This is a very dumb question for you jeep guys, this my first jeep ( 98 I6) and I've worked on suspension before, just not this kind, so not a complete noob. How do I remove the springs? I know I need to disconnect steering shocks sways but how do drop the axle? Unhook just top arm or lower, both? I just don't want to do more then I really needed to
Last edited by morando6784; 03-24-2011 at 09:45 AM.
#2
CF Veteran
Join Date: Feb 2010
Location: Oroville, CA
Posts: 12,367
Likes: 0
Received 19 Likes
on
18 Posts
Year: 1995
Model: Grand Cherokee
Engine: 4.0 with all of the noise and clatter
The lowers will bind up in the bracket at the axle and not aloow the axle to dropfar enough, so mark the position of the cam bolts and take the lower arms loose from the axle. Also be careful not to damage the brake hoses and ABS sensor wires.
#3
CF Veteran
Join Date: Mar 2009
Location: Visalia, Kalifornia, ussa
Posts: 2,750
Likes: 0
Received 2 Likes
on
2 Posts
Year: 1996
Model: Cherokee
Engine: 4.0
To remove the pring, you need to disconect the Swaybar and shocks, thats IT. The axel should drop enough for removal. You may need to disconect the trackbar if you can't get enough droop. I never have, I use a jack to push the axel downward. If you do unbolt the trackbar or control arms, do it at the axel, not the body ends.
#4
CF Veteran
Join Date: Feb 2010
Location: Oroville, CA
Posts: 12,367
Likes: 0
Received 19 Likes
on
18 Posts
Year: 1995
Model: Grand Cherokee
Engine: 4.0 with all of the noise and clatter
Why are you removing the springs? Replacing or adding a spacer? Pulling the stock spring is a breeze, but installing longer springs or installing the spring after puting a spacer in can be kind of tricky.
#6
CF Veteran
Join Date: Feb 2010
Location: Oroville, CA
Posts: 12,367
Likes: 0
Received 19 Likes
on
18 Posts
Year: 1995
Model: Grand Cherokee
Engine: 4.0 with all of the noise and clatter
If you take the lower arms loose at the axle, it will drop enough to get the spring in without a compressor. It's only two bolts.
Trending Topics
#9
Member
Thread Starter
Join Date: Oct 2010
Posts: 226
Likes: 0
Received 0 Likes
on
0 Posts
Model: Cherokee
Ok thanks guys, it shouldn't take me to long seems pretty simple to me, and seeing that the front axle was just put in it should come right back apart with hardly any fight
#10
Seasoned Member
Join Date: Mar 2010
Location: South Dakota
Posts: 262
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1995
Model: Cherokee
Engine: 4.0
Don't know why you need to remove lca. I put in 3" lift coils and did not have a problem. Just took off the sway bar brackets and removed shocks after you remove the shocks jack up the end of the axle opposite the one you want to remove the spring from so it lowers the side you want removed and take off the stock spring.
If spring isn't stock you might need a spring compressor which you can rent from a local parts store. If you don't want to compress the spring then I guess you can remove the lca but it's unnecessary for a small lift or stock replacement and much easier just to leave it on.
Just my .02. Hope this helps.
If spring isn't stock you might need a spring compressor which you can rent from a local parts store. If you don't want to compress the spring then I guess you can remove the lca but it's unnecessary for a small lift or stock replacement and much easier just to leave it on.
Just my .02. Hope this helps.
#12
CF Veteran
Join Date: Feb 2010
Location: Oroville, CA
Posts: 12,367
Likes: 0
Received 19 Likes
on
18 Posts
Year: 1995
Model: Grand Cherokee
Engine: 4.0 with all of the noise and clatter
I had to remove the lower arms when I pulled the spacers out of my rig, the bracket on the axle limited my downword travel. You can try and do it without dropping the arms, nothing to lose.
