Jeep Builds Make your own jeep build thread here, discuss and view jeeps here. All Jeep models are welcome here.

project: xjeep

Old 01-20-2010, 04:33 PM
  #1
Seasoned Member
Thread Starter

91xj's Avatar

Join Date: Apr 2009
Location: fresno, ca.
Posts: 344
Year: 1991
Model: Cherokee
Engine: 4.0 liter h.o.
Default project: xjeep

this is my first build. its a 91 xj that i bought from my uncle for 500 bucks. it had a lot of problems when i bought it about 3 years ago. i have kept all the receipts for everything i have done to it and so far i have spent a little over 3000 dollars to get it where i am happy with it. it has pro comp 3 inch coils in the front, along with the control arms. the rear is s10 bastard 3 inch leafs. cooper stt 31x10.50 15 on steel rock crawler rims. trimmed fenders. front non disco hp d30 from a 99. i have an 8.8 trussed for the rear with posi and disc brakes. (not in yet).
Attached Images
91xj is offline
Old 01-20-2010, 04:36 PM
  #2
Seasoned Member
Thread Starter

91xj's Avatar

Join Date: Apr 2009
Location: fresno, ca.
Posts: 344
Year: 1991
Model: Cherokee
Engine: 4.0 liter h.o.
Default

my plans for the future are the 6.5 inch longarm kit from rough country with some 35 inch mudders. custom tube bumper front and custom rear bumper with tire carrier, sliders in place of the rockers, truss the front axle, bedline interior heavily, one good coat on the underside, paint od green, or maybe flat black, and an exo cage.

Last edited by 91xj; 01-20-2010 at 04:40 PM.
91xj is offline
Old 01-20-2010, 04:51 PM
  #3
Seasoned Member
Thread Starter

91xj's Avatar

Join Date: Apr 2009
Location: fresno, ca.
Posts: 344
Year: 1991
Model: Cherokee
Engine: 4.0 liter h.o.
Default

my buddy almost flipped his bronco down the table top at my house (that i enjoy jumping in my jeep). the only thing holding it from going over was a small tree. i had to pull him sideways while he drove back and forth to work his way back up to the top. we had to move the chain up a little higher though. we had it on the leaf springs for some reason
Attached Images

Last edited by 91xj; 01-20-2010 at 10:43 PM.
91xj is offline
Old 01-20-2010, 09:56 PM
  #4
Seasoned Member

LCFRJEEP's Avatar

Join Date: Nov 2008
Location: Virginia
Posts: 452
Year: 1997
Model: Cherokee
Engine: 4.0 H.O.
Default

Hey man how did you do the bastard pack in the rear of your XJ?? Im thinkin of doin that to mine.
LCFRJEEP is offline
Old 01-20-2010, 10:19 PM
  #5
Seasoned Member
Thread Starter

91xj's Avatar

Join Date: Apr 2009
Location: fresno, ca.
Posts: 344
Year: 1991
Model: Cherokee
Engine: 4.0 liter h.o.
Default

well i only wanted three inches to match the front. if you also want to get a three inch lift, alls you do is take the s10 pack apart, remove its main and the helper spring, cut the s10 main to the length of the helper spring and put it on bottom. dont use the helper. bolt the pack to your main, and thats it. i had to customize my shackle a bit though because it made the pack shorter with more arch. i will take some pics tomorrow of the shackle. here is a pic of the pack with the helper spring in. its a little too stiff with it. i recommend putting the main leaf under there. just cut to length. gives it a very nice ride too.
Attached Images

Last edited by 91xj; 01-20-2010 at 10:29 PM.
91xj is offline
Old 01-20-2010, 10:33 PM
  #6
Seasoned Member
Thread Starter

91xj's Avatar

Join Date: Apr 2009
Location: fresno, ca.
Posts: 344
Year: 1991
Model: Cherokee
Engine: 4.0 liter h.o.
Default

here is what my stock springs looked like. i made a really long set of shackles to get three inches, then i jumped it a little too high.
Attached Images
91xj is offline
Old 01-20-2010, 10:37 PM
  #7
Seasoned Member
Thread Starter

91xj's Avatar

Join Date: Apr 2009
Location: fresno, ca.
Posts: 344
Year: 1991
Model: Cherokee
Engine: 4.0 liter h.o.
Default

i thought this was kinda cool. going to put my temp guage right next to it when i can get the stupid plug out of the block. anyone have any tips?
Attached Images
91xj is offline
Old 01-20-2010, 10:40 PM
  #8
CF Veteran

ckysodkorn_xj's Avatar

Join Date: Dec 2009
Location: Oxford NC
Posts: 1,882
Year: 1998
Model: Cherokee
Engine: 4.0L
Default

BFH
ckysodkorn_xj is offline
Old 01-20-2010, 10:44 PM
  #9
Seasoned Member
Thread Starter

91xj's Avatar

Join Date: Apr 2009
Location: fresno, ca.
Posts: 344
Year: 1991
Model: Cherokee
Engine: 4.0 liter h.o.
Default

to get the block drainage plug out? lol
91xj is offline
Old 01-22-2010, 01:49 AM
  #10
Seasoned Member
Thread Starter

91xj's Avatar

Join Date: Apr 2009
Location: fresno, ca.
Posts: 344
Year: 1991
Model: Cherokee
Engine: 4.0 liter h.o.
Default

sorry. i didnt get any pics today of the shackle, i will post them up soon
91xj is offline
Old 01-22-2010, 04:43 PM
  #11
Seasoned Member

LCFRJEEP's Avatar

Join Date: Nov 2008
Location: Virginia
Posts: 452
Year: 1997
Model: Cherokee
Engine: 4.0 H.O.
Default

Dont fool with the block drain plug. Go to Home Depot/ Lowes and get some piping. Specifically a galvanized "T" and a double male extension. Remove your temp sensor from the front of the t-stat housing and screw in the "T" where the sensor goes. On one end of the "T", screw in your sensor and the other end screw in the sensor for your gauge. Now my temp sensor is a mechanical gauge. I will take some pics and post them so you really understand.
LCFRJEEP is offline
Old 01-22-2010, 04:50 PM
  #12
Seasoned Member

LCFRJEEP's Avatar

Join Date: Nov 2008
Location: Virginia
Posts: 452
Year: 1997
Model: Cherokee
Engine: 4.0 H.O.
Default

Here is one of three
Attached Images
LCFRJEEP is offline
Old 01-22-2010, 04:51 PM
  #13
Seasoned Member

LCFRJEEP's Avatar

Join Date: Nov 2008
Location: Virginia
Posts: 452
Year: 1997
Model: Cherokee
Engine: 4.0 H.O.
Default

Two of three
Attached Images
LCFRJEEP is offline
Old 01-22-2010, 04:52 PM
  #14
Seasoned Member

LCFRJEEP's Avatar

Join Date: Nov 2008
Location: Virginia
Posts: 452
Year: 1997
Model: Cherokee
Engine: 4.0 H.O.
Default

Three of Three
Attached Images
LCFRJEEP is offline
Old 01-22-2010, 04:52 PM
  #15
Seasoned Member

LCFRJEEP's Avatar

Join Date: Nov 2008
Location: Virginia
Posts: 452
Year: 1997
Model: Cherokee
Engine: 4.0 H.O.
Default

Hope that helps
LCFRJEEP is offline
