XJ Lift/Tire Setup thread
Newbie
Joined: Jan 2010
Posts: 4
Likes: 0
From: Toronto, Ontario
Year: 1989
Model: Cherokee
Engine: 4.0L
RC 3in series 2 lift with 31 bfg a/t... installing 1.5 lift blocks and 3/4in coil spacers and t case drop. also jks hd brake lines as soon as they arrive
Last edited by Cory88; Nov 14, 2010 at 12:28 PM. Reason: 1 more pic
Newbie
Joined: Mar 2010
Posts: 12
Likes: 0
Model: Cherokee
2000 Jeep Cherokee Classic
At the time of picture...
No Lift.
BW Flat Flares
15x10 Cragars w/ 3.75" BS
33x12.50-15 GY Duratracs
In case it isn't apparent, the front right tire is parked on a cynder block under the leaves, the rear drivers side tire is NOT touching the fender flare but it is close. I don't know why but I didn't take any pictures of it on level ground and I have since then installed the 2" front coil spacers and I will be installing new HD rear springs with my clayton shackles sometime between tomorrow and sunday.
At the time of picture...
No Lift.
BW Flat Flares
15x10 Cragars w/ 3.75" BS
33x12.50-15 GY Duratracs
In case it isn't apparent, the front right tire is parked on a cynder block under the leaves, the rear drivers side tire is NOT touching the fender flare but it is close. I don't know why but I didn't take any pictures of it on level ground and I have since then installed the 2" front coil spacers and I will be installing new HD rear springs with my clayton shackles sometime between tomorrow and sunday.
Last edited by Metzroth; Dec 1, 2010 at 11:59 AM.
Senior Member
Joined: Nov 2010
Posts: 976
Likes: 5
From: Cloquet, MN
Year: 2000 Ltd.
Model: Cherokee
Engine: 4.0L I6
As promised... Stock height with fresh 225/75-16s. You can see why I'm looking at new springs.
Last edited by Northwoods Snowman; Dec 8, 2010 at 09:01 PM.
CF Veteran
Joined: Jul 2008
Posts: 2,328
Likes: 1
From: Minnesota
Year: 1999
Model: Cherokee
Engine: 4.0
ive been through 3 lift setups, ill try to include all the parts on them from the top of my head
completely bone freakin stock
first setup: RC 4.5" lift - 4.5" coils, 3" full packs, 1.5" shackle, RC nitro shocks, fixed LCAs, stock trac bar drilled 3/4" over, stock steering - 33" procomp xtremes on 15x7 canyons on topline wheel spacers
2nd setup - mix 6.5" lift - 4.5" coils, 2" BB spacers, 5.5" IRO leaf packs, 1.5" shackle, doetsch tech 8000 pre-runner shocks front, still RC shocks rear, IRO OTK 5/8" upgrade hardware steering, IRO HD trac bar, IRO long arms - 35x12.5" KM2s on 15x8 chrome soft 8s
3rd setup - IRO 8.5" lift - IRO 8.5" coils, IRO 5.5" full packs w/ 2.5" AAL, 1.5" shackle, IRO OTK steering, IRO HD tracbar, IRO AA tabs, doetsch tech 8000 prerunner shocks front and rear, IRO long arms, 35x12.5" KM2s on 15x10 black soft 8s
ive got more pics if you need any..flex shots, wheeling shots, etc.
completely bone freakin stock
first setup: RC 4.5" lift - 4.5" coils, 3" full packs, 1.5" shackle, RC nitro shocks, fixed LCAs, stock trac bar drilled 3/4" over, stock steering - 33" procomp xtremes on 15x7 canyons on topline wheel spacers
2nd setup - mix 6.5" lift - 4.5" coils, 2" BB spacers, 5.5" IRO leaf packs, 1.5" shackle, doetsch tech 8000 pre-runner shocks front, still RC shocks rear, IRO OTK 5/8" upgrade hardware steering, IRO HD trac bar, IRO long arms - 35x12.5" KM2s on 15x8 chrome soft 8s
3rd setup - IRO 8.5" lift - IRO 8.5" coils, IRO 5.5" full packs w/ 2.5" AAL, 1.5" shackle, IRO OTK steering, IRO HD tracbar, IRO AA tabs, doetsch tech 8000 prerunner shocks front and rear, IRO long arms, 35x12.5" KM2s on 15x10 black soft 8s
ive got more pics if you need any..flex shots, wheeling shots, etc.
