Rear shoulder belt mounts
So I picked up some rear 3 point seat belts.
I've seen a few threads and a video on installing. Everything matches up except the hole for the top mount. Is there something I'm missing here.
In the video the upper mount looks like this.
My upper holes look like this and the hole is to big for the bolt.
I've seen a few threads and a video on installing. Everything matches up except the hole for the top mount. Is there something I'm missing here.
In the video the upper mount looks like this.
My upper holes look like this and the hole is to big for the bolt.
#2
CF Veteran
Yes, you are missing the nutsert. What year is your Jeep. The erly ones didn't have the rear shoulder belt
#3
Member
Thread Starter
Sorry I forgot to mention it's an 87. I know they didn't have them factory pre 90, but the video and thread were talking about an 86.
https://www.cherokeeforum.com/f2/rear-seat-belt-video-up-18199/
Can the nut be added? Or any suggestions?
My daughter won't ride in it until I add rear belts.
https://www.cherokeeforum.com/f2/rear-seat-belt-video-up-18199/
Can the nut be added? Or any suggestions?
My daughter won't ride in it until I add rear belts.
Last edited by rapidrabbit; 04-19-2020 at 06:38 PM.
#4
CF Veteran
You could probably put in a nutsert if you can get one to fit that hole. Not that tough to do
The following users liked this post:
rapidrabbit (04-20-2020)
#5
CF Veteran
Join Date: Oct 2018
Location: United Kingdom
Posts: 1,576
Received 278 Likes
on
242 Posts
Year: 1995 RHD
Model: Cherokee (XJ)
Engine: 4.0l
I'd personally use a proper anchoring plate instead of a nut insert. I stripped mine when removing the seatbelt so had to put another in.
These are what I used but this is a UK company, I'm sure you'll find some in the US.
https://www.justkampers.com/6814-sea...ates-pair.html
I welded it in place but 2 rivets would suffice to hold it in place.
These are what I used but this is a UK company, I'm sure you'll find some in the US.
https://www.justkampers.com/6814-sea...ates-pair.html
I welded it in place but 2 rivets would suffice to hold it in place.
The following users liked this post:
rapidrabbit (04-20-2020)
#7
CF Veteran
Join Date: Oct 2018
Location: United Kingdom
Posts: 1,576
Received 278 Likes
on
242 Posts
Year: 1995 RHD
Model: Cherokee (XJ)
Engine: 4.0l
Looks spot on. With all of those pre drilled holes, you may even get 2 to align with the originals. It's only to hold it in place to help get the seatbelt bolt in.
Before you fit the belt, make sure that the spacer collar on the bolt spins freely. Mine had rusted solid and was the reason it ended up stripping the threads trying to remove it.
Before you fit the belt, make sure that the spacer collar on the bolt spins freely. Mine had rusted solid and was the reason it ended up stripping the threads trying to remove it.
Trending Topics
#8
Member
Thread Starter
Looks spot on. With all of those pre drilled holes, you may even get 2 to align with the originals. It's only to hold it in place to help get the seatbelt bolt in.
Before you fit the belt, make sure that the spacer collar on the bolt spins freely. Mine had rusted solid and was the reason it ended up stripping the threads trying to remove it.
Before you fit the belt, make sure that the spacer collar on the bolt spins freely. Mine had rusted solid and was the reason it ended up stripping the threads trying to remove it.
I also found some like this. I may order a couple different styles to see what fits best.
The following users liked this post:
rapidrabbit (04-20-2020)
#10
Member
Thread Starter
#11
CF Veteran
Join Date: Oct 2018
Location: United Kingdom
Posts: 1,576
Received 278 Likes
on
242 Posts
Year: 1995 RHD
Model: Cherokee (XJ)
Engine: 4.0l
I can't see any reason why it wouldn't fit. If I remember correctly, there's a large opening right by the rear hatch that should get it in easily enough. It's just a matter of sliding it to where it needs to go and holding it in place to rivet or however you choose it to the body. Just be sure you place it behind the panel and not on top as in the picture you provided.
The following users liked this post:
rapidrabbit (04-20-2020)
