Default Header Panel

Quadratec offers an OMIX-ADA header panel for "91-96 Jeep Cherokee XJ". When I asked what the difference was between this and a pre-'91 header panel they responded:

Hello,

You asked the following question regarding the product "OMIX-ADA 12035.23 Header Panel for 91-96 Jeep Cherokee XJ"
https://www.quadratec.com/products/912035_23.htm

Your Question:
What is the difference between this and the pre-91 header?

Our Answer:
They have completely different shapes. Please see the following: https://www.quadratec.com/sites/default/files/styles/product_zoomed/publ... https://www.quadratec.com/sites/default/files/styles/product_zoomed/publ...
They claim that they have "completely different shapes" and provided a link to a '97-01 header panel which, I agree, is a completely different shape but has absolutely nothing to do with my question. When I explained that the link they provided was for a '97-01 Cherokee and not a pre-'91 they stopped communicating.

Can someone here please tell me if the header panel for a '91 XJ will work on an '89 XJ.
F1Addict is offline
Old 05-14-2019, 12:53 PM
  #2
CF Veteran

Join Date: Dec 2015
Location: PA
Posts: 1,905
Year: 1997
Model: Cherokee
Engine: 4.0L
Default

I think the grille was different at some point, but the rest remained the same. I think.
fb97xj1 is offline
Old 05-14-2019, 04:03 PM
  #3
Senior Member

Join Date: Jan 2017
Location: Connecticut
Posts: 684
Year: 2000
Model: Cherokee
Engine: 4.0
Default

Dave51 is online now
Old 05-14-2019, 09:13 PM
  #4
CF Veteran
Thread Starter

F1Addict's Avatar

Join Date: Nov 2011
Location: SoCal
Posts: 2,380
Year: 1989
Model: Cherokee
Engine: 4.0
Default

Originally Posted by Dave51 View Post

Yes. Thanks for finding that.

I'm still curious about the difference and/or compatibility between the pre and post-'91 header panels. My plan is to get one from my local junk yard which only occasionally has a Cherokee in stock. If I can use one from an '84 to '96 that will greatly increase my chances of finding one there.
F1Addict is offline
Old 05-15-2019, 12:22 AM
  #5
CF Veteran

Join Date: Oct 2015
Posts: 2,964
Default

I spend a lot of time researching stuff. One of the things is compatibility. Comes in handy knowing this for boneyard searches or Craigslist part outs. I need "fill in the blank" for my '00 but what other years will fit.
Part numbers. Won't tell you why it is different but I have to figure if the part for the same part is different from one year to another then it won't work.
Which is why I think you should read this:

https://www.cherokeeforum.com/f2/research-249236/
Ralph77 is offline
Old 05-15-2019, 02:37 AM
  #6
CF Veteran
Thread Starter

F1Addict's Avatar

Join Date: Nov 2011
Location: SoCal
Posts: 2,380
Year: 1989
Model: Cherokee
Engine: 4.0
Default

Originally Posted by Ralph77 View Post
I spend a lot of time researching stuff. One of the things is compatibility. Comes in handy knowing this for boneyard searches or Craigslist part outs. I need "fill in the blank" for my '00 but what other years will fit.
Part numbers. Won't tell you why it is different but I have to figure if the part for the same part is different from one year to another then it won't work.
Which is why I think you should read this:

https://www.cherokeeforum.com/f2/research-249236/
Yeah, I've read that. You would think that if the part numbers are different there would be a compatibility issue but that is rarely the case with XJ body panels. For right now it was easier to just ask those here who might have first hand experience rather than downloading every parts catalog on the internet and cross-referencing part numbers.
F1Addict is offline
Old 05-15-2019, 04:42 AM
  #7
Senior Member

Join Date: Jan 2017
Location: Connecticut
Posts: 684
Year: 2000
Model: Cherokee
Engine: 4.0
Default

Originally Posted by F1Addict View Post
I'm still curious about the difference and/or compatibility between the pre and post-'91 header panels.
It's only 95 bucks! Put some of that $$$ you're hoarding back into the economy!

