A/C stuck on defrost
#1
Newbie
Thread Starter
Join Date: Apr 2016
Posts: 1
Likes: 0
Received 0 Likes
on
0 Posts
Model: Cherokee
A/C stuck on defrost
Hey guys, so I just bought a 2000 JEEP CHEROKEE and it has an issue with the A/C. It's stuck on defrost and through research I've narrowed it down to the blend door actuator or stuck or broken blend doors. Where is the blend door actuator in my 2000 JEEP CHEROKEE and how do I get to it and where are my blend doors and how do I get to them? Thanks 😊
#2
CF Veteran
First check the vacuum diagram under the hood, trace down the line that goes into the cabin and verify it's not disconnected or broken. After that I can't offer much help, never done the job. I do know on the Liberty's there were huge issues with the defective blend doors and there are aftermarket fixes for them.
#3
Member
Join Date: Dec 2010
Location: East Sussex, UK
Posts: 114
Likes: 0
Received 0 Likes
on
0 Posts
Year: 2000
Model: Grand Cherokee
Engine: 4.0 Petrol
I have replaced the blend doors on my 2000 WJ.
You can get a repair kit - to fit the new parts you cut - very carefully - an access hole in the side of the plastic heater box - there are various youtube clips to show how its done.
I used a fine tipped cordless soldering iron to cut through the plastic, quite a slow process but a lot less messy than using a Dremel or similar type tool.
Edit : Found this clip on YouTube which shows how it's done :
You can get a repair kit - to fit the new parts you cut - very carefully - an access hole in the side of the plastic heater box - there are various youtube clips to show how its done.
I used a fine tipped cordless soldering iron to cut through the plastic, quite a slow process but a lot less messy than using a Dremel or similar type tool.
Edit : Found this clip on YouTube which shows how it's done :
Last edited by Cherokee_Mike; 05-01-2016 at 03:25 AM. Reason: Additional information
#4
CF Veteran
Join Date: Jun 2011
Location: Louisville,KY
Posts: 8,014
Likes: 0
Received 14 Likes
on
14 Posts
Model: Cherokee
Its a monster of a job,You have to remove the whole dash to get to the heater box its a 12 hour job,Doing so you will have to discharge the ac system.While your in there i would replace the heater core and the ac evaporator.
#5
CF Veteran
Join Date: Feb 2010
Location: Oroville, CA
Posts: 12,367
Likes: 0
Received 19 Likes
on
18 Posts
Year: 1995
Model: Grand Cherokee
Engine: 4.0 with all of the noise and clatter
As stated above, make sure the vacuum supply line is hooked up and make sure the vacuum reservoir isn't cracked. Check the simple things first before you start pulling the dash out. A proper diagnosis will save you more than jumping to conclusions.
#6
Old fart with a wrench
First of all, the blend door on the 2000 Grand Cherokee is actuated by an electric stepper motor, not vacuum. The motor is behind the glove box on the outside of the heater box. Take out the screws and check if the plastic shaft is broken. If it is, you can cut a hole in the heater box and install a repair door. This is if it's a single control heater. If it's dual zone control, there are 2 doors and the heater has to come out to work on the rear door actuator. THAT requires the dash be removed.
The blend door only controls temperature of the heat. The mode control sends the heat to various places and that is vacuum controlled. The dual zone heater is a pain to repair because everything is electronically controlled automatically just by setting the temperature.
The best thing you can do is download a Full Service Manual from pacificcoastmanuals.com for $7.99+tax. It's 93mb of pdf files and covers everything on your jeep. These are copies of the Factory Service Manuals used by the dealer service techs. They are year-specific so you don't have to paw thru them to find stuff about your particular jeep. It's the BEST manual I've EVER seen! DO NOT try to print out the whole thing because you'll go thru about a ream of paper and a couple of ink cartridges! Just print out the sections you want and you can throw them away when you're done if you want.
The blend door only controls temperature of the heat. The mode control sends the heat to various places and that is vacuum controlled. The dual zone heater is a pain to repair because everything is electronically controlled automatically just by setting the temperature.
The best thing you can do is download a Full Service Manual from pacificcoastmanuals.com for $7.99+tax. It's 93mb of pdf files and covers everything on your jeep. These are copies of the Factory Service Manuals used by the dealer service techs. They are year-specific so you don't have to paw thru them to find stuff about your particular jeep. It's the BEST manual I've EVER seen! DO NOT try to print out the whole thing because you'll go thru about a ream of paper and a couple of ink cartridges! Just print out the sections you want and you can throw them away when you're done if you want.
Trending Topics
#8
Old fart with a wrench
There I go, jumping to conclusions again! Oh, well, I took a shot at it.
#10
Old fart with a wrench
Well they are, aren't they? HAHAHA! Seriously, it was posted in Grand Cherokee and I just assumed. Silly of me.
#12
Old fart with a wrench
Yeah, and it's not a REAL jeep unless it's a Wrangler!
I saw 2 young girls today POUNDING on a Cherokee Sport zipping in and out of traffic like their tails were on fire! Oh, to be young again!I might have started chasing them!
I saw 2 young girls today POUNDING on a Cherokee Sport zipping in and out of traffic like their tails were on fire! Oh, to be young again!I might have started chasing them!
