need more electrical power!!!
#1
Member
Thread Starter
Join Date: Jul 2014
Location: Papillion, NE
Posts: 160
Likes: 0
Received 1 Like
on
1 Post
Year: 1999
Model: Cherokee
Engine: 4.0 litre I6
need more electrical power!!!
So..my I just installed hids on a harness...I have a sound system ready to go in, I plan on using extra lights and I'm really worried I'm gonna overpower the ol jeep.
With my s10 I swapped alternators for an ad244. Took care of all my power issues forever.
What can I do to beef up my system? I've already swapped all the stock wiring for thicker stuff what else...
I'll get a spectre cowl intake if it means I can use another battery I guess
With my s10 I swapped alternators for an ad244. Took care of all my power issues forever.
What can I do to beef up my system? I've already swapped all the stock wiring for thicker stuff what else...
I'll get a spectre cowl intake if it means I can use another battery I guess
#3
Member
Thread Starter
Join Date: Jul 2014
Location: Papillion, NE
Posts: 160
Likes: 0
Received 1 Like
on
1 Post
Year: 1999
Model: Cherokee
Engine: 4.0 litre I6
Is there an alternator people typically swap err what...? Most likely can't afford a brand new one
#7
CF Veteran
Join Date: Jul 2013
Location: Monett, MO.
Posts: 7,554
Likes: 0
Received 14 Likes
on
14 Posts
Year: 1999
Model: Cherokee
Engine: 4.0
I used a 136 amp on mine only a small amount of grinding on the mount needed to install then plug and play no other mods. Bought it from a member here for $100 shipped new rebuilt works great and much better output than the 117 amp stocker. I know only 20 amps but it does show when I'm running most all of my trail lights (3 sets Hella Black Magic's and 1 set side Hella 8").
I do run 2 large Optima batteries with a isolator, even using one battery and my Superwinch 9.5 it runs a more steady speed longer at idle while winching. Here you can see the lights (except for the side ones hadn't been mounted yet) and there 8" rear Hellas for backup and work lights.
I do run 2 large Optima batteries with a isolator, even using one battery and my Superwinch 9.5 it runs a more steady speed longer at idle while winching. Here you can see the lights (except for the side ones hadn't been mounted yet) and there 8" rear Hellas for backup and work lights.
Last edited by Fred/N0AZZ; 08-19-2014 at 08:45 AM.
Trending Topics
#8
CF Veteran
Join Date: Oct 2013
Location: Tarpon Springs, FL / Denver, CO
Posts: 2,097
Likes: 0
Received 8 Likes
on
7 Posts
Year: '98
Engine: 4.0 I6
I used a Durango 136 amp alternator, which my local starter & alternator shop rebuilt and rewound to around 150 amps (load tested). Only cost me $20 for a junkyard alternator, and $120 for the alternator rebuild and rewind (rebuild only was $70 IIRC).
Can anyone confirm that the Durango 160 amp alternator is physically BIGGER than the 136 amp alternator? I was under the impression that the case size was similar, and would fit in the stock location.
You will need to grind the alternator bracket and engine block for clearance regardless of which alternator you get (ZJ or Durango), but if you have a die grinder it is no more than 2-3 minutes of grinding to massage it in. You absolutely must upgrade the main alternator positive wire to the battery with an appropriate fuse though.
EDIT:
Just for fun, here is an old picture of the old vs new brushes;
http://img.photobucket.com/albums/v4...112_230326.jpg
I was trying to find a picture of my old alternator next to the new one, but I dont know where I uploaded it to
Can anyone confirm that the Durango 160 amp alternator is physically BIGGER than the 136 amp alternator? I was under the impression that the case size was similar, and would fit in the stock location.
You will need to grind the alternator bracket and engine block for clearance regardless of which alternator you get (ZJ or Durango), but if you have a die grinder it is no more than 2-3 minutes of grinding to massage it in. You absolutely must upgrade the main alternator positive wire to the battery with an appropriate fuse though.
EDIT:
Just for fun, here is an old picture of the old vs new brushes;
http://img.photobucket.com/albums/v4...112_230326.jpg
I was trying to find a picture of my old alternator next to the new one, but I dont know where I uploaded it to
Last edited by investinwaffles; 08-19-2014 at 11:08 AM.
