Bumper Build Bro
#17
Member
Thread Starter
Join Date: Jun 2013
Location: Kentucky
Posts: 136
Likes: 0
Received 0 Likes
on
0 Posts
Year: 95
Model: Cherokee
Engine: 4.0
#18
Member
Join Date: Jun 2011
Location: Lubbock, TX
Posts: 165
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1999
Model: Cherokee
Engine: 4.0
Maybe it'll help you in your designs.
#19
Seasoned Member
Join Date: Dec 2011
Location: Southern Maine
Posts: 437
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1999
Model: Cherokee
Engine: 4.0L
Nice build man I like the way you choose to do your front bumper I'm also in the process of building one shoul have it all finished tomorrow
#20
Member
Thread Starter
Join Date: Jun 2013
Location: Kentucky
Posts: 136
Likes: 0
Received 0 Likes
on
0 Posts
Year: 95
Model: Cherokee
Engine: 4.0
#21
Senior Member
Join Date: Aug 2009
Location: Tulsa,Oklahoma
Posts: 838
Likes: 0
Received 0 Likes
on
0 Posts
Year: 97
Model: Cherokee
Engine: 4.0
wow dude !!! I guess ace is the place Impressive !!! glad to see it didn't cause you any problems...
btw, after replacing my front bumper last week with another stock one, I found the front had been tapped pretty good and cause a front frame (at bumper mount) to be tweaked... so now I'm thinking a real bumper and winch myself, someday.....
btw, after replacing my front bumper last week with another stock one, I found the front had been tapped pretty good and cause a front frame (at bumper mount) to be tweaked... so now I'm thinking a real bumper and winch myself, someday.....
#22
Member
Thread Starter
Join Date: Jun 2013
Location: Kentucky
Posts: 136
Likes: 0
Received 0 Likes
on
0 Posts
Year: 95
Model: Cherokee
Engine: 4.0
#23
Seasoned Member
Join Date: Dec 2011
Location: Southern Maine
Posts: 437
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1999
Model: Cherokee
Engine: 4.0L
Awesome start! My question is I notice you incorporated where the trailer hitch would normally tie into did you just put the metal in there then mark where you needed to drill and weld those nuts in?
#25
Seasoned Member
Join Date: Dec 2011
Location: Southern Maine
Posts: 437
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1999
Model: Cherokee
Engine: 4.0L
#27
CF Veteran
Join Date: Mar 2012
Location: Richmond, VA
Posts: 1,369
Likes: 0
Received 0 Likes
on
0 Posts
Model: Cherokee
#28
Seasoned Member
Join Date: Sep 2011
Location: Arlington, TN (Memphis area)
Posts: 280
Likes: 0
Received 1 Like
on
1 Post
Year: 2000
Model: Cherokee
Engine: 242 Power Tech I6 (4.0)
I noticed you said 7/8" holes for the D rings... I really hope you didn't actually drill them to 7/8" holes. If you did the D rings aren't going to fit. A 3/4" D ring has a 7/8" pin, so you need to drill a 1" hole, not a 7/8" hole. Hence why when you buy D ring mounts they have a 1" hole drilled in them. So if you actually did drill them to 7/8", you might as well buy a 1" drill bit and start drilling, hole saw won't work now.... When I made my bumper I did a 1" drill bit, wish I would of done a hole saw though, took about 30 minutes a hole from start to finish.
Anyway, nice bumper and good start of the rear. Though when I did mine I used all the hitch bolts plus one extra further back, so i have 10 bolts holding my bumper/carrier on. But 8 should hold. The A to Z fab is the same kit I used too (mega spindle upgrade) and it is a very nice kit, have had it for over a year and it's still holding strong... though I do wish I would of went with a bushing style hinge and not a spindle type. The spindle that comes with the kit is great, but I eventually need to mount some gas cans and a high lift and I don't know how they spindle will hold, so I'm going to redo the whole swing at some point with a double shear bushing mount.
Just some food for thought if you ever plan to put some accessories on the swing, if you do put a carrier on it.
Anyway, nice bumper and good start of the rear. Though when I did mine I used all the hitch bolts plus one extra further back, so i have 10 bolts holding my bumper/carrier on. But 8 should hold. The A to Z fab is the same kit I used too (mega spindle upgrade) and it is a very nice kit, have had it for over a year and it's still holding strong... though I do wish I would of went with a bushing style hinge and not a spindle type. The spindle that comes with the kit is great, but I eventually need to mount some gas cans and a high lift and I don't know how they spindle will hold, so I'm going to redo the whole swing at some point with a double shear bushing mount.
Just some food for thought if you ever plan to put some accessories on the swing, if you do put a carrier on it.
#29
Member
Thread Starter
Join Date: Jun 2013
Location: Kentucky
Posts: 136
Likes: 0
Received 0 Likes
on
0 Posts
Year: 95
Model: Cherokee
Engine: 4.0
#30
Member
Thread Starter
Join Date: Jun 2013
Location: Kentucky
Posts: 136
Likes: 0
Received 0 Likes
on
0 Posts
Year: 95
Model: Cherokee
Engine: 4.0
Okay, I used a 15/16" hole saw and ended up around a 1" hole
I have $60 in this project so far because I got the metal for free. I would guess around $100 worth of material in the Front bumper
The gussets are a Good Idea, I would of used 2x4 or bigger tube but I just used what I had. Any way I will look into adding a few for moar strength
Thanks Guys! I still have not got any more scrap to work with
I have $60 in this project so far because I got the metal for free. I would guess around $100 worth of material in the Front bumper
The gussets are a Good Idea, I would of used 2x4 or bigger tube but I just used what I had. Any way I will look into adding a few for moar strength
Thanks Guys! I still have not got any more scrap to work with
