Choosing the right lift?
So I'm in the process of building my jeep but having a hard time figuring out what I really want. My xj will be mainly used for wheeling and the occasional cruise around town. I have 35's ready to go on it from my other jeep and I have the front lifted 4.5". But it's a terrible lift with huge spacers.
So the question which has been asked a thousand times on here... Short arm or long arm it?
I'm kinda tight on money right now but I really need to get this thing put back together and out of my shop.
I've been looking at just buying a complete new 4.5" lift then going with the long arm upgrade later.
Again I said I had the front already lifted but I still need to replace the coils, rear leafs, shocks, brake lines etc so it seems that it's easier and cheaper to go ahead and buy a new compete lift. Am I right?
So the question which has been asked a thousand times on here... Short arm or long arm it?
I'm kinda tight on money right now but I really need to get this thing put back together and out of my shop.
I've been looking at just buying a complete new 4.5" lift then going with the long arm upgrade later.
Again I said I had the front already lifted but I still need to replace the coils, rear leafs, shocks, brake lines etc so it seems that it's easier and cheaper to go ahead and buy a new compete lift. Am I right?
Last edited by bjefferies94; 11-07-2016 at 04:45 PM. Reason: Left something out
#2
CF Veteran
Join Date: Feb 2016
Location: Northern New Mexico
Posts: 3,683
Likes: 0
Received 7 Likes
on
6 Posts
Year: 1999
Model: Cherokee
Engine: 4.0
So I'm in the process of building my jeep but having a hard time figuring out what I really want. My xj will be mainly used for wheeling and the occasional cruise around town. I have 35's ready to go on it from my other jeep and I have the front lifted 4.5". But it's a terrible lift with huge spacers.
So the question which has been asked a thousand times on here... Short arm or long arm it?
I'm kinda tight on money right now but I really need to get this thing put back together and out of my shop.
I've been looking at just buying a complete new 4.5" lift then going with the long arm upgrade later.
Again I said I had the front already lifted but I still need to replace the coils, rear leafs, shocks, brake lines etc so it seems that it's easier and cheaper to go ahead and buy a new compete lift. Am I right?
So the question which has been asked a thousand times on here... Short arm or long arm it?
I'm kinda tight on money right now but I really need to get this thing put back together and out of my shop.
I've been looking at just buying a complete new 4.5" lift then going with the long arm upgrade later.
Again I said I had the front already lifted but I still need to replace the coils, rear leafs, shocks, brake lines etc so it seems that it's easier and cheaper to go ahead and buy a new compete lift. Am I right?
#3
Junior Member
Thread Starter
Join Date: Nov 2016
Location: Greenwood
Posts: 31
Likes: 0
Received 0 Likes
on
0 Posts
Model: Cherokee
So maybe 5.5 and above? There isn't much price difference between the 4.5 and 6 so that's good. What other things do I have to consider when going with a long arm lift like that. What else would I need besides the lift kit itself
#4
CF Veteran
Join Date: Apr 2010
Location: st.george utah
Posts: 2,209
Likes: 0
Received 3 Likes
on
3 Posts
Year: 1996
Model: Cherokee
Engine: l6 4.0
Do it right or do it twice. Long arm is a must. Avoid spacers and blocks. Get quality shocks. I went with 4.5 and 33s. Then 6.5 and 35s. Now back to 33s. All had ups and downs.
You will also need o install a slip yoke eliminator. Which requires a new rear drive shaft.
Also a good trac bar must be installed. Some kits include one. Usually they are trash.
You will also need o install a slip yoke eliminator. Which requires a new rear drive shaft.
Also a good trac bar must be installed. Some kits include one. Usually they are trash.
#5
Seasoned Member
Join Date: Oct 2011
Location: spokane valley, wa
Posts: 433
Likes: 0
Received 2 Likes
on
2 Posts
Year: 1993
Model: Cherokee
Engine: 4.0
You say you already have a parts xj (that I'm assuming was lifted since you mentioned it had 35s). Do you by chance already have either adjustable or at least fixed aftermarket control arms? If you do you could also consider CA drop brackets. I'm not trying to open up the debate on what's better and blah blah blah... Just simply suggesting another option. We all know long arms are superior.
