Trying to change cps??
help please.. 1994 Cherokee sport,4.0,automatic,4x4..trying to change crank sensor,jacked it up,got the bottom bolt out,top bolt#*#..Looks like if I drop the driveshaft below it,maybe can get the top bolt..It is pouring rain now so Quit for the night..If I take out the 4 little bolts will it slide back & down?? It is on 2 jackstands,+ 12x 12 wood blocks,,safety first.. Thanks for any help..Wayne
09-17-2014, 07:39 PM
#2
CF Veteran
Join Date: Feb 2012
Location: Kansas
Posts: 2,652
Likes: 0
Received 2 Likes
on
2 Posts
Year: 1994
Model: Cherokee
Engine: 190-hp, 4.0-liter I-6
help please.. 1994 Cherokee sport,4.0,automatic,4x4..trying to change crank sensor,jacked it up,got the bottom bolt out,top bolt#*#..Looks like if I drop the driveshaft below it,maybe can get the top bolt..It is pouring rain now so Quit for the night..If I take out the 4 little bolts will it slide back & down?? It is on 2 jackstands,+ 12x 12 wood blocks,,safety first.. Thanks for any help..Wayne
09-17-2014, 08:15 PM
#4
Newbie
Thread Starter
Join Date: Aug 2012
Location: Az,desert
Posts: 28
Received 0 Likes
on
0 Posts
Year: 1994
Model: Cherokee
Engine: 4.0
Yes, I have 9in,12 in,3 4in & many diff wobblies.can get on the top bolt ,,but up against driveshaft and can't move the ratchet handle for driveshaft in the way.. Wayne
09-17-2014, 08:20 PM
#5
THE Admin
Join Date: Sep 2010
Location: Lantana, Fl
Posts: 34,036
Received 231 Likes
on
187 Posts
Year: 1996
Model: Cherokee (XJ)
Engine: 4.Slow
I found 1/4" drive extensions and sockets work the best in that tight area. If you have flex head ratcheting wrenches, you can get it from the top.
09-17-2014, 08:22 PM
#6
Senior Member
Easiest way is with a whole lot of extensions and a u-joint so that you can turn the ratchet underneath the car but the socket is on the bolt.
There's a few videos on youtube that show it.
There's a few videos on youtube that show it.
09-17-2014, 08:36 PM
#7
No need to drop the tranny. That's just extra work. Add to your tool collection with some extensions and you'll be in business. Disconnecting the front drive shaft does help. It's a PITA but easily done in the driveway.
Trending Topics
09-17-2014, 08:47 PM
#8
CF Veteran
Join Date: Feb 2012
Location: Kansas
Posts: 2,652
Likes: 0
Received 2 Likes
on
2 Posts
Year: 1994
Model: Cherokee
Engine: 190-hp, 4.0-liter I-6
It took me all of two minutes to drop my tranny... It would have taken longer to track down the extensions. Haha each there own I guess. Just saying my experience. Took me 30 minutes for whole swap...
09-18-2014, 05:40 PM
#9
Newbie
Thread Starter
Join Date: Aug 2012
Location: Az,desert
Posts: 28
Received 0 Likes
on
0 Posts
Year: 1994
Model: Cherokee
Engine: 4.0
Finally got it installed,started and ran fine..Road test later.I did drop the front driveshaft and that really helped.The little plastic cover fell out and was a real pain to get back in..Thank you all for advice and tips.. Wayne