Actually, they just might interchange. The only difference that is clearly known is that in 91 they went to stickum letters:

84/90 w/ Holes for Emblem Mounting 83506616
91/96 w/out Holes for Emblem Mounting 55294926
Dave51 is online now
Old 05-15-2019, 08:07 AM
  #8
::CF Moderator::

cruiser54's Avatar

Join Date: Aug 2011
Location: Prescott, Az
Posts: 37,756
Year: 1990
Model: Comanche
Engine: 4.0
Default

The headlight surrounds and top grille molding are a different configuration. Get it all for a 91 to 96 or stick with 90 and earlier header panel only.
cruiser54 is offline
Old 05-15-2019, 08:19 AM
  #9
Senior Member

Join Date: Jan 2017
Location: Connecticut
Posts: 684
Year: 2000
Model: Cherokee
Engine: 4.0
Default

Originally Posted by cruiser54 View Post
...a different configuration.
Yeah I see that now.

<90 faces left, >90 points to the right:


Dave51 is online now
Old 05-15-2019, 08:37 AM
  #10
::CF Moderator::

cruiser54's Avatar

Join Date: Aug 2011
Location: Prescott, Az
Posts: 37,756
Year: 1990
Model: Comanche
Engine: 4.0
Default

Huh?

The headlamp surrounds, marker light surrounds and upper grille moldings are different but interchangeable as assemblies with the header panel.
cruiser54 is offline
Old 05-15-2019, 09:18 AM
  #11
Member

Join Date: Sep 2017
Location: St. Louis
Posts: 135
Year: 1996
Model: Cherokee (XJ)
Engine: 4.0
Default

Originally Posted by Dave51 View Post
84/90 w/ Holes for Emblem Mounting 83506616
91/96 w/out Holes for Emblem Mounting 55294926
Explains why my new emblem I got has studs on the back of the letters haha
Spencer_P is offline
Old 05-15-2019, 09:47 AM
  #12
Senior Member

Join Date: Jan 2017
Location: Connecticut
Posts: 684
Year: 2000
Model: Cherokee
Engine: 4.0
Default

Originally Posted by cruiser54 View Post
Huh?
Dat be humor, son.
Dave51 is online now
Old 05-15-2019, 06:21 PM
  #13
::CF Moderator::

cruiser54's Avatar

Join Date: Aug 2011
Location: Prescott, Az
Posts: 37,756
Year: 1990
Model: Comanche
Engine: 4.0
Default

Originally Posted by Dave51 View Post
Dat be humor, son.

Now I get it.
cruiser54 is offline
Old 05-15-2019, 10:50 PM
  #14
CF Veteran
Thread Starter

F1Addict's Avatar

Join Date: Nov 2011
Location: SoCal
Posts: 2,380
Year: 1989
Model: Cherokee
Engine: 4.0
Default

Originally Posted by Dave51 View Post
It's only 95 bucks! Put some of that $$$ you're hoarding back into the economy!

Actually, they just might interchange. The only difference that is clearly known is that in 91 they went to stickum letters:

84/90 w/ Holes for Emblem Mounting 83506616
91/96 w/out Holes for Emblem Mounting 55294926
My XJ is Chinese enough. If given the choice between salvaging a little piece of Americana from a junkyard or contributing to an enterprising communist's new GT3RS by buying his cheap, knock-off plastic replacement part... I think you can probably discern from my previous responses which I'll choose.

Originally Posted by cruiser54 View Post
The headlight surrounds and top grille molding are a different configuration. Get it all for a 91 to 96 or stick with 90 and earlier header panel only.
I need it all. And a bumper.





F1Addict is offline
Old 05-15-2019, 11:04 PM
  #15
::CF Moderator::

cruiser54's Avatar

Join Date: Aug 2011
Location: Prescott, Az
Posts: 37,756
Year: 1990
Model: Comanche
Engine: 4.0
Default

easy then.
