Gears, gears and more gears!!!!!!!!!!!!!!
10-25-2010, 07:03 PM
#1
Member
Thread Starter
Join Date: Sep 2010
Location: duncan b.c
Posts: 223
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1992
Model: Cherokee
Engine: 4.0L h/o
Gears, gears and more gears!!!!!!!!!!!!!!
Hey , I was just wondering if a 410 gear set would fit in stock jeep howsings (d-35, d-30) and if its possible. Sorry if this has already been posted ! ima newb on this site . any suggestions would be awesome . thanks
10-25-2010, 07:22 PM
#3
CF Veteran
10-25-2010, 07:26 PM
#4
Member
Thread Starter
Join Date: Sep 2010
Location: duncan b.c
Posts: 223
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1992
Model: Cherokee
Engine: 4.0L h/o
well thats good to here! also im running 33/12.5's and i got no more bottom end should i run 410's or goo bigger like 456's ???????
Last edited by xj101; 10-25-2010 at 07:35 PM.
10-25-2010, 07:41 PM
#6
CF Veteran
10-25-2010, 07:53 PM
#7
Member
Thread Starter
Join Date: Sep 2010
Location: duncan b.c
Posts: 223
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1992
Model: Cherokee
Engine: 4.0L h/o
456's also fit in i take it , i have chromoly shafts no locker basicly stock i can just bolt 456's right in ????????????????????
Trending Topics
10-25-2010, 08:47 PM
#10
Different gear ratios require a different carrier due to the differences in ring gear thickness.
Here ya go.
Some more.
Here ya go.
Some more.
10-25-2010, 09:01 PM
#11
Seasoned Member
Join Date: Sep 2010
Location: Akron, OH
Posts: 440
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1993
Model: Cherokee
Engine: 4.0 HO
For the D30 the stock carrier case break is 3.54 and down and 3.73 and up. So if you are running stock gears and want to run 4.10 or 4.56 you are going to replace the carrier to a 3.73 and up. Sorry I dont know about the D35.
10-25-2010, 11:55 PM
#12
CF Veteran
Join Date: Feb 2010
Location: Cove, OR
Posts: 2,095
Likes: 0
Received 2 Likes
on
2 Posts
Year: 1993
Model: Cherokee
Engine: 4.0
The way to figure what rpms you will run with the different gear ratios is:
MPH x gear ratio x 336 / tire diameter x top gear ratio = RPM
example
70 x 4.88 x 336 / 33 x .75 = 2609
MPH x gear ratio x 336 / tire diameter x top gear ratio = RPM
example
70 x 4.88 x 336 / 33 x .75 = 2609
Last edited by Rock Toy; 10-25-2010 at 11:59 PM.
10-26-2010, 01:32 AM
#14
CF Veteran
Join Date: Mar 2010
Location: Broward County Fl.
Posts: 47,923
Likes: 0
Received 22 Likes
on
22 Posts
Year: 1989 xj sport 2dr
Model: Cherokee
Engine: 12 hole bosch Injectors
