf
Here is a DANA writeup.
http://www2.dana.com/pdf/5717.pdf
Trending Topics
#9
Member
Thread Starter
Join Date: Dec 2009
Location: Missoula, MT
Posts: 189
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1995
Model: Cherokee
Engine: 4.0L
#11
Member
Thread Starter
Join Date: Dec 2009
Location: Missoula, MT
Posts: 189
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1995
Model: Cherokee
Engine: 4.0L
#12
CF Veteran
Join Date: Feb 2010
Location: Soddy Daisy TN
Posts: 5,420
Likes: 0
Received 0 Likes
on
0 Posts
Year: 97
Model: Cherokee
Engine: 4.0L
The YJ - XJ swap won't work, you need reverse cut gears. Installation is pretty much straight forward, correct clearance adjustment is the most difficult part.
Here is a DANA writeup.
http://www2.dana.com/pdf/5717.pdf
Here is a DANA writeup.
http://www2.dana.com/pdf/5717.pdf
#13
Junior Member
Join Date: Jan 2011
Location: new jeresy
Posts: 38
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1998
Model: Cherokee
Engine: 4.0
for 300 it is not worth it.there is no problem with used gears if they are not to tore up.i would look for a diconect rear because the gears didnt turn so they probly dont have to many miles on them.but to do it right you check the back lash before you pull it apart and set it up to that number
#14
Member
Thread Starter
Join Date: Dec 2009
Location: Missoula, MT
Posts: 189
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1995
Model: Cherokee
Engine: 4.0L
Yeah I thought it was... if you were on a budget would you use used gears or just wait until you had the bread for new gears, carrier etc...?
I was thinking about swapping in the ford 8.8 rear with the 4.10s and then just pulling the front driveline on the D30 until I can afford new gears and maybe an ox.
But at the same token... I don't want the possibility of going through a Montana winter without 4x4.
I was thinking about swapping in the ford 8.8 rear with the 4.10s and then just pulling the front driveline on the D30 until I can afford new gears and maybe an ox.
But at the same token... I don't want the possibility of going through a Montana winter without 4x4.
