air /fuel ratio gauge ..any using them
#1
Member
Thread Starter
Join Date: Mar 2011
Location: montana,laurel
Posts: 108
Likes: 0
Received 1 Like
on
1 Post
Year: 89 cherokee pioneer
Model: Cherokee
Engine: 4:0
air /fuel ratio gauge ..any using them
Was curious about what brands and how u have them wired in.are you using computer signal wire to read from or have it's own sensor
#2
CF Veteran
Join Date: Oct 2012
Location: Capac, Mi
Posts: 1,127
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1997
Model: Cherokee
Engine: 4.0L
Why do you feel the need to use one? Turboed? Supercharged? If the answer to the last two questions is no, then leave it be, the OEM computer does a very good job at monitoring that.
#3
CF Veteran
Join Date: Feb 2012
Location: central IN
Posts: 2,282
Likes: 0
Received 15 Likes
on
11 Posts
Year: 1997
Engine: 4.0
it's just a gauge. it is a standalone setup that has no affiliation with the factory ecu. also the factory ecu only reads narrow band and has a very small window of information.
to the op: i have an aem yugo sitting in the box i plan to install for a short period of time just to get an idea of what it's really doing.
to the op: i have an aem yugo sitting in the box i plan to install for a short period of time just to get an idea of what it's really doing.
#4
CF Veteran
Join Date: Jul 2013
Location: Monett, MO.
Posts: 7,554
Likes: 0
Received 14 Likes
on
14 Posts
Year: 1999
Model: Cherokee
Engine: 4.0
I have a Scan Gauge mounted on my windshield in my 99 and that function is one I do not use on it. But it has very much more that I do use and it can be swapped to another car if needed.
#5
CF Veteran
I am a fan of the AEM UEGO 30-4110. It needs a 12v power source and a ground. It features an output wire for datalogging. Sensor and bung are included. Auto dimming at night.
#6
Senior Member
Join Date: Mar 2014
Location: Cincinnati, Ohio
Posts: 539
Likes: 0
Received 4 Likes
on
4 Posts
Year: 1999
Model: Cherokee
Engine: 4.0
I have the same as cummins. I use it because I have done some bolt on mods and have had mine tuned.
You will need to have a the bung welded into your down pipe just after the header for the sensor, it has it's own. You can run the sensor wire right through one of the grommets in the firewall. You will also need a power source for the gauge inside of the cab.
It is interesting to see what is going on during different times of driving but, like someone said above you really do not need it for and engine that is not tuned.
You will need to have a the bung welded into your down pipe just after the header for the sensor, it has it's own. You can run the sensor wire right through one of the grommets in the firewall. You will also need a power source for the gauge inside of the cab.
It is interesting to see what is going on during different times of driving but, like someone said above you really do not need it for and engine that is not tuned.
Trending Topics
#8
Member
Thread Starter
Join Date: Mar 2011
Location: montana,laurel
Posts: 108
Likes: 0
Received 1 Like
on
1 Post
Year: 89 cherokee pioneer
Model: Cherokee
Engine: 4:0
I have one on my truck that's been heavily modified under the hood and have it piggyback off the ecu..it's nice cause I can see that the motor is doing real.time...like when my fuel pump started to fail it would start leaning out on the top end...would never of known that with out it...I want it on the jeep cause I spend lots of time at very high elevation,like 10,000 feet plus and am always afraid to get on it hard when I may need to cause I cannot see what the afr is
#9
Member
Thread Starter
Join Date: Mar 2011
Location: montana,laurel
Posts: 108
Likes: 0
Received 1 Like
on
1 Post
Year: 89 cherokee pioneer
Model: Cherokee
Engine: 4:0
It does have a long tube header egr delete and full 2.5 exhaust and high flow intake
Last edited by oldcelicaracer; 12-19-2016 at 09:51 AM.
#10
CF Veteran
I have got one of the Ballenger Motorsports wideband (afx-500) in my Bug. Its kinda ugly but works great! If you do get a wideband, make sure it uses the Bosch LSU 4.9 sensor. The other ones don't seem last as long and you need to calibrate more often.
#12
CF Veteran
Join Date: Sep 2009
Location: ☼ Blackhole Sun
Posts: 8,567
Likes: 0
Received 18 Likes
on
16 Posts
Year: My Jeep is a GMC
Last edited by Turbo X_J; 12-15-2016 at 09:18 PM.
