Pulling motor out.
08-31-2013, 10:17 AM
#1
Member
Thread Starter
Join Date: Oct 2012
Location: California
Posts: 147
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1988
Model: Cherokee
Engine: 4.6 Stroker
Pulling motor out.
I'm pulling the 4.0 out of my automatic 88 cherokee. Can i pull the motor and tranny at the same time or do i have to detach the tranny and pull it seperately? I'm pulling both of them either way.
I'm starting on this today so if you have any tips or should knows on pulling the motor let me know, thanks
I'm starting on this today so if you have any tips or should knows on pulling the motor let me know, thanks
08-31-2013, 10:27 AM
#2
Caracticus Potts The Mod
if you don't have a really good engine crane and a paved or concrete rolling surface....separate the engine and trans.
Last edited by Willys55; 08-31-2013 at 10:39 AM.
08-31-2013, 10:34 AM
#3
CF Veteran
Join Date: Mar 2011
Location: California
Posts: 2,570
Likes: 0
Received 4 Likes
on
4 Posts
Year: 1992
Model: Cherokee
Engine: 4.0 HO
I've done both, pulled the engine and trans out of a 98 and pulled just the engine out of my 92. Was much easier to pull both at once. You'll want a decent sized engine hoist and at least 1 extra set of hands.
08-31-2013, 11:09 AM
#4
CF Veteran
Join Date: Feb 2011
Location: Bergen County, New Jersey U.S.A.
Posts: 3,074
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1990 Laredo
Model: Cherokee
Engine: 4.0 Inline 6 Renix
If you are on a flat hard surface with a good engine hoist or good tree and chain it is better to pull both less work for you and find it better to remove the hood gives you more room to work...
08-31-2013, 09:18 PM
#5
::CF Moderator::
Join Date: Aug 2011
Location: Prescott, Az
Posts: 43,875
Received 1,526 Likes
on
1,238 Posts
Year: 1990
Model: Cherokee (XJ)
Engine: 4.0
Way too much work. Remove radiator. Support trans, remove engine. Lay the power steering pump where the air cleaner WAS and the AC compressor where the battery WAS.
09-01-2013, 09:26 AM
#7
::CF Moderator::
Join Date: Aug 2011
Location: Prescott, Az
Posts: 43,875
Received 1,526 Likes
on
1,238 Posts
Year: 1990
Model: Cherokee (XJ)
Engine: 4.0
Trending Topics
09-01-2013, 01:44 PM
#10
Member
Thread Starter
Join Date: Oct 2012
Location: California
Posts: 147
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1988
Model: Cherokee
Engine: 4.6 Stroker
Stupid question
How do you disconnect the metal hose that goes to the lower radiator part? its got those plastic things sticking out of each side where it looks like it should disconnect. Those same type of disconnects are running to the fuel rail as well. I just don't want to break them so im checking to see the proper way to remove them
09-01-2013, 01:47 PM
#11
CF Veteran
Join Date: Mar 2011
Location: California
Posts: 2,570
Likes: 0
Received 4 Likes
on
4 Posts
Year: 1992
Model: Cherokee
Engine: 4.0 HO
How do you disconnect the metal hose that goes to the lower radiator part? its got those plastic things sticking out of each side where it looks like it should disconnect. Those same type of disconnects are running to the fuel rail as well. I just don't want to break them so im checking to see the proper way to remove them
09-01-2013, 06:49 PM
#13
Member
Thread Starter
Join Date: Oct 2012
Location: California
Posts: 147
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1988
Model: Cherokee
Engine: 4.6 Stroker
So im pulling the tranny and the motor both at once. I got everything disconnected from the motor, but what exactly do i need to disconnect from the AW4, and any tips? I'm not as smart when it comes to transmisiions, but im learning. Thanks
09-01-2013, 08:35 PM
#14
::CF Moderator::
Join Date: Aug 2011
Location: Prescott, Az
Posts: 43,875
Received 1,526 Likes
on
1,238 Posts
Year: 1990
Model: Cherokee (XJ)
Engine: 4.0
