rim offset

Old 11-09-2016, 04:12 PM
  #1
Newbie
Thread Starter

Join Date: Nov 2016
Posts: 2
Model: Cherokee
Default rim offset

i would like to buy a new set of rims for my sons 03 Grand Cherokee, the rims that I found that he likes are a 16 x 8 with 5 x 127mm hole pattern and a -12mm offset, the online rim guy says that the stock rims are 16 x 7, 5 x 127mm and a +50 or 51mm, he said that this would require a lift, I don't think so??it looks as though they will just stick out of the wheel wells a little (2.5" or so).
I plan to use the stock 16 in tires.

Last edited by duger; 11-10-2016 at 06:27 AM. Reason: left out info
duger is offline
Old 11-10-2016, 11:42 AM
  #2
CF Veteran

Fred/N0AZZ's Avatar

Join Date: Jul 2013
Location: Monett, MO.
Posts: 7,554
Year: 1999
Model: Cherokee
Engine: 4.0
Default

My 04 GC Overland came with 235/65R17's on it from the factory but I can't find the wheel info right now as usual . But the exact same body style.
Name:  IMG_0046_zps7bb8f795.jpg
Views: 71
Size:  103.0 KB
Fred/N0AZZ is offline
Old 11-10-2016, 01:43 PM
  #3
Former Sponsor

Join Date: Sep 2016
Posts: 87
Default


Originally Posted by duger View Post
i would like to buy a new set of rims for my sons 03 Grand Cherokee, the rims that I found that he likes are a 16 x 8 with 5 x 127mm hole pattern and a -12mm offset, the online rim guy says that the stock rims are 16 x 7, 5 x 127mm and a +50 or 51mm, he said that this would require a lift, I don't think so??it looks as though they will just stick out of the wheel wells a little (2.5" or so).
I plan to use the stock 16 in tires.
That would be correct, you will want a positive offset wheel for sure. Moving the wheel that far past the fender will cause major rubbing. Even with factory tire sizes. That 4 inches of movement toward and past the fender over stock is the same as putting a very wide tire on the vehicle. I have had several WJ's, my current one is on an 8 inch lift with 35's and I still hit the front rocker a little on the drivers side. Current wheel is a 17x9 with a -12mm offset.
We could try and find a wheel option for you, but if not us I would suggest you stay at least at a +12mm offset.

Last edited by ReadyToMount; 11-10-2016 at 01:58 PM. Reason: Added images
ReadyToMount is offline
Old 11-15-2016, 12:19 PM
  #4
Newbie
Thread Starter

Join Date: Nov 2016
Posts: 2
Model: Cherokee
Default thanks

thanks for the input, I may just put this off until spring, but your help is appreciated.
duger is offline
Old 11-15-2016, 01:31 PM
  #5
Junior Member

daedricjeep's Avatar

Join Date: Jul 2012
Location: indiana
Posts: 75
Year: 1998
Model: Cherokee
Engine: 4.0
Default

i need to widen my stance after lifting and putting 31's on, having the same question. so many choices out there. anyone got a link to a set of rims that will stick out? preferably around the 60$ mark and no higher, if possible. for 15' rims (97 grandcherokee)
daedricjeep is offline
Old 11-15-2016, 04:41 PM
  #6
CF Veteran

dave1123's Avatar

Join Date: Nov 2010
Location: Manlius, east of Syracuse, NY
Posts: 11,245
Year: 2000
Model: Grand Cherokee (WJ)
Engine: 4.0L
Default

Originally Posted by readytomount View Post



That would be correct, you will want a positive offset wheel for sure. Moving the wheel that far past the fender will cause major rubbing. Even with factory tire sizes. That 4 inches of movement toward and past the fender over stock is the same as putting a very wide tire on the vehicle. I have had several WJ's, my current one is on an 8 inch lift with 35's and I still hit the front rocker a little on the drivers side. Current wheel is a 17x9 with a -12mm offset.
We could try and find a wheel option for you, but if not us I would suggest you stay at least at a +12mm offset.
That's one bad*** WJ! Me likes!
dave1123 is online now
Old 11-15-2016, 04:44 PM
  #7
Former Sponsor

Join Date: Sep 2016
Posts: 87
Default

Originally Posted by dave1123 View Post
That's one bad*** WJ! Me likes!
Thank you sir. I has been a dependable daily driver/weekend wheeler/work truck for the past 8 years now. A part of the family almost.
ReadyToMount is offline
Old 11-15-2016, 05:12 PM
  #8
CF Veteran

dave1123's Avatar

Join Date: Nov 2010
Location: Manlius, east of Syracuse, NY
Posts: 11,245
Year: 2000
Model: Grand Cherokee (WJ)
Engine: 4.0L
Default

Yes, mine is just a DD/snow machine/newspaper delivery vehicle. I was going to give it a lift, but then I couldn't reach people's mailboxes! I'd love to have an off-road playtoy but I'm on SS, ya know.
dave1123 is online now
Old 11-15-2016, 11:01 PM
  #9
Member

GUARDIAN's Avatar

Join Date: Aug 2014
Location: LAS VEGAS, NV
Posts: 159
Year: 2004
Model: Grand Cherokee (WJ)
Engine: 4.0 I6
Default

I'm running 265/75/16 on 8 inch american racing wheels with 4 inches backspacing and 0 offset, 2.5 inch lift, 2 inch bump stops. Mostly daily driver, so it rides a bit stiff. haven't wheeled it much lately as i'm getting ready to re-gear and do the rear and front bumpers.


GUARDIAN is offline
