Default de-broifacation of the brodozer...

since my newly acquired xj seems to fit the name, figured it would make a good title for my rebuild thread lol

if you may not have seen it yet i posted about it in the intro section.

https://www.cherokeeforum.com/f8/new-guy-az-222894/

apparently this jeeps been tossed around the frat, and the last bro added the finishing touches of douche before it made its way to my driveway. 20's, huge annoying (somewhat offending) stickers, "eyelid" paint on the headlights, over-spray bomb job even my 9 month old would cringe at, you name it it was done. but there is some good stuff, ill list the current specs:

96 xj 2 door

6 point cage
comp cut rear

4.7 stroker with bolt ons (according to PO. im not sure on the size stroker, but its got 24# ford injectors has PLENTY of ***** to roast 37s)
brown dog motor mounts
tripple electric fans with a brand new champion aluminium rad (done by me)
ax15 and np231 with sye
boostwerks t case linkage (done by me)
hand throttle made from a bicycle brake lol
heim draglink and i think a stock f350 tie rod?
89 ford kingpin dana 60 front axle, 4.10 gears, welded diff, warn locking hubs, stock 30 spline shafts
72 dodge dana 60 rear, 4.10s, also welded (assuming stock shafts)
full rubicon 7.5 extreme duty long arm kit
RE shocks
the RE coil springs replaced with rustys 8.5-9 inchers

super worn 37x12.5r20 km2s on brodawg 20s

heres some pics

before the de-broification began

Name:  IMG_20160213_174701002_HDR.jpg
Views: 603
Size:  257.2 KB

removed most of the stickers and wrenched on it for a good month. repaired/replaced all the hack job wiring. almost every bolt you wouldnt want loose, was or was stripped. replaced the dizzy since someone had torqued the bolt down on the locating tab vs the hold down clamp... replaced the radiator and missing 3rd electric fan. put all the fans on relays vs STRAIGHT OFF THE BATTERY.. cleaned up a lot of other odds and ends

Name:  IMG_20160225_184012999_HDR.jpg
Views: 752
Size:  182.6 KB

finally had a chance to take it out. didnt do an serious wheeling, just a fun cruise though the desert with the chick. overall it went well and i found out itll cruise at 80 on the freeway with no problems

Name:  IMG_20160312_113454716.jpg
Views: 408
Size:  379.9 KB

Name:  IMG_20160312_113342978_HDR.jpg
Views: 392
Size:  391.6 KB

Name:  IMG_20160312_113326977_HDR.jpg
Views: 416
Size:  315.8 KB

Name:  FB_IMG_1458005137437.jpg
Views: 417
Size:  81.0 KB

Name:  FB_IMG_1458005150284.jpg
Views: 392
Size:  83.6 KB


turns out the water crossing wasnt such a good idea. got home and the dreaded milkshake was oozing from the pass side axle tube.

Name:  IMG_20160319_140214369_HDR.jpg
Views: 386
Size:  227.3 KB

sorta looks like semigloss paint lol so here it sits. gotta pull the hubs, shafts, and carrier to get to the seals. hope to have that done this week while im off.

Name:  IMG_20160320_144720392_HDR.jpg
Views: 403
Size:  230.5 KB

Name:  IMG_20160320_144746604_HDR.jpg
Views: 407
Size:  245.4 KB

future plans:

pro comp 40x13.5r17 mt2s on 17" steelies so i can weld beadlocks to em.
wheels and tires should be here within the next week
bilstien or fox shocks, still undecided
smaller springs to get teh COG down, or look into stertching the wheelbase. its squirly. then bump stop accordingly
ballistic fab 7/8" steering kit and high steer
needs a muffler lol and stereo
further sticker removal
suspension seats and harenesses
truck-lite leds
ive got some rigid cubes to mount just not sure where
new tank filler neck

Last edited by wheelsaz08; 05-21-2016 at 12:27 PM.
wheelsaz08 is offline
Old 03-22-2016, 06:58 AM
  #2
HUH? WHAT?

XJwonders's Avatar

Join Date: Jan 2013
Location: west chester, pa
Posts: 19,078
Year: 1999
Model: Cherokee(XJ)
Engine: 4.0
Default

Very nice job lol. I like the title. Ha keep it up
XJwonders is offline
Old 03-22-2016, 07:22 AM
  #3
CF Veteran

jay_sco's Avatar

Join Date: Dec 2011
Location: IE (SoCal)
Posts: 1,080
Year: 1994 SE
Model: Cherokee
Engine: 4.0
Default

Sounds like a solid plan, looking forward to updates. I like the title too, no more mall duty for this rig!!
jay_sco is offline
Old 03-22-2016, 07:25 AM
  #4
Junior Member

Lowrange2's Avatar

Join Date: May 2008
Location: +34 25' 35.67", -81 21' 12.04"
Posts: 15,016
Year: 1993
Engine: 4.0
Default

I was going to say that you just need to lower it 4 inches and toss on some bigger tires.
Lowrange2 is offline
Old 03-22-2016, 08:22 AM
  #5
TIME TO GET SCHWIFTY

roninofako's Avatar

Join Date: Feb 2011
Location: Apple Valley, CA
Posts: 13,074
Year: 97
Model: Cherokee
Engine: 4.6 stroker
Default

You're doing God's work, son...LMAO

I approve. Thanks for saving that abomination, and giving it a good home.
roninofako is offline
Old 03-23-2016, 03:48 PM
  #6
Senior Member

Alpha 1-4's Avatar

Join Date: Mar 2013
Posts: 655
Model: Cherokee
Default

Originally Posted by wheelsaz08 View Post

turns out the water crossing wasnt such a good idea. got home and the dreaded milkshake was oozing from the pass side axle tube.


