Coil pack vs cap and rotor and plug wires
#1
Newbie
Thread Starter
Join Date: Jun 2013
Location: sc
Posts: 27
Likes: 0
Received 0 Likes
on
0 Posts
Year: 2001
Model: Cherokee
Engine: 4.0
Coil pack vs cap and rotor and plug wires
Have an 01 cherokee with the ignition rail/ coil pack/ wastespark setup however you wanna call it it came stock in the 00-01 models. I recently swapped my motor for a rebuilt crate motor from 505 performance and was wondering how hard it would be to switch to a cap and rotor set up. The cylinder head in the new motor does not have the holes for the bolts for the ignition coil pack so rather than trying to weld nuts on there I was thinking about just changing out that whole set up. Anyone of y'all ever done this?
#2
Banned
Join Date: Oct 2009
Location: West Springfield, MA
Posts: 2,231
Likes: 0
Received 1 Like
on
1 Post
Year: 1999
Model: Cherokee
Engine: 4.0
i dont think it could be done or it would be very hard first off instead of a cam pos. sensor on the '00-'01 you would need to make the pick-up coil work and adapt it so the ecm sees it instead of the cam pos. sensor and im sure the signals are different for the one coil with distributor and the coil pack...
why would you want to switch its a good working system
why would you want to switch its a good working system
#6
Senior Member
Join Date: Mar 2012
Location: FL.
Posts: 615
Likes: 0
Received 0 Likes
on
0 Posts
Year: 2000
Model: Cherokee
https://www.cherokeeforum.com/f2/200...n-4-0l-171014/
https://www.cherokeeforum.com/f58/co...ad-swap-98820/
https://www.cherokeeforum.com/f58/co...ad-swap-98820/
Last edited by prcherokee; 01-29-2014 at 08:17 PM.
#7
CF Veteran
Join Date: Jul 2011
Location: Pompano Beach
Posts: 1,386
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1998
Model: Cherokee
Engine: 4.0
Use a Dodge Viper coil instead of the rail coil, they have a tad more output and are less prone to failure. The pigtail should plug in same as the rail coil as well.
edit; I failed to mention that the Viper coil is compatible with the OBD2 ECU used with the rail coil. You will not get a MIL and all P-codes will be correct in terms of system or component malfunction.
edit; I failed to mention that the Viper coil is compatible with the OBD2 ECU used with the rail coil. You will not get a MIL and all P-codes will be correct in terms of system or component malfunction.
Last edited by offroadordnance; 01-31-2014 at 07:04 AM.
Trending Topics
#8
CF Veteran
Join Date: Feb 2011
Location: Long Beach, Ca
Posts: 3,500
Likes: 0
Received 0 Likes
on
0 Posts
Year: 2000
Model: Cherokee
Engine: 4.0 I6
#10
CF Veteran
Join Date: Jan 2013
Location: columbia, pa
Posts: 1,053
Likes: 0
Received 2 Likes
on
2 Posts
Year: 2000
Model: Cherokee
Engine: 4.0
Use a Dodge Viper coil instead of the rail coil, they have a tad more output and are less prone to failure. The pigtail should plug in same as the rail coil as well.
edit; I failed to mention that the Viper coil is compatible with the OBD2 ECU used with the rail coil. You will not get a MIL and all P-codes will be correct in terms of system or component malfunction.
edit; I failed to mention that the Viper coil is compatible with the OBD2 ECU used with the rail coil. You will not get a MIL and all P-codes will be correct in terms of system or component malfunction.
#11
Senior Member
Join Date: Mar 2012
Location: FL.
Posts: 615
Likes: 0
Received 0 Likes
on
0 Posts
Year: 2000
Model: Cherokee
http://naxja.org/forum/showthread.php?t=1066869
http://www.rockauto.com/catalog/moreinfo.php?pk=940061
it's also use on the dodge Ram.
http://www.rockauto.com/catalog/moreinfo.php?pk=940061
it's also use on the dodge Ram.
#12
Newbie
Thread Starter
Join Date: Jun 2013
Location: sc
Posts: 27
Likes: 0
Received 0 Likes
on
0 Posts
Year: 2001
Model: Cherokee
Engine: 4.0
Is there a specific year viper I am going to order one now and install in in a few months lol I am deploying so it will be something to look forward to
#13
Senior Member
Join Date: Mar 2012
Location: FL.
Posts: 615
Likes: 0
Received 0 Likes
on
0 Posts
Year: 2000
Model: Cherokee
2004-06 Dodge Ram 1500 Truck 4 Terminal Connection 6 Lead Ignition Coil Pack for V10 8.3L
1997-03 Dodge Ram 2500 Truck 4 Terminal Connection 6 Lead Ignition Coil Pack for V10 8.0L
1997-03 Dodge Ram 3500 Truck 4 Terminal Connection 6 Lead Ignition Coil Pack for V10 8.0L
2003-06 Dodge Viper 6 Lead Ignition Coil Pack V10 8.3L
1997-02 Dodge Viper 6 Lead Ignition Coil Pack for V10 8.0L
Part # 56029098AA
1997-03 Dodge Ram 2500 Truck 4 Terminal Connection 6 Lead Ignition Coil Pack for V10 8.0L
1997-03 Dodge Ram 3500 Truck 4 Terminal Connection 6 Lead Ignition Coil Pack for V10 8.0L
2003-06 Dodge Viper 6 Lead Ignition Coil Pack V10 8.3L
1997-02 Dodge Viper 6 Lead Ignition Coil Pack for V10 8.0L
Part # 56029098AA