#10
Member
Thread Starter
Join Date: Jul 2014
Location: Papillion, NE
Posts: 160
Likes: 0
Received 1 Like
on
1 Post
Year: 1999
Model: Cherokee
Engine: 4.0 litre I6
Now just thinkin about doin a capacitor or getting rewound or getting a better battery....I think I got ahead of myself with the alt swap idea...just sounds like a pita.
Last edited by 99XJake; 08-19-2014 at 02:07 PM.
#11
CF Veteran
Join Date: Oct 2013
Location: Tarpon Springs, FL / Denver, CO
Posts: 2,097
Likes: 0
Received 8 Likes
on
7 Posts
Year: '98
Engine: 4.0 I6
It took me 2 hours start to finish - its super easy!
Basically, remove the old alternator and bracket. Keep grinding at the bracket until the new alternator bolt holes line up (taking off too much here doesnt matter).
Next, slide the whole assembly into the car, and look for where you need to grind at the block. There are two "nubs" with PLENTY of meat on em to grind for clearance. Keep going until the whole things lots into place. Then, just bolt everything back up and put the belt back on.
You will still need to upgrade some of the wiring, but not a big deal.
Also consider replacing your battery, if you have a stock sized 550cca battery. I shoehorned an 800CCA battery in mine with some small mods to the battery tray;
Basically, remove the old alternator and bracket. Keep grinding at the bracket until the new alternator bolt holes line up (taking off too much here doesnt matter).
Next, slide the whole assembly into the car, and look for where you need to grind at the block. There are two "nubs" with PLENTY of meat on em to grind for clearance. Keep going until the whole things lots into place. Then, just bolt everything back up and put the belt back on.
You will still need to upgrade some of the wiring, but not a big deal.
Also consider replacing your battery, if you have a stock sized 550cca battery. I shoehorned an 800CCA battery in mine with some small mods to the battery tray;
#13
Member
Thread Starter
Join Date: Jul 2014
Location: Papillion, NE
Posts: 160
Likes: 0
Received 1 Like
on
1 Post
Year: 1999
Model: Cherokee
Engine: 4.0 litre I6
Okay, well when you put it that way it doesn't sound terrible...
I was brainstorming with the techs at work and they were against the alt swap..
I have an 800 but it's that Walmart brand crap
I've done the ground and got better terminals but the hots running to the alternator looks like a pain too
I was brainstorming with the techs at work and they were against the alt swap..
I have an 800 but it's that Walmart brand crap
I've done the ground and got better terminals but the hots running to the alternator looks like a pain too
#14
Member
Thread Starter
Join Date: Jul 2014
Location: Papillion, NE
Posts: 160
Likes: 0
Received 1 Like
on
1 Post
Year: 1999
Model: Cherokee
Engine: 4.0 litre I6
So it's my understanding that I should look for a 5.2 99 durango?
Have I said already that I hate the location of our alternators? Freakin buried and stupid
Have I said already that I hate the location of our alternators? Freakin buried and stupid
#15
Seasoned Member
Join Date: Apr 2011
Location: Yuma
Posts: 420
Likes: 0
Received 1 Like
on
1 Post
Year: 1993
Model: Cherokee
Engine: 4.0, APN header & 2.5" exhaust
I think a group 34 size battery can fit but it might need modification to the tray.
Honestly I don't think you are overloading your factory alternator just yet. Keep in mind you saved ~20w per side when you did hid lights. 400w RMS isn't a crazy amount, but a 1 farad capacitor would be a good idea.
If you want to have a warm fuzzy feeling about your charging system, do the 136a alternator. It's really not that much grinding and you already upgraded your wiring for the additional available power, so why not.. you should be able to get one from a salvage yard for like $35.
Honestly I don't think you are overloading your factory alternator just yet. Keep in mind you saved ~20w per side when you did hid lights. 400w RMS isn't a crazy amount, but a 1 farad capacitor would be a good idea.
If you want to have a warm fuzzy feeling about your charging system, do the 136a alternator. It's really not that much grinding and you already upgraded your wiring for the additional available power, so why not.. you should be able to get one from a salvage yard for like $35.