That carrier looks like an abused sorority girl. The "Bros" did a number on it.
Is that daylight coming through from the pinion?
Alpha 1-4 is offline
Old 03-25-2016, 08:33 AM
  #7
Member
Thread Starter

Join Date: Mar 2016
Location: Tempe, AZ
Posts: 113
Year: 1989
Model: Comanche
Engine: 4.7 stroker
Default

Originally Posted by Alpha 1-4 View Post
That carrier looks like an abused sorority girl. The "Bros" did a number on it.
Is that daylight coming through from the pinion?
yeah the pinion and carrier were real "close" friends at one time. the shiny spot is part of the completely flattened crush sleeve

thanks for all the replies everyone! progress probably wont be as quick as id like but heres the broific update

as you can see, the front axle was full of brosomeness. the pinion ground its way into the carrier, the crush sleeve is well, crushed flat lol and turns out its just got stock dana/spicer 4.10s!!! i could have sworn the gearing felt a lot deeper than that.. oh well now im definitely thinking its got a stroker and just means i get to upgrade. either 5.13 or 5.38 to help get the 40s turnin. oh and the shafts are stock 30 splines so we'll see how long those hold up as well

the spindles, kingpins, u joints, and all bearings checked out ok so for the time being i just cleaned everything up, put new axle seals in and slapped the used and abused carrier back in. probably wasnt the best idea, but this jeeps full of that already

random pictures

Name:  IMG_20160322_161531243.jpg
Views: 390
Size:  250.6 KB

Name:  IMG_20160322_162157535_HDR.jpg
Views: 382
Size:  324.5 KB

chewy chewy
Name:  IMG_20160322_170543392_HDR.jpg
Views: 384
Size:  320.8 KB

thats where the rest of the carrier went
Name:  IMG_20160322_170535123_HDR.jpg
Views: 382
Size:  283.2 KB

pass side bad seal

Name:  IMG_20160322_170603644_HDR.jpg
Views: 393
Size:  237.0 KB

driver seal

Name:  IMG_20160322_170616208_HDR.jpg
Views: 380
Size:  205.0 KB

rear gears with brotastic over spray

Name:  IMG_20160323_154716982_HDR.jpg
Views: 392
Size:  231.4 KB

warn hubs cleaned up

Name:  IMG_20160321_234619747_HDR.jpg
Views: 381
Size:  243.5 KB

random engine bay shots and interior pic (need to fab up a battery tie down)

Name:  IMG_20160322_171045953_HDR.jpg
Views: 389
Size:  261.2 KB

Name:  IMG_20160322_171108885.jpg
Views: 391
Size:  222.2 KB

Name:  IMG_20160322_171038973.jpg
Views: 396
Size:  273.7 KB

Name:  IMG_20160322_171018070_HDR.jpg
Views: 391
Size:  217.9 KB



still need to put the diff covers back on and fill em up with fluid. then wait for my 40s and high steer to show up

Last edited by wheelsaz08; 03-25-2016 at 08:51 AM.
wheelsaz08 is offline
Old 03-25-2016, 09:24 AM
  #8
CF Veteran

gpXJ's Avatar

Join Date: Sep 2009
Location: Grand Prairie, Texas
Posts: 1,142
Year: 1998
Model: Cherokee
Engine: 4.0 HO I6
Default

I like how it's comp cut, but then lifted so freakin high there is no way the tire even gets close to the original fender location, much less the newly clearanced comp fender. Get that thing down a good 4 inches at least.

I approve of your efforts to save this one from going the way of the brodo bird!
gpXJ is offline
Old 03-25-2016, 10:15 AM
  #9
Member
Thread Starter

Join Date: Mar 2016
Location: Tempe, AZ
Posts: 113
Year: 1989
Model: Comanche
Engine: 4.7 stroker
Default

thats the plan along with stretching the rear a good 4-5 inches. just waiting on time and money lol

Last edited by wheelsaz08; 04-18-2016 at 12:20 AM.
wheelsaz08 is offline
Old 03-29-2016, 09:11 PM
  #10
Member
Thread Starter

Join Date: Mar 2016
Location: Tempe, AZ
Posts: 113
Year: 1989
Model: Comanche
Engine: 4.7 stroker
Default slightly less brotastic

well, i was bored after topping off the diffs so did some more un-broing. i painted the covers black, scrapped as much of the paint off the headlights as i could, and ditched the front bumper. and then 40s showed up.

mmmeats

Name:  IMG_20160328_123920671.jpg
Views: 384
Size:  171.6 KB

and some more parts

beef

Name:  IMG_20160328_153231052_HDR.jpg
Views: 381
Size:  211.4 KB

ballistic fab 2 inch spacers, high steer arms and hardware, 7/8 rod ends, 3/4 misalignment spacers, and a koozie! the tubing for the steering linkages will be here later this week.

i couldnt help but throw the wheels and tires on

fronts, 40s make the trashed 37s look tiny

Name:  IMG_20160328_125520572.jpg
Views: 468
Size:  153.1 KB

Name:  IMG_20160328_125604250.jpg
Views: 391
Size:  140.4 KB

40s all the way around (pre spacers) also ignore the lines i drew on the rear of the fender lol but i am thinking of cutting the front more

Name:  IMG_20160328_145836843_HDR.jpg
Views: 417
Size:  175.8 KB

rear before spacers
