Lower control arms issue
I have a 1996 Cherokee Sport and I recently bought a pro comp 3 inch lift (add a leaf). I installed everything but the lower control arms fairly easily, but I can't get the holes to line up on the lower control arms. I tried to use a ratchet, and that didn't work. I also tried to move the axle which also didn't work. Has anybody else ran into this problem? Any suggestions are welcome, thanks everyone.
-Justen
-Justen
#2
Senior Member
Join Date: Mar 2011
Location: VA
Posts: 770
Likes: 0
Received 1 Like
on
1 Post
Year: 2000
Model: Cherokee (XJ)
Engine: 4L, 6 cylinder, 190 hp, 225 ft lp torque
You are so right, getting the lower control arms with fixed bushings installed is not easy. Disconnect the track bar and use ratchet straps and a pry bar to move the axle to install one at a time. I now have the adjustable lowers from Rough Country with ball-in-joints which made installation a little easier. If your going to be rock crawling, consider having axle heavy duty lower control arm mounts welded on; the stock axle lower mounts won't stand up to rock crawling.
#3
Newbie
Thread Starter
Join Date: Mar 2017
Posts: 5
Likes: 0
Received 0 Likes
on
0 Posts
Model: Cherokee
You are so right, getting the lower control arms with fixed bushings installed is not easy. Disconnect the track bar and use ratchet straps and a pry bar to move the axle to install one at a time. I now have the adjustable lowers from Rough Country with ball-in-joints which made installation a little easier. If your going to be rock crawling, consider having axle heavy duty lower control arm mounts welded on; the stock axle lower mounts won't stand up to rock crawling.
-Justen
