Cherokee Chat General non-tech Cherokee chat
XJ/MJ/ZJ/WJ

Lift kit combinations

Thread Tools

Search this Thread

Old Oct 22, 2012 | 05:47 PM
  #16
Rivmage's Avatar
Junior Member

Joined: Jun 2010
Posts: 32
Likes: 0
From: Centennial
Default

Why not take a picture of the cover and post it?

Scott
Reply
Old Oct 22, 2012 | 05:59 PM
  #17
caged's Avatar
CF Veteran

Joined: Nov 2008
Posts: 7,874
Likes: 100
From: Northern Ontario, Canada
Year: 1990, 1999, 2000
Model: Cherokee
Engine: 4.0
Default

for the gearing, if there's no tag on the diff cover stretched between 2 bolts that tell you the gearing, then you'll have to remove the cover and look on the edge of the ring gear for the number. in that group of numbers will be the amount of teeth on the pinion and the amount of teeth on the ring gear.
something like 11-39 or something like that.

you would then take the 39 and divide it by 11 to get 3.54

btw, you probably have 3.55 if it's an auto.
Reply
Old Oct 22, 2012 | 10:23 PM
  #18
Kevin22793's Avatar
Thread Starter
Newbie

Joined: Oct 2012
Posts: 14
Likes: 0
From: Miami
Year: 1994
Model: Cherokee
Engine: 4.0L
Default

i was going to but didnt have a phone earlier i will tomorrow. im sure doing that will help.
Reply
Old Oct 22, 2012 | 10:26 PM
  #19
Kevin22793's Avatar
Thread Starter
Newbie

Joined: Oct 2012
Posts: 14
Likes: 0
From: Miami
Year: 1994
Model: Cherokee
Engine: 4.0L
Default

alright perfect i will try that tomorrow also and let you know how it goes thanks again. and it is auto but it has been opened before and the cover looks like it might not be original only reason i think that it might have upgraded gearing. and has crazy acceleration compared to my friends cherokee which also gets me to think that. it wants to peel out straight off the whole everytime
Reply
Old Oct 23, 2012 | 09:09 AM
  #20
Kevin22793's Avatar
Thread Starter
Newbie

Joined: Oct 2012
Posts: 14
Likes: 0
From: Miami
Year: 1994
Model: Cherokee
Engine: 4.0L
Default

Here's the pic of it let me know thanks.
Attached Thumbnails Lift kit combinations-image.jpg
Reply
Old Oct 23, 2012 | 09:18 AM
  #21
Rocky98's Avatar
Member

Joined: Jul 2012
Posts: 207
Likes: 0
From: College Park, MD
Year: 1998
Model: Cherokee
Engine: 4.0
Default

Looks like a Dana 35 to me!
Reply
Old Oct 23, 2012 | 03:52 PM
  #22
Kevin22793's Avatar
Thread Starter
Newbie

Joined: Oct 2012
Posts: 14
Likes: 0
From: Miami
Year: 1994
Model: Cherokee
Engine: 4.0L
Default

Originally Posted by caged
for the gearing, if there's no tag on the diff cover stretched between 2 bolts that tell you the gearing, then you'll have to remove the cover and look on the edge of the ring gear for the number. in that group of numbers will be the amount of teeth on the pinion and the amount of teeth on the ring gear.
something like 11-39 or something like that.

you would then take the 39 and divide it by 11 to get 3.54

btw, you probably have 3.55 if it's an auto.
i do have an auto and i did exactly what you said and the numbers are 8-36 which gives me 4.5 is that right has anyone heard of 4.50 gears i dont know much about gears. i can tell it has been opened before also because all the bearing have been changed and the company that did it marked everything iside with a k. these gears being 4.50 seem to be perfect for my use right

Last edited by Kevin22793; Oct 23, 2012 at 03:55 PM.
Reply
Old Oct 24, 2012 | 08:41 AM
  #23
Kevin22793's Avatar
Thread Starter
Newbie

Joined: Oct 2012
Posts: 14
Likes: 0
From: Miami
Year: 1994
Model: Cherokee
Engine: 4.0L
Default

Anyone? I know I asked a lot already but this will be the last thing for this topic.
Reply
Old Oct 24, 2012 | 08:53 AM
  #24
caged's Avatar
CF Veteran

Joined: Nov 2008
Posts: 7,874
Likes: 100
From: Northern Ontario, Canada
Year: 1990, 1999, 2000
Model: Cherokee
Engine: 4.0
Default

it is possible you have 4.56 gears.

i had it wrong, the ring gear number is stamped first, so the larger number then the smaller pinion gear number.

like this...

Reply
