alignment help? cant turn tie rod
12-01-2010, 08:06 PM
#1
CF Veteran
Thread Starter
Join Date: Aug 2010
Location: Carlisle, PA
Posts: 1,678
Likes: 0
Received 0 Likes
on
0 Posts
Year: 2000
Model: Cherokee
Engine: Inline 6
alignment help? cant turn tie rod
i got my new 32s on i am trying to align the front but i cant get the tie rod to turn. with the left front wheel straight the right one definitely is not straight its pointing out. what can i do to toe it in??
12-01-2010, 08:21 PM
#2
Seasoned Member
Join Date: Nov 2010
Location: NE Ohio
Posts: 479
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1996
Model: Cherokee
Engine: 4.0
im assuming you are loosening the 2 13mm nuts on the tierod bar and trying to turn the bar. a big monkey wrench is the way to go on that bar.
12-01-2010, 08:35 PM
#4
CF Veteran
Join Date: Mar 2010
Location: Broward County Fl.
Posts: 47,923
Likes: 0
Received 22 Likes
on
22 Posts
Year: 1989 xj sport 2dr
Model: Cherokee
Engine: 12 hole bosch Injectors
make the pass tire straight and turn the tie rod to turn the drivers in you still got stock steering right
12-01-2010, 08:39 PM
#6
CF Veteran
Join Date: Mar 2010
Location: Broward County Fl.
Posts: 47,923
Likes: 0
Received 22 Likes
on
22 Posts
Year: 1989 xj sport 2dr
Model: Cherokee
Engine: 12 hole bosch Injectors
is the stering wheel straight do that first then lock the steerring turn the drag link to straighten the pass tire the turn the tie rod to straighten the drivers 1/8 closer in the front then the rear on the toe
Trending Topics
12-01-2010, 08:45 PM
#9
Honorary Moderator
Join Date: Mar 2010
Location: Gilbert AZ/Las Cruces NM
Posts: 8,135
Likes: 0
Received 13 Likes
on
11 Posts
Year: 1996
Model: Cherokee
Engine: 4.0 upgraded
Yeah I took out my TRE's and greased them. no problem since. and my "monkey wrench" is the same as a pipe wrench lol
12-01-2010, 09:10 PM
#12
CF Veteran
Thread Starter
Join Date: Aug 2010
Location: Carlisle, PA
Posts: 1,678
Likes: 0
Received 0 Likes
on
0 Posts
Year: 2000
Model: Cherokee
Engine: Inline 6
yeah i got it to move took alot of pb blaster and an 18inch pipe wrench. going to go take it to a shop and work on it there to make sure alignment it good. didnt have to use heat but i might have to tomorrow cus i turned it as must as i could tonight. thanks for the input guys!
12-01-2010, 09:23 PM
#14
CF Veteran
Thread Starter
Join Date: Aug 2010
Location: Carlisle, PA
Posts: 1,678
Likes: 0
Received 0 Likes
on
0 Posts
Year: 2000
Model: Cherokee
Engine: Inline 6
just did. eventually i wanna get an ironrockoffroad tie rod bar its solid steel lol
