Stock XJ Cherokee Tech. All XJ Non-modified/stock questions go here XJ (84-01)
All OEM related XJ specific tech. Examples, no start, general maintenance or anything that's stock.

Black Ball

Thread Tools

Search this Thread

Old Oct 16, 2013 | 11:17 AM
  #1
RJ60's Avatar
Thread Starter
Newbie

Joined: Oct 2013
Posts: 13
Likes: 0
From: Colorado Springs
Year: 2001
Model: Cherokee
Engine: 4.0
Default Black Ball

Can anyone tell me what the ball like canister behind front bumper passenger side 2001 XJ is?
Reply
Old Oct 16, 2013 | 11:45 AM
  #2
EZEARL's Avatar
CF Veteran

Joined: Aug 2009
Posts: 5,676
Likes: 301
From: WV
Year: '96
Model: Cherokee
Default

Here you go(per cruiser54):

Reply
Old Oct 16, 2013 | 12:16 PM
  #3
dzeinert's Avatar
Member

Joined: Mar 2012
Posts: 113
Likes: 0
From: Minnesota
Year: 1999
Model: Cherokee
Engine: 4.0 I6
Default

I believe that vacuum ball is used for cruise control and something else. Can't remember what.
Reply
Old Oct 16, 2013 | 12:30 PM
  #4
Gee oh Dee's Avatar
CF Veteran

Joined: Sep 2010
Posts: 21,168
Likes: 5
From: Milwaukee, WI
Year: 1987
Engine: Check
Default

Heating/cooling controls. And maybe cruise.

Mine had more than enough slack to relocate it to the pass side firewall, out of harms way.
Reply
Old Oct 16, 2013 | 04:38 PM
  #5
cruiser54's Avatar
::CF Moderator::

Joined: Aug 2011
Posts: 43,971
Likes: 1,579
From: Prescott, Az
Year: 1990
Model: Cherokee (XJ)
Engine: 4.0
Default

Originally Posted by EZEARL
Here you go(per cruiser54):

I stole that from CCKen!! LOL. Glad it's being put to good use.
Reply
Old Oct 17, 2013 | 08:54 AM
  #6
RJ60's Avatar
Thread Starter
Newbie

Joined: Oct 2013
Posts: 13
Likes: 0
From: Colorado Springs
Year: 2001
Model: Cherokee
Engine: 4.0
Default

Thanks for the info
Reply
Old Oct 17, 2013 | 09:56 AM
  #7
EZEARL's Avatar
CF Veteran

Joined: Aug 2009
Posts: 5,676
Likes: 301
From: WV
Year: '96
Model: Cherokee
Default


Sorry Ken.
Reply
Old Oct 17, 2013 | 04:00 PM
  #8
cruiser54's Avatar
::CF Moderator::

Joined: Aug 2011
Posts: 43,971
Likes: 1,579
From: Prescott, Az
Year: 1990
Model: Cherokee (XJ)
Engine: 4.0
Default

Originally Posted by EZEARL
Sorry Ken.
Don't be sorry!! We steal this stuff from each other quite frequently.

Go ahead. Post up a photo on a tech item. I'll steal it.
Reply
Old Oct 17, 2013 | 06:01 PM
  #9
EZEARL's Avatar
CF Veteran

Joined: Aug 2009
Posts: 5,676
Likes: 301
From: WV
Year: '96
Model: Cherokee
Default

Well I can't say I wasn't warned.
Reply
Old Oct 17, 2013 | 06:26 PM
  #10
cruiser54's Avatar
::CF Moderator::

Joined: Aug 2011
Posts: 43,971
Likes: 1,579
From: Prescott, Az
Year: 1990
Model: Cherokee (XJ)
Engine: 4.0
Default

Originally Posted by EZEARL
Well I can't say I wasn't warned.
Just remembered. I stole your write-up on headlight harness upgrades and foglight issues.

I DID give you credit for it though.
Reply
Old Oct 17, 2013 | 06:38 PM
  #11
EZEARL's Avatar
CF Veteran

Joined: Aug 2009
Posts: 5,676
Likes: 301
From: WV
Year: '96
Model: Cherokee
Default

Well,I kinda found that while doing a search. It did take looong time to find it and to make sure it was legit so I guess I kinda payed for it.
Reply
Old Oct 17, 2013 | 06:45 PM
  #12
CCKen's Avatar
CF Veteran

Joined: Aug 2010
Posts: 8,357
Likes: 103
From: Canton, MI
Year: 1999
Model: Cherokee
Engine: 4.0
Default

Originally Posted by Gee oh Dee
Heating/cooling controls. And maybe cruise.

Mine had more than enough slack to relocate it to the pass side firewall, out of harms way.
Actually, the Vacuum Reservoir is called a "Reservoir, Speed Control". It shows up in the parts catalog under the Speed Control Section. It is not associated with the HVAC system.

The Heater and AC Vacuum Harness only feeds the reservoir.


Data, not opinion.
Reply
Old Oct 17, 2013 | 06:47 PM
  #13
dzeinert's Avatar
Member

Joined: Mar 2012
Posts: 113
Likes: 0
From: Minnesota
Year: 1999
Model: Cherokee
Engine: 4.0 I6
Default

Originally Posted by CCKen

Actually, the Vacuum Reservoir is called a "Reservoir, Speed Control". It shows up in the parts catalog under the Speed Control Section. It is not associated with the HVAC system.

The Heater and AC Vacuum Harness only feeds the reservoir.

Data, not opinion.
+1 for this guy
Reply
Old Oct 18, 2013 | 08:25 AM
  #14
Gee oh Dee's Avatar
CF Veteran

Joined: Sep 2010
Posts: 21,168
Likes: 5
From: Milwaukee, WI
Year: 1987
Engine: Check
Default

Originally Posted by CCKen
Actually, the Vacuum Reservoir is called a "Reservoir, Speed Control". It shows up in the parts catalog under the Speed Control Section. It is not associated with the HVAC system.

The Heater and AC Vacuum Harness only feeds the reservoir.


Data, not opinion.
:eyeroll:
Reply
Old Oct 18, 2013 | 09:20 AM
  #15
salad's Avatar
Herp Derp Jerp
Premium Member

Joined: Nov 2011
Posts: 18,251
Likes: 17
From: Parham, ON
Year: 1999
Model: Cherokee
Engine: 4.0L OBD-II
Default

Originally Posted by CCKen
It shows up in the parts catalog under the Speed Control Section. It is not associated with the HVAC system
Originally Posted by CCKen
The Heater ... Vacuum Harness only feeds the reservoir.
Not related eh?

Black Ball-image-638221789.jpg

It must be Opposite Day!
