IAC
#2
CF Veteran
As the name states, its involved in regulating the air inflow during idle, or whenever your foot comes of the gas, like slowing down a hill or come to a stop. The device is quite simple, a rod or pinion its called, moves in and out, whenever ur engine goes idle. Symptoms related to this usually rekate to the pinion being stuck, not allowing the required or desired amount of air in, resulting in rough idle, dying after stating up, stalling whilst sit in front of traffic lights etc. Surging ,high,or low idle is another one, where to ECU is getting incorrect information and tries to adjust the air/fuel mix.
Cleaning the IAC is therefore an item on the list when you have symptoms like that, its simple and there is info available on theforum how to do this. Hope this helps.
Cleaning the IAC is therefore an item on the list when you have symptoms like that, its simple and there is info available on theforum how to do this. Hope this helps.
#3
::CF Moderator::
Join Date: Aug 2011
Location: Prescott, Az
Posts: 43,875
Received 1,526 Likes
on
1,238 Posts
Year: 1990
Model: Cherokee (XJ)
Engine: 4.0
Ever done this? If not, it's about time.
--------------------------------------------------------------------
The Idle Air Control (IAC) is mounted on the back of the throttle body. (front for 87-90) The valve controls the idle speed of the engine by controlling the amount of air flowing through the air control passage. It consists of a stepper motor that moves a pintle shaped plunger in and out of the air control passage. When the valve plunger is moved in, the air control passage flows more air which raises the idle speed. When the valve plunger is moved out, the air control passage flows less air which lowers the idle speed. Over time and miles, the IAC can get carboned up which can have an adverse affect on idle quality. Cleaning the IAC may restore proper function and is an easy procedure to perform and good preventive maintenance so it is never a bad idea.
CLEANING THE JEEP 4.0 IDLE AIR CONTROL
Remove the air filter cover, associated hoses and the rubber boot that goes from the air filter cover to the throttle body. Remove the IAC with a torx driver (2 bolts; one can be kind of hard to get to)
"Gently" wiggle out the IAC from the throttle body. Gasket on the IAC can be re-used if it is not damaged
Clean the IAC with a spray can of throttle body cleaner; inexpensive and available at any place that sells auto parts. Throttle body cleaner is recommended rather than carburetor cleaner as it is less harsh, safe for throttle body coatings and is best for this task. Use cleaner, a rag and a toothbrush and or Q-Tips. Be gentle; don’t twist or pull on the pintle that protrudes from the IAC as it is fragile and you could damage it.
Thoroughly spray clean and flush where the IAC seats in the throttle body with the same spray cleaner
It is also a good idea to clean the entire throttle body itself, the butterfly valve inside of the throttle body and all associated linkage as long as you have things disassembled
--------------------------------------------------------------------
The Idle Air Control (IAC) is mounted on the back of the throttle body. (front for 87-90) The valve controls the idle speed of the engine by controlling the amount of air flowing through the air control passage. It consists of a stepper motor that moves a pintle shaped plunger in and out of the air control passage. When the valve plunger is moved in, the air control passage flows more air which raises the idle speed. When the valve plunger is moved out, the air control passage flows less air which lowers the idle speed. Over time and miles, the IAC can get carboned up which can have an adverse affect on idle quality. Cleaning the IAC may restore proper function and is an easy procedure to perform and good preventive maintenance so it is never a bad idea.
CLEANING THE JEEP 4.0 IDLE AIR CONTROL
Remove the air filter cover, associated hoses and the rubber boot that goes from the air filter cover to the throttle body. Remove the IAC with a torx driver (2 bolts; one can be kind of hard to get to)
"Gently" wiggle out the IAC from the throttle body. Gasket on the IAC can be re-used if it is not damaged
Clean the IAC with a spray can of throttle body cleaner; inexpensive and available at any place that sells auto parts. Throttle body cleaner is recommended rather than carburetor cleaner as it is less harsh, safe for throttle body coatings and is best for this task. Use cleaner, a rag and a toothbrush and or Q-Tips. Be gentle; don’t twist or pull on the pintle that protrudes from the IAC as it is fragile and you could damage it.
Thoroughly spray clean and flush where the IAC seats in the throttle body with the same spray cleaner
It is also a good idea to clean the entire throttle body itself, the butterfly valve inside of the throttle body and all associated linkage as long as you have things disassembled
#4
CF Veteran
Thread Starter
Join Date: Jul 2012
Location: San Antonio, TX
Posts: 4,104
Likes: 0
Received 2 Likes
on
2 Posts
Year: 1996
Model: Cherokee
Engine: 4.0L
Yea i took the throlt body off and gave it a really good cleaning and im stuck with a high idle at about 1200 rpm and im thinking that may be my problem cause i cant find any vacum leaks anywhere
#5
::CF Moderator::
Join Date: Aug 2011
Location: Prescott, Az
Posts: 43,875
Received 1,526 Likes
on
1,238 Posts
Year: 1990
Model: Cherokee (XJ)
Engine: 4.0
Did you remove and clean the IAC?
#7
::CF Moderator::
Join Date: Aug 2011
Location: Prescott, Az
Posts: 43,875
Received 1,526 Likes
on
1,238 Posts
Year: 1990
Model: Cherokee (XJ)
Engine: 4.0
Trending Topics
#9
::CF Moderator::
Join Date: Aug 2011
Location: Prescott, Az
Posts: 43,875
Received 1,526 Likes
on
1,238 Posts
Year: 1990
Model: Cherokee (XJ)
Engine: 4.0
TPS could be taking a dump on you.
