1 ton XJ 40's
#17
Senior Member
Thread Starter
Join Date: Mar 2011
Location: New Haven, IN
Posts: 956
Likes: 0
Received 1 Like
on
1 Post
Year: 1998
Model: Cherokee
Engine: 4.0L
Don't update this much..
Well here are the plans..
Front
KP HP60
5.38 gears
Grizzly locker
Riddler diff cover
Warn Premium lockout hubs
LII high steer arms
1.5" tie rod/drag link
Ruffstuff heims
Kingpin rebuild, spindle rebuild, new calipers, rotors, and pads, new bearings seals
Sandblasted and powder coated black
REAR
FF60
5.38 gears
Grizzly locker
Riddler diff cover
3/4 ton Chevy disc brakes
Ruffstuff disc brake brackets
New bearings seals
Suspension
RE 5.5" coils
1/2 ton Chevy main on RC 4.5" leaf pack
Bilstein 5100's
JKS boomerang shackles
Shackle relocation brackets
Custom longarms and crossmember
Wheels/Tires
39.5x13.5r16 Irok Bias
16x10 4" bs Pro Comp 51 Series
Misc
TNT front bumper
2x5 rock rails with 1.5 tube
No rear bumper yet but think about going with Hudfab
JCR 1/4 panel guards with taillights
Cage is in the works, possibly hybrid or just in internal. I dont like exo's
Unibody getting plated but not sure if i'll buy ruffstuff or just have a local guy make something up
Not sure if im going to relocate the gas tank yet.. We'll see once i get the tires under it. If so i'll probably use a fuel cell
I think thats it for now.. it's all coming along just waiting for parts.. I'll get some pics up here soon..
Well here are the plans..
Front
KP HP60
5.38 gears
Grizzly locker
Riddler diff cover
Warn Premium lockout hubs
LII high steer arms
1.5" tie rod/drag link
Ruffstuff heims
Kingpin rebuild, spindle rebuild, new calipers, rotors, and pads, new bearings seals
Sandblasted and powder coated black
REAR
FF60
5.38 gears
Grizzly locker
Riddler diff cover
3/4 ton Chevy disc brakes
Ruffstuff disc brake brackets
New bearings seals
Suspension
RE 5.5" coils
1/2 ton Chevy main on RC 4.5" leaf pack
Bilstein 5100's
JKS boomerang shackles
Shackle relocation brackets
Custom longarms and crossmember
Wheels/Tires
39.5x13.5r16 Irok Bias
16x10 4" bs Pro Comp 51 Series
Misc
TNT front bumper
2x5 rock rails with 1.5 tube
No rear bumper yet but think about going with Hudfab
JCR 1/4 panel guards with taillights
Cage is in the works, possibly hybrid or just in internal. I dont like exo's
Unibody getting plated but not sure if i'll buy ruffstuff or just have a local guy make something up
Not sure if im going to relocate the gas tank yet.. We'll see once i get the tires under it. If so i'll probably use a fuel cell
I think thats it for now.. it's all coming along just waiting for parts.. I'll get some pics up here soon..
Last edited by Nickell586; 02-20-2012 at 11:35 PM.
#19
CF Veteran
Join Date: Nov 2011
Location: Nashville
Posts: 2,752
Likes: 0
Received 0 Likes
on
0 Posts
Year: 2001
Model: Cherokee
Engine: 4.0
Lookin good. How are the bilsteins holding up? I am considering ditching the DT's 8000's already. They are much stiffer than I was expecting.
#20
Senior Member
Thread Starter
Join Date: Mar 2011
Location: New Haven, IN
Posts: 956
Likes: 0
Received 1 Like
on
1 Post
Year: 1998
Model: Cherokee
Engine: 4.0L
Thanks man. Great. So much better than I thought they would be. pretty soft. I ordered then through iro they were the cheapest I found. They were only like 300 shipped.
#21
CF Veteran
Join Date: Nov 2011
Location: Nashville
Posts: 2,752
Likes: 0
Received 0 Likes
on
0 Posts
Year: 2001
Model: Cherokee
Engine: 4.0
Good to know. When im ready ill def check out the iro price. Btw subscribed. Will be interesting to see you knock out that wild list.
#22
Senior Member
Thread Starter
Join Date: Mar 2011
Location: New Haven, IN
Posts: 956
Likes: 0
Received 1 Like
on
1 Post
Year: 1998
Model: Cherokee
Engine: 4.0L
Already in the process so it should be done by next week i'm hoping. Already have all the parts ordered or in the garage.
Last edited by Nickell586; 02-20-2012 at 11:36 PM.
#25
Senior Member
Thread Starter
Join Date: Mar 2011
Location: New Haven, IN
Posts: 956
Likes: 0
Received 1 Like
on
1 Post
Year: 1998
Model: Cherokee
Engine: 4.0L
Yeah i can't wait.. I can picture it all but I just want it to be done lol. I'm not going to chop it to hell like most guys do either.. I'm going to open the wheel wells a little more.. depending on how much stretch i need to stuff the tires in the rear i might relocate the gas tank or put a fuel cell back there.. i just want to keep it a full bodied cherokee and not an all out buggy.. and yes.. on 39.5" tires lol
#27
Senior Member
Thread Starter
Join Date: Mar 2011
Location: New Haven, IN
Posts: 956
Likes: 0
Received 1 Like
on
1 Post
Year: 1998
Model: Cherokee
Engine: 4.0L
its all flat black rattle can.. then up to the body line is bedliner.. and the hood.. ill probably re do it this summer.. holds up pretty well on the trails though.. which is the main reason i did it.
#29
Senior Member
Thread Starter
Join Date: Mar 2011
Location: New Haven, IN
Posts: 956
Likes: 0
Received 1 Like
on
1 Post
Year: 1998
Model: Cherokee
Engine: 4.0L
i just used a couple sanding blocks.. i scuffed the paint pretty good.. then went over it with the fine block.. i didnt put a whole lot of time into it.. thats why im redoing it.. 3 coats of flat paint and 2 coats of duplicolor bedliner
