Jeep Cherokee 1984-2001: How to Replace/Install Windshield Molding

Leaky windshield molding is troublesome and can mean in-car showers during rainy season. Luckily, you don't need to replace the windshield to fix this problem. Read this article to discover more information on how to fix leaks.

By Neftali Medina - September 1, 2015
Contributors: BleepinJeep

This article applies to the Jeep Cherokee (1984-2001).

The windshield on your Jeep Cherokee XJ is held in place with a sealant which also acts as its molding. You'll notice when the sealant fails, as rain and other moisture makes their way through. Unfortunately, there is no way to replace the window molding without removing the windshield. However, you can access the windshield sealant and apply some silicone onto the leak. Although a complete, professional windshield replacement is recommended, this quick fix can generally hold up to a year of abuse.

Materials Needed

  • Flat head screwdriver
  • Caulk gun
  • Silicone
  • New windshield trim

Step 1 – Remove the windshield trim

First remove the windshield wiper and set it aside, then focus on the chrome stripping found around the windshield.

Figure 1. Remove the windshield wiper.
  • Grab your flat head screwdriver and pry upwards around the windshield.
  • Begin at one corner of the windshield and gently pull up.
  • Loosen the clips that hold the trim in place, then proceed to slide them off the glass.
  • Pull off the first clip from the side, then begin to pull out the windshield trim.
  • Repeat this procedure for each side of the windshield.
  • Figure 2. Start at one corner of the windshield, prying it upwards.
  • Figure 3. Slide out the window trim.
  • Figure 4. Repeat the process for the other side.
  • Figure 5. Slide off the top trim.
  • Figure 6. Slide off the bottom trim.
  • Figure 7. Slide off the remaining trim.

Step 2 – Clean off the windshield molding and apply sealant

  • Use a hose to clean off the windshield molding and remove any debris.
    • Figure 8. Clean the windshield.
  • Locate the leak and squeeze a bead to seal it.
  • Allow the specified amount of time it needs to set and apply more if necessary.
  • Install clips for the new pieces of window trim.
Figure 9. Apply sealant where necessary.

Step 3 – Install the new windshield trim

Once the sealant has dried, install the new pieces of window trim.

  • Carefully align them onto each part of the windshield.
  • Then, proceed to click them in place. Make your way around the windshield, clicking each one into place.
Figure 10. Make your way around the windshield.
