how to adjust
ok a week ago i bent my tie rod and had to replace it.now i am still noticing that my camber looks to be way off. how do i adjust this?......i dont know if it matter but i do not have sway bars.....when i replaced the tie rod bar i did not lift the jeep off the ground thinking it would stay the same?
#2
CF Veteran
Join Date: Jul 2011
Location: Pompano Beach
Posts: 1,386
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1998
Model: Cherokee
Engine: 4.0
You can't adjust camber with tierod, only toe in/out. If it was bent, it probably was toe'd in and still is. Search "toe in out adjustment". If you really mean camber, it's not tierod, maybe BJ.
#3
CF Veteran
Join Date: Sep 2010
Location: Milwaukee, WI
Posts: 21,168
Likes: 0
Received 5 Likes
on
5 Posts
Year: 1987
Engine: Check
Pic is toe out.
Use the adjuster sleeve to shorten your tie rod.
Measure the distance between your rear wheels. Use the same points on the front wheels, then adjust the tie rod to be he correct length to keep the front tires the same distance apart as the rear.
Use the adjuster sleeve to shorten your tie rod.
Measure the distance between your rear wheels. Use the same points on the front wheels, then adjust the tie rod to be he correct length to keep the front tires the same distance apart as the rear.
#4
CF Veteran
Join Date: Aug 2012
Location: oregon
Posts: 1,592
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1993
Model: Cherokee
Engine: 4.0 ho 99 intake ps pump 1" tb spacer 62mm bored tb eletric fans and more
did you check your drag link also to make sure it wassnt bent at all?
#5
CF Veteran
Join Date: Feb 2010
Location: Missoula, MT
Posts: 3,353
Likes: 0
Received 1 Like
on
1 Post
Year: 1999
Model: Cherokee
Engine: Golen 4.6 Stroker, AFE Headers, 62mm TB, 24 LB Injectors, Brown Dog kit, HF Cat, 3" Exhaust
Here ya go man. Plenty of great info in there.
http://jeep-xj.info/HowtoAlignment.htm
I use thumb-tacks in the tread to make sure I am measuring from the same spot everytime.
http://jeep-xj.info/HowtoAlignment.htm
I use thumb-tacks in the tread to make sure I am measuring from the same spot everytime.
#7
CF Veteran
Join Date: Aug 2012
Location: oregon
Posts: 1,592
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1993
Model: Cherokee
Engine: 4.0 ho 99 intake ps pump 1" tb spacer 62mm bored tb eletric fans and more
this is true but after seeing my brother bend his i alway sugest taking a second to look never hurt anyone.
Trending Topics
#8
CF Veteran
Join Date: Sep 2010
Location: Milwaukee, WI
Posts: 21,168
Likes: 0
Received 5 Likes
on
5 Posts
Year: 1987
Engine: Check
Very true! Never hurts to check!
My wife was driving her TJ and got smacked right on the rim, smileyed up her tie rod really bad, but her drag link was fine.
I went right with the V8 zj stuff.
My wife was driving her TJ and got smacked right on the rim, smileyed up her tie rod really bad, but her drag link was fine.
I went right with the V8 zj stuff.