#6
CF Veteran
Yeah, you're not gonna do 4.5" properly without spending some coin. Coils, Leafs, SYE & rear driveshaft, shims, control arms (long or short), adjustable track bar, upgraded steering are all needed (I might be forgetting something).
The most complete kit I've found so far that includes long arms (radius arms) and a SYE & rear DS is from Serious Offroad here... http://www.seriousoffroadproducts.co...Path=419_2040&
The most complete kit I've found so far that includes long arms (radius arms) and a SYE & rear DS is from Serious Offroad here... http://www.seriousoffroadproducts.co...Path=419_2040&
#7
CF Veteran
Join Date: Jul 2013
Location: Monett, MO.
Posts: 7,554
Likes: 0
Received 14 Likes
on
14 Posts
Year: 1999
Model: Cherokee
Engine: 4.0
The lift kit is usually the cheapest part of doing it right, with 35's and a trail rig you will need gears and lockers, armor etc. the list is long and expensive.
Trending Topics
#9
Junior Member
Thread Starter
Join Date: Nov 2016
Location: Greenwood
Posts: 31
Likes: 0
Received 0 Likes
on
0 Posts
Model: Cherokee
It does make sense to do it right one time instead of having to lift it twice. I have fixed aftermarket control arms and cool spacers. As of now the 35's are just some tires I will be using from another jeep. Still need to get the Dana 44 put in the rear and new leafs but I may just wait until I purchase a long arm lift. Thanks for the help guys.
What are you guys running on your rigs?
What are you guys running on your rigs?
#10
CF Veteran
Mine's kind of a "custom" setup. I've kind of been putting mine together with what I want to get around 4.25 to 4.5". You can check out my build for more on it. If I get the parts I need before the weekend, there will be an update on my build shortly. Plans have taken a small detour over the last few weeks.
#12
Junior Member
Thread Starter
Join Date: Nov 2016
Location: Greenwood
Posts: 31
Likes: 0
Received 0 Likes
on
0 Posts
Model: Cherokee
#13
CF Veteran
Join Date: Feb 2013
Location: Belton S.C.
Posts: 1,286
Likes: 0
Received 1 Like
on
1 Post
Year: 1998
Model: Cherokee
Engine: 4.0
I'm running a Frankenstein 4.5" lift. RE coils, leafs ,and shackles with a RC long arm upgrade kit. No complaints with 20k+ miles with DD duty and moderate off-road. Also running Serious 1-ton steering, crown SYE, IRO track bar, JKS discos, bilstiens, and a ZJ front DS in the rear.
#14
Junior Member
Thread Starter
Join Date: Nov 2016
Location: Greenwood
Posts: 31
Likes: 0
Received 0 Likes
on
0 Posts
Model: Cherokee
I'm running a Frankenstein 4.5" lift. RE coils, leafs ,and shackles with a RC long arm upgrade kit. No complaints with 20k+ miles with DD duty and moderate off-road. Also running Serious 1-ton steering, crown SYE, IRO track bar, JKS discos, bilstiens, and a ZJ front DS in the rear.
#15
CF Veteran
Join Date: Feb 2013
Location: Belton S.C.
Posts: 1,286
Likes: 0
Received 1 Like
on
1 Post
Year: 1998
Model: Cherokee
Engine: 4.0
Thanks man. Just piece together a lift. It took me almost two years to collect all of my parts. Search the forums and web for lifted rigs with specs, so you can decide exactly which components you want.
This is the best time of year to buy parts, there should be lots of sales. Also a lot of vendors offer free shipping during the holiday season, which will save you a ton.
This is the best time of year to buy parts, there should be lots of sales. Also a lot of vendors offer free shipping during the holiday season, which will save you a ton.
