Ok after many many hours of sleepness nights and research during the day I have been unable to come to a decision on a complete in the box lift kit so I'll be doing a budget lift next weekend. Got the plans from this site...
http://www.lunghd.com/Tech_Articles/...udget_Lift.htm
Going to pull apart Tuesday to start looking for my coil springs and leaf springs. Drew up a list of parts and it came out to under $250. I figure I'll hit $250 or just over that once it's completely done. Here's the list of parts that I've gathered so far.
Leafs- $45.78 set (pull apart)
80’s S10 or 90’s Dakota
Coils- $21.54 set (pull apart)
75-79 F150 or *93-96 Grand Cherokee (also get isolators)
Rear Brake Hose- $16.99 (O'Reilly)
87-95 Wrangler (Wagner# BH123814)
Rear Shocks- $44.00 set (O'Reilly)
95 F150 4X4 (Monroe# 32386)
Front Shocks- $44.00 set (O'Reilly)
87-95 Wrangler (Monroe# 32219)
Front BPE’s- $29.99
Iron Rock Offroad
U-Bolts- $24.99
Iron Rock Offroad
I will be completing a technical write up in the how to section with pictures/part numbers/and instructions once it is done.
The Jeep will have long arms with a higher stance but this will be later. This lift is just to get me off the ground on 33's and keep me happy for a while! LOL!!! Wish me luck!!!
http://www.lunghd.com/Tech_Articles/...udget_Lift.htm
Going to pull apart Tuesday to start looking for my coil springs and leaf springs. Drew up a list of parts and it came out to under $250. I figure I'll hit $250 or just over that once it's completely done. Here's the list of parts that I've gathered so far.
Leafs- $45.78 set (pull apart)
80’s S10 or 90’s Dakota
Coils- $21.54 set (pull apart)
75-79 F150 or *93-96 Grand Cherokee (also get isolators)
Rear Brake Hose- $16.99 (O'Reilly)
87-95 Wrangler (Wagner# BH123814)
Rear Shocks- $44.00 set (O'Reilly)
95 F150 4X4 (Monroe# 32386)
Front Shocks- $44.00 set (O'Reilly)
87-95 Wrangler (Monroe# 32219)
Front BPE’s- $29.99
Iron Rock Offroad
U-Bolts- $24.99
Iron Rock Offroad
I will be completing a technical write up in the how to section with pictures/part numbers/and instructions once it is done.
The Jeep will have long arms with a higher stance but this will be later. This lift is just to get me off the ground on 33's and keep me happy for a while! LOL!!! Wish me luck!!!
CF Veteran
Joined: Sep 2009
Posts: 1,152
Likes: 2
From: louisiana
Year: 1994
Model: Cherokee
Engine: 2.5L
you shouldnt need the u bolts. just get leaf spring clamps u shouldnt need the rear brake hose either u can just pull it off the lil tab in the back and get plenty of slack. once you get all your parts you can bring it all over to my place and we can knock that out in a couple hours
Thread Starter
Senior Member
Joined: Jan 2010
Posts: 846
Likes: 0
From: South Louisiana
Year: 1990
Model: Cherokee
Engine: 4.0
you shouldnt need the u bolts. just get leaf spring clamps u shouldnt need the rear brake hose either u can just pull it off the lil tab in the back and get plenty of slack. once you get all your parts you can bring it all over to my place and we can knock that out in a couple hours
