4.0 torque specs

Reply



Thread Tools Search this Thread
Old 11-18-2011, 01:12 PM   #1
Newbie
Thread Starter

Join Date: Nov 2011
Posts: 25

View FILO's Photo Album My Photos
Model: Cherokee
Default 4.0 torque specs

DOES ANYONE ON HERE HAVE THE ENGINE TORQUE SPECS FOR ENGINE REBUILD .94 JEEP CHEROKEE
FILO is offline   Reply With Quote
Old 11-18-2011, 01:30 PM   #2
☠ CF Sheriff ☠

dukie564's Avatar

Join Date: Nov 2009
Location: Aberdeen, MD
Posts: 15,174

View dukie564's Photo Album My Photos
Year: 1995
Model: Cherokee
Engine: 4.0L HO I-6, 703 Injectors, Brown Dog Super Engine Mounts
Default

dukie564 is offline   Reply With Quote
Old 11-18-2011, 03:32 PM   #3
Senior Member

413maxwedge's Avatar

Join Date: Jan 2011
Location: Upstate N.Y
Posts: 689

View 413maxwedge's Photo Album My Photos
Year: 2000.1999,1996
Model: Cherokee
Engine: 4.0
Default

Yup right in my haynes manual, go buy one for 20.00 they are helpful.
413maxwedge is offline   Reply With Quote
Old 11-18-2011, 04:46 PM   #4
Newbie
Thread Starter

Join Date: Nov 2011
Posts: 25

View FILO's Photo Album My Photos
Model: Cherokee
Default

THANKS DUKIE
FILO is offline   Reply With Quote
Old 11-18-2011, 04:49 PM   #5
CF Veteran

99 Purple XJ's Avatar

Join Date: Oct 2010
Location: Long Island N.Y.
Posts: 1,889

View 99 Purple XJ's Photo Album My Photos
Year: 1999
Model: Cherokee
Engine: I6 4.0
Default

Or find a book i found a factory bool on how to disassemble and reassemble a 4.0 with torque specs and everything in it
99 Purple XJ is offline   Reply With Quote
Old 11-18-2011, 05:17 PM   #6
Newbie
Thread Starter

Join Date: Nov 2011
Posts: 25

View FILO's Photo Album My Photos
Model: Cherokee
Default SEQUENCE

@PURPLE WHATS THE NAME OF THE BOOK IF YOU DONT MIND .I JUST NEED TORQUE SEQUENCE OF MAIN CAP BEARINGS AND OF THE HEAD .WANT TO SEE WHY NUMBER 11 BOLT NEEDS 110ft lbs INSTEAD OF 100ft lbs 3RD STEP .TORQUE ON THE HEAD BOLTS .ALSO FOUND A GOOD WEBSITE .http://www.torkspec.com
FILO is offline   Reply With Quote
Old 11-19-2011, 02:41 PM   #7
☠ CF Sheriff ☠

dukie564's Avatar

Join Date: Nov 2009
Location: Aberdeen, MD
Posts: 15,174

View dukie564's Photo Album My Photos
Year: 1995
Model: Cherokee
Engine: 4.0L HO I-6, 703 Injectors, Brown Dog Super Engine Mounts
Default

he's talking about a factory service manual

Here's the tightening sequence for the head bolts:


The #11 bolt torque is LOWER than the rest. This is because you need to install that bolt with red locktite 592 (high-temp) sealant - the locktite affects the torque reading.

So all the bolts get 110 ft-lb, except #11 which gets locktite and 100 ft-lb
dukie564 is offline   Reply With Quote
Old 11-19-2011, 04:52 PM   #8
Senior Member

413maxwedge's Avatar

Join Date: Jan 2011
Location: Upstate N.Y
Posts: 689

View 413maxwedge's Photo Album My Photos
Year: 2000.1999,1996
Model: Cherokee
Engine: 4.0
Default

Its in the water jacket and like above the sealent affects its torqe.
413maxwedge is offline   Reply With Quote
Old 09-30-2017, 01:16 PM   #9
Newbie

Join Date: Sep 2017
Posts: 1

View Keith Draves's Photo Album My Photos
Model: Cherokee
Default Same issue

It had the same issue with my 99 checked 4.0 the misfire was caused by the crank position sensor located on top of the bellhousing its a pain in the *** to change but well worth it. Should cost you about 89.00$ at O'Riley.
Keith Draves is offline   Reply With Quote
Old 09-30-2017, 01:55 PM   #10
☠CF-K9 Unit☠

Dumajones's Avatar

Join Date: Apr 2012
Location: Alaska
Posts: 4,894

View Dumajones's Photo Album My Photos
Year: 2000 sport
Engine: New 4.0l from s&j engines
Default

Dumajones is offline   Reply With Quote
Old 09-30-2017, 02:00 PM   #11
TIME TO GET SCHWIFTY

roninofako's Avatar

Join Date: Feb 2011
Location: Apple Valley, CA
Posts: 12,141

View roninofako's Photo Album My Photos
Year: 97
Model: Cherokee
Engine: 4.6 stroker
Default

Quote:
Originally Posted by Dumajones View Post
A caucasian sounds famous right now, LOL
roninofako is offline   Reply With Quote
Old 09-30-2017, 02:40 PM   #12
CF Veteran

Bugout4x4's Avatar

Join Date: May 2015
Location: Arizona
Posts: 2,204

View Bugout4x4's Photo Album My Photos
Year: 97
Model: Cherokee
Engine: 4.0
Default

Quote:
Originally Posted by dukie564 View Post
he's talking about a factory service manual

Here's the tightening sequence for the head bolts:


The #11 bolt torque is LOWER than the rest. This is because you need to install that bolt with red locktite 592 (high-temp) sealant - the locktite affects the torque reading.

So all the bolts get 110 ft-lb, except #11 which gets locktite and 100 ft-lb
I just learned something very very valuable in this. I just tore mine down because what I thought was an exhaust leak on the #1 hole was actually compression spitting out between the head and the block on the #1 cylinder. No locktite? it backed off?
Bugout4x4 is online now   Reply With Quote
