Anyone know what these go to?
#1
Seasoned Member
Thread Starter
Join Date: Jul 2012
Location: Fort Worth
Posts: 417
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1999
Model: Cherokee
Engine: 4.0
Anyone know what these go to?
I cant seem to find wires that would go to these, theyre in the front passenger side of the engine bay, one set goes to the horn(single green wire) another to a plug to something that snakes under the batt tray and then these.... i cant figure out what they go to... i do know that whomever worked on this rig hooked them up to the from side marker lights.... and that was WRONG!! lol here are pics for reference.
Thanks
Thanks
#2
CF Veteran
Join Date: Sep 2009
Location: ☼ Blackhole Sun
Posts: 8,567
Likes: 0
Received 18 Likes
on
16 Posts
Year: My Jeep is a GMC
If I were you I would not "hook anything up" without a wiring diagram in hand (well maybe if I had a fire extingusher nearby). A quick google and pirate OEM manuals magically appear, try it.
#3
Seasoned Member
Thread Starter
Join Date: Jul 2012
Location: Fort Worth
Posts: 417
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1999
Model: Cherokee
Engine: 4.0
I'll look for a wiring diagram and see what i can dig up on my own as well.
Thanks, Randy
#4
CF Veteran
Join Date: Aug 2010
Location: Canton, MI
Posts: 8,357
Likes: 0
Received 82 Likes
on
67 Posts
Year: 1999
Model: Cherokee
Engine: 4.0
Appears to be for the Ambient Temperature Sensor. The Violet/Light Green tracer wire is the Temp sensor signal and the Black/Light Blue tracer wire is the sensor ground. Both wires went from the temp sensor to the overhead display.
Edit: My '99 is wired for it but I don't have an ambient temp display or the sensor. My temp sensor connector is located on the front bumper frame just below the radiator mechanical fan.
Edit: My '99 is wired for it but I don't have an ambient temp display or the sensor. My temp sensor connector is located on the front bumper frame just below the radiator mechanical fan.
Last edited by CCKen; 08-18-2012 at 09:09 PM.
