It can't be this hard

Trying o do a speedometer gear correction on a 2001 XJ. Chart shows I need a 30 tooth yellow gear. No problem, order one up. Install the gear and nothing. Re install the factory gear and it works.
This is he short shaft gear. Everything clicked in like it should. What am I missing. Looking the the 2 gears side by side it looks like the teeth are opposite. Any thoughts?

Jun 2, 2024 | 02:59 PM

That Jeep Guy XJMJ

CF Veteran

Joined: Jun 2009

Posts: 2,609

Likes: 446

From: Michigan

Year: 1987 MJ, 1973 J2000, 1986 XJ, 08 JK

Model: Comanche (MJ)

Engine: 4.0L H.O

Potentially the new gear wasn't engaging the tone ring on the output shaft?

If your installing both gears with the retaining tab in the same notches then your prolly onto something regarding not being clocked correctly.

Jun 4, 2024 | 07:33 AM

MrTodd

Member

Joined: May 2021

Posts: 136

Likes: 50

From: San Antonio, Texas

Year: 1999

Model: Cherokee (XJ)

Engine: 4.0L

See this video around the 1:20 mark. Other than having backward teeth, this could be your trouble.

Todd

Last edited by MrTodd; Jun 4, 2024 at 07:34 AM. Reason: time correctiom

Jun 4, 2024 | 08:39 PM

Checkedout

Thread Starter

Junior Member

Joined: Jul 2023

Posts: 36

Likes: 25

From: Fort Lupton CO

Year: 2001

Model: Cherokee (XJ)

Engine: 4.0L

Mr. Todd for the win. Learned something. There are several ways to index the pick up depending on the gear size. Match up the correct range and install. Rotate to line up the bolt and a way ya go.
Thanks for the help.
