Another death wobble issue, feel like I've checked everything
#1
Junior Member
Thread Starter
Join Date: Dec 2015
Location: Indiana
Posts: 44
Likes: 0
Received 0 Likes
on
0 Posts
Year: 2000
Model: Cherokee
Engine: 4.0L I6
Another death wobble issue, feel like I've checked everything
To preface, my jeep is lifted 4.5" with short arms, SYE in the rear, and 6 degree shims to correct the pinion angle. The track bar is brand new, all control arms are brand new, steering stabilizer is brand new, and I have new wheels and tires that have now been balanced and rotated twice (I originally thought this was a balancing issue)
I can cruise easily to 80mph (on 3.55s and 32s) with only a slight shimmy and vibration in the wheel. I think this is just being masked by my new steering stabilizer (like all you say, it's just a band aid). Also new UCA bushings on the axle end. Yesterday, on the way home on a freeway cruising at only 55, I hit the *smallest* bump. I could barely feel it in my seat, and then all the sudden BAM BRBBRBRBRBRB death wobble. I knew what happened so I handled it fine and pulled over. The vibration stopped once I got under 30mph
I have checked all my bolts for proper torque. The track bar is tight and the hole is round. The tie rod ends are all fine (can be turned with two hands on the link, but not that bad and no lateral play). My wheel bearings and ball joints also tested fine.
Honestly at this point I have exhausted all my resources and can't think of anything else to check. Before it goes to a 4 wheel mechanic, does anyone else have something for me to look at?
I can cruise easily to 80mph (on 3.55s and 32s) with only a slight shimmy and vibration in the wheel. I think this is just being masked by my new steering stabilizer (like all you say, it's just a band aid). Also new UCA bushings on the axle end. Yesterday, on the way home on a freeway cruising at only 55, I hit the *smallest* bump. I could barely feel it in my seat, and then all the sudden BAM BRBBRBRBRBRB death wobble. I knew what happened so I handled it fine and pulled over. The vibration stopped once I got under 30mph
I have checked all my bolts for proper torque. The track bar is tight and the hole is round. The tie rod ends are all fine (can be turned with two hands on the link, but not that bad and no lateral play). My wheel bearings and ball joints also tested fine.
Honestly at this point I have exhausted all my resources and can't think of anything else to check. Before it goes to a 4 wheel mechanic, does anyone else have something for me to look at?
#2
CF Veteran
Your steering gear spacer may be cracked, They are aluminum and known to crack out leaving the box not tight on the frame.
#3
Junior Member
Thread Starter
Join Date: Dec 2015
Location: Indiana
Posts: 44
Likes: 0
Received 0 Likes
on
0 Posts
Year: 2000
Model: Cherokee
Engine: 4.0L I6
#5
Junior Member
Thread Starter
Join Date: Dec 2015
Location: Indiana
Posts: 44
Likes: 0
Received 0 Likes
on
0 Posts
Year: 2000
Model: Cherokee
Engine: 4.0L I6
#6
Seasoned Member
Join Date: Jan 2014
Location: Springfield, MO
Posts: 302
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1996
Model: Cherokee
Engine: 4.0
Have you had someone turn the wheel as you watch carefully all of the components such as track bar, drag link, steering components etc?
Trending Topics
#8
Junior Member
Thread Starter
Join Date: Dec 2015
Location: Indiana
Posts: 44
Likes: 0
Received 0 Likes
on
0 Posts
Year: 2000
Model: Cherokee
Engine: 4.0L I6
Multiple times now. The only thing I noticed is that some of my TRE boots are cracked, but by no means are any of them loose or have bad play.
#9
Junior Member
Thread Starter
Join Date: Dec 2015
Location: Indiana
Posts: 44
Likes: 0
Received 0 Likes
on
0 Posts
Year: 2000
Model: Cherokee
Engine: 4.0L I6
#10
Junior Member
Join Date: Mar 2016
Location: Michigan
Posts: 52
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1998
Model: Cherokee
Engine: 4.0
Try checking the bolt hole where the track bar goes into the axle, I replaced my track bar and the death wobble got worse! The front hole where the track bar bolts up to the axle was all wallered out and gave it just enough room to shake the rear nut loose and give the track bar some slop to walk back and forth. This gave me some bad death wobble. I welded a washer over it to correct the hole size.
Last edited by tedparis; 10-19-2016 at 12:33 PM.
#11
Seasoned Member
Join Date: Jan 2014
Location: Springfield, MO
Posts: 302
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1996
Model: Cherokee
Engine: 4.0
Well you could do mount a gopro or similar under the front bumper and take it for a ride and see what happens when the shaking starts.
#13
CF Veteran
Retorque all the bolts on the control arms and trac bar? If everything else is tight I could only suspect ball joints or hub bearings.
#14
Newbie
Join Date: Feb 2016
Location: North Jersey
Posts: 8
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1992
Model: Cherokee
Engine: 4.0 I6
did you check your tire pressure? it may just be an issue with that. I run a 3 inch budget boost in the front no doors and a chopped back. I had death wobble on anything over 65 which was terrible because of the interstate on my daily commute. 5 pounds made a huge difference in speed before wobble. one thing I've learned is that stupid things can cause problems too. just try changing the tire psi a bit till you find a happy pressure if you run oversized tires the previous owner had 185/75r17 on mine havent gotten around to upgrades but I find slightly less then 30 psi which is recommended helps ride quality and death wobble. if you cant find the issue maybe it could be an excuse for more upgrades
#15
Junior Member
Thread Starter
Join Date: Dec 2015
Location: Indiana
Posts: 44
Likes: 0
Received 0 Likes
on
0 Posts
Year: 2000
Model: Cherokee
Engine: 4.0L I6
Update: steering spacer is fine. All bolts are torqued in the front end. Tire pressure is fine. Track bar is tight and holes aren't ovaled out. It's adjusted properly and the geometry is ok.
Only thing I've found is a bad u joint in the passenger front axle. I'm going to replace both u joints in the front axle, but I don't think that will help my death wobble issue. Any other ideas would be appreciated...
Only thing I've found is a bad u joint in the passenger front axle. I'm going to replace both u joints in the front axle, but I don't think that will help my death wobble issue. Any other ideas would be appreciated...
