Bed Frame Rails

Old 01-14-2014, 04:03 AM
  #1
Junior Member
Thread Starter

Join Date: Apr 2013
Location: Grove, Oklahoma
Posts: 45
Year: 1994
Model: Cherokee
Engine: 4.0l Inline 6
Default Bed Frame Rails

Hey there Cherokeeforum, long time listener first time caller... I have a question pertaining to the use of bed frame rails for a roof rack I've thought up. I'm a landlord and over the years have amassed a wonderful amount of bed frames. It's a fairly simple design and I think they will be light enough, has anyone ever tried to do this or is there a reason people don't do this? Thanks in advance. Chris
wrestler74354 is offline
Old 01-14-2014, 05:26 AM
  #2
Junior Member
Thread Starter

Join Date: Apr 2013
Location: Grove, Oklahoma
Posts: 45
Year: 1994
Model: Cherokee
Engine: 4.0l Inline 6
Default

Should definitely read stickies before posting. I'm such a newb. Sorry admin.
wrestler74354 is offline
Old 01-16-2014, 07:24 PM
  #3
CF Veteran

jeepsurfer1's Avatar

Join Date: May 2011
Location: va
Posts: 2,516
Year: 1996
Model: Cherokee
Engine: i-6 4.0
Default

It should work buddy
jeepsurfer1 is offline
Old 01-16-2014, 07:48 PM
  #4
CF Veteran

xjfirefighter's Avatar

Join Date: Jan 2011
Location: Rochester
Posts: 1,021
Year: 2001
Model: Cherokee
Engine: 4.0
Default

A lot of people use them. Just make sure you grind the metal until it's shiny so you can get some good welds on it
xjfirefighter is offline
Old 01-18-2014, 06:09 AM
  #5
Junior Member
Thread Starter

Join Date: Apr 2013
Location: Grove, Oklahoma
Posts: 45
Year: 1994
Model: Cherokee
Engine: 4.0l Inline 6
Default

Originally Posted by xjfirefighter View Post
A lot of people use them. Just make sure you grind the metal until it's shiny so you can get some good welds on it
Thanks for the tip! Have the metal cut and ground the paint off with a steel wheel and a jig built. Just waiting to weld, it's too cold outside and my shop doesn't hav eheat lol.
wrestler74354 is offline
Old 01-21-2014, 06:27 AM
  #6
Junior Member
Thread Starter

Join Date: Apr 2013
Location: Grove, Oklahoma
Posts: 45
Year: 1994
Model: Cherokee
Engine: 4.0l Inline 6
Default

Well it turned out to be a real PITA to get this all done. The bed frame rails were all warped. I think I did a pretty good job for a first time welder. I did learn with enough time, enough grinding, and enough Jack even a guy like me can make a decent weld! It's all done now, just need to put the expanded metal floor on then mount it to the XJ.

Name:  IMG_20140118_100359_zpsf39500c1.jpg
Views: 82
Size:  83.4 KB
Name:  IMG_20140119_144806_zpseeadc955.jpg
Views: 76
Size:  195.3 KB
Name:  IMG_20061231_180658_zpsf964e574.jpg
Views: 61
Size:  55.6 KB
wrestler74354 is offline
Old 01-26-2014, 12:12 PM
  #7
Newbie

Join Date: Jan 2014
Posts: 4
Model: Cherokee
Default

It good to have a rack in the roof so you could have more passengers inside and stuffs outside
osiel_salazar is offline
Old 01-31-2014, 05:38 PM
  #8
Junior Member

Join Date: Jun 2010
Location: Nova Scotia, Canada
Posts: 41
Year: 1996
Model: Cherokee
Engine: 4.0
Default

A word of caution regarding bed frame rails: I've made many things from bed rails, from roof racks to trailer sides, and have lots of experience with them. They're great (and a free source of angle iron, you can usually find them by the curb on garbage day), but they do have their weaknesses. The steel they are made of is very hard, and quite brittle. You will need high quality drill bits (Cobalt) to drill through them, and they may break or crack at the welds.

That being said, nice rack
Just4Kixx is offline
Old 02-01-2014, 11:21 AM
  #9
Junior Member
Thread Starter

Join Date: Apr 2013
Location: Grove, Oklahoma
Posts: 45
Year: 1994
Model: Cherokee
Engine: 4.0l Inline 6
Default

Originally Posted by Just4Kixx View Post
A word of caution regarding bed frame rails: I've made many things from bed rails, from roof racks to trailer sides, and have lots of experience with them. They're great (and a free source of angle iron, you can usually find them by the curb on garbage day), but they do have their weaknesses. The steel they are made of is very hard, and quite brittle. You will need high quality drill bits (Cobalt) to drill through them, and they may break or crack at the welds.

That being said, nice rack
Thanks! I appreciate the warning but you are a little too late LOL. I dulled out 4 bits, and that was just drilling the holes in the brackets.

Name:  IMG_20140122_091327_zpsc9ed5091.jpg
Views: 58
Size:  104.4 KB

Name:  IMG_20140122_171829_zps5a550c38.jpg
Views: 47
Size:  100.7 KB

Here's the finished product, I just primered and painted it. Rustoleum Satin Black to match the bumpers and trim.
wrestler74354 is offline
Old 02-09-2015, 05:35 PM
  #10
Member

Bishop75's Avatar

Join Date: Nov 2011
Posts: 195
Default

Your lucky if all you did was dull the bits. I killed 10 before I got my roof rack done.
Attached Thumbnails Bed Frame Rails-image-2547272274.jpg   Bed Frame Rails-image-279863517.jpg   Bed Frame Rails-image-3454059588.jpg

Last edited by Bishop75; 02-09-2015 at 05:39 PM.
Bishop75 is offline
