Heater doesnt work
01-14-2012, 04:33 PM
#1
Member
Thread Starter
Join Date: Jan 2011
Location: Big Lake, Alaska
Posts: 181
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1996
Model: Cherokee
Engine: 2.5
Heater doesnt work
Nothing works!!! It was working yesterday, today nothing! I replaced the capacitor last winter. Second fan control switch last week. Selector control last spring. But now nothing, nothing from the fan at all. Ideas?
01-14-2012, 05:28 PM
#3
Member
Thread Starter
Join Date: Jan 2011
Location: Big Lake, Alaska
Posts: 181
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1996
Model: Cherokee
Engine: 2.5
Maybe, doesn't make sense, no issues with the motor ever, never even a bad noise. And damned if I can't find it under the dash.
01-14-2012, 06:12 PM
#6
Member
Thread Starter
Join Date: Jan 2011
Location: Big Lake, Alaska
Posts: 181
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1996
Model: Cherokee
Engine: 2.5
Fuses: good
Motor: runs when jumped
Resistor: looks good
Fan speed switch: just replaced
Heater controls: seems good
Can I jump between two terminals on the fan speed switch to check for an issue there? If the heater control selector switch is dead the fan will not operate either correct?
Need to figure this out, the sun is getting low in the sky and it's a bit chilly out there...
Motor: runs when jumped
Resistor: looks good
Fan speed switch: just replaced
Heater controls: seems good
Can I jump between two terminals on the fan speed switch to check for an issue there? If the heater control selector switch is dead the fan will not operate either correct?
Need to figure this out, the sun is getting low in the sky and it's a bit chilly out there...
01-14-2012, 06:13 PM
#7
CF Veteran
Join Date: Mar 2010
Location: Broward County Fl.
Posts: 47,923
Likes: 0
Received 22 Likes
on
22 Posts
Year: 1989 xj sport 2dr
Model: Cherokee
Engine: 12 hole bosch Injectors
Fuses: good
Motor: runs when jumped
Resistor: looks good
Fan speed switch: just replaced
Heater controls: seems good
Can I jump between two terminals on the fan speed switch to check for an issue there? If the heater control selector switch is dead the fan will not operate either correct?
Need to figure this out, the sun is getting low in the sky and it's a bit chilly out there...
Motor: runs when jumped
Resistor: looks good
Fan speed switch: just replaced
Heater controls: seems good
Can I jump between two terminals on the fan speed switch to check for an issue there? If the heater control selector switch is dead the fan will not operate either correct?
Need to figure this out, the sun is getting low in the sky and it's a bit chilly out there...
Trending Topics
01-14-2012, 06:30 PM
#8
Member
Thread Starter
Join Date: Jan 2011
Location: Big Lake, Alaska
Posts: 181
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1996
Model: Cherokee
Engine: 2.5
If I'm correct, the resistor would still allow the motor to operate at full speed. So that leaves the fan speed switch and heater function control. If jumping the speed selector wires merit no results than the function control is the fault... Yea? Nea?
01-15-2012, 12:33 PM
#10
Newbie
Join Date: Sep 2011
Posts: 10
Likes: 0
Received 0 Likes
on
0 Posts
Model: Cherokee
I have the same issues as you and what I have found is when jeep is running I pop the hood and shake the housing of the blower motor and is starts working. I'm not to sure if this is a grounding problem or not. But seems to work on my 97...And Hell yes is -20F here in the AK. I don't feel like fixing the problem.
01-15-2012, 04:31 PM
#12
Member
Thread Starter
Join Date: Jan 2011
Location: Big Lake, Alaska
Posts: 181
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1996
Model: Cherokee
Engine: 2.5
Fixed it!!! Holy nightmare Batman!!! Well now I got a nice new wiring harness hand made under the dash in -30 temps but she fire up and blows some lovely hot air.
02-04-2012, 11:38 PM
#13
Newbie
Join Date: Oct 2011
Location: Gurnee, Illinois
Posts: 18
Likes: 0
Received 0 Likes
on
0 Posts
Year: 2001
Model: Cherokee
Engine: 4.0L I6
what part of the wiring did you have to replace? im having the same problem you did and the motor works when jumped, brand new resistor, the switches are fine (nothing melted). im thinking its a loose plug or something but im not sure. im about to set the turn on fire to get heat while i drive!!!!
