Gas tank skidplate mount
I went to the junkyard today and stumbled across a jeep with gas tank, and T case skids. I'm pretty sure the T case skid just bolts right up, but I don't think my frame rails have the same threaded holes that the gas tank skid was originally bolted to. Should I drill and tap? Weld some bolt/studs to my frame rails and use nuts to fasten the skidplate? Has anyone else run into this problem?
Any and all advice welcomed, truly.
Thanks
Any and all advice welcomed, truly.
Thanks
#6
CF Veteran
Join Date: Dec 2008
Location: eaton ohio
Posts: 1,533
Likes: 0
Received 0 Likes
on
0 Posts
Year: 93
Model: Cherokee
Engine: 4.0
dont do any of the fore mentioned crap, do it the right way, if i recall correctly the stock gas tank skids mount on the uniboy as if you were to bolt up a hitch, and to do so they used nut strips that fit inside the unibody rails, on the nut strips are obvioulsy nuts that are welded on and just you just run bolts thru the holes in the skid and into the nutstrip and there you go it wont rip off when you hit it off of something
#7
Seasoned Member
Join Date: May 2009
Location: Pittsburgh, PA
Posts: 473
Likes: 0
Received 1 Like
on
1 Post
Year: 1990
Model: Comanche (MJ)
Engine: 4.0L
dont do any of the fore mentioned crap, do it the right way, if i recall correctly the stock gas tank skids mount on the uniboy as if you were to bolt up a hitch, and to do so they used nut strips that fit inside the unibody rails, on the nut strips are obvioulsy nuts that are welded on and just you just run bolts thru the holes in the skid and into the nutstrip and there you go it wont rip off when you hit it off of something
Trending Topics
#10
CF Veteran
Join Date: Dec 2008
Location: eaton ohio
Posts: 1,533
Likes: 0
Received 0 Likes
on
0 Posts
Year: 93
Model: Cherokee
Engine: 4.0
#11
CF Veteran
Join Date: Aug 2008
Location: Hollidaysburg, PA
Posts: 5,603
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1990
Model: Cherokee
Engine: 4.0 lt. 242 cu.in.
#12
CF Veteran
Join Date: Jul 2009
Location: New Jersey (Milltown, Lavallette, and Wayne)
Posts: 2,245
Likes: 0
Received 1 Like
on
1 Post
Year: 1999
Model: Cherokee
Engine: 4.0L I6
You don't need the nut strips if you put the bolts in the frame and then tighten them by having a long wrench through the frame like I did. You just gotta pull the bumper off to do either method. I did mine the same time I did my hitch so it's held up there with grade 8s. Good luck
#13
Junior Member
Thread Starter
Join Date: Mar 2009
Posts: 52
Likes: 0
Received 0 Likes
on
0 Posts
Model: Cherokee
I thought this one was dead. I didn't like the self-tappers either contrary to what I wrote. I still haven't got around to doing anything with the skids since I've been fixing problem after problem to get the brakes and 4wd working right. The nut strips sound like the answer I was looking for. Are these available on an offroad website somewhere or should I just get some flat stock and make them myself?
#14
CF Veteran
Join Date: Jul 2009
Location: New Jersey (Milltown, Lavallette, and Wayne)
Posts: 2,245
Likes: 0
Received 1 Like
on
1 Post
Year: 1999
Model: Cherokee
Engine: 4.0L I6
I thought this one was dead. I didn't like the self-tappers either contrary to what I wrote. I still haven't got around to doing anything with the skids since I've been fixing problem after problem to get the brakes and 4wd working right. The nut strips sound like the answer I was looking for. Are these available on an offroad website somewhere or should I just get some flat stock and make them myself?
#15
Seasoned Member
Join Date: May 2009
Location: Pittsburgh, PA
Posts: 473
Likes: 0
Received 1 Like
on
1 Post
Year: 1990
Model: Comanche (MJ)
Engine: 4.0L
I thought this one was dead. I didn't like the self-tappers either contrary to what I wrote. I still haven't got around to doing anything with the skids since I've been fixing problem after problem to get the brakes and 4wd working right. The nut strips sound like the answer I was looking for. Are these available on an offroad website somewhere or should I just get some flat stock and make them myself?
