Here's r2 of the decal.
I've got all of the contour details. the lettering is as perfect as I can make it without having a high-res scan of the original.
The real beast is going to be the halftone pattern on the second tree. It's not a standard halftone pattern, but "designed" to be that pattern--checkerboard. I'm guessing based off the best version of the decal that it's .015", or 4.5 pixels based on a 300 ppi print.
I think I'm going to have to manually make the pattern...
I've got all of the contour details. the lettering is as perfect as I can make it without having a high-res scan of the original.
The real beast is going to be the halftone pattern on the second tree. It's not a standard halftone pattern, but "designed" to be that pattern--checkerboard. I'm guessing based off the best version of the decal that it's .015", or 4.5 pixels based on a 300 ppi print.
I think I'm going to have to manually make the pattern...
Edit: That crappy screen tint stuff, called ziptone I think, that paste up artists used use on copy boards when ever they wanted a screen tint in something. It was coarse like the tree. Made it quicker to strip and print a job but not as clean looking as using a film screen tint behind the neg that we would shoot from the copy for making the final negs or plating when printing.
