Dana 35 to Chrysler 8.25 swap
05-27-2015, 02:05 PM
#1
Junior Member
Thread Starter
Join Date: Apr 2015
Location: Prescott, AZ
Posts: 67
Likes: 0
Received 1 Like
on
1 Post
Year: 1997
Model: Cherokee (XJ)
Engine: 4.0
Dana 35 to Chrysler 8.25 swap
Does anyone know if the brake drums from a Dana 35 will work on a Chrysler 8.25? I am looking to do a swap but the 8.25 I found does not come with brakes. I have also heard that the housing is longer on the 8.25 and could possibly require a shorter drive shaft but I don't think that would be an issue as I have a 4.5" lift. Any knowledge/experience about this would be appreciated.
05-27-2015, 02:24 PM
#2
CF Veteran
Join Date: Jan 2015
Location: Southern Maryland
Posts: 1,381
Likes: 0
Received 1 Like
on
1 Post
Year: 1991
Model: Cherokee
Engine: 1999 4.0L
Does anyone know if the brake drums from a Dana 35 will work on a Chrysler 8.25? I am looking to do a swap but the 8.25 I found does not come with brakes. I have also heard that the housing is longer on the 8.25 and could possibly require a shorter drive shaft but I don't think that would be an issue as I have a 4.5" lift. Any knowledge/experience about this would be appreciated.
Pinion on the 8.25 comes out about 1" further than the D35 but if you are lifted then you have room for it
05-27-2015, 02:33 PM
#3
Banned
Join Date: Apr 2015
Location: Pacific NW
Posts: 62
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1997
Model: Cherokee
Engine: 4.0
Yeah, all of that brake stuff swaps over, but IIRC the Ebrake levers are different. At any rate, you can compare the two and figure it out. I installed a Junkyard 8.25 and used the best parts from both it and the outgoing Dana35 to make up a good set of brakes on the 8.25.
Then I sold the D35 to the scrapyard for 6 bucks and spent that on beer.
Then I sold the D35 to the scrapyard for 6 bucks and spent that on beer.
05-27-2015, 03:01 PM
#4
Junior Member
Thread Starter
Join Date: Apr 2015
Location: Prescott, AZ
Posts: 67
Likes: 0
Received 1 Like
on
1 Post
Year: 1997
Model: Cherokee (XJ)
Engine: 4.0
Yeah, all of that brake stuff swaps over, but IIRC the Ebrake levers are different. At any rate, you can compare the two and figure it out. I installed a Junkyard 8.25 and used the best parts from both it and the outgoing Dana35 to make up a good set of brakes on the 8.25.
Then I sold the D35 to the scrapyard for 6 bucks and spent that on beer.
Then I sold the D35 to the scrapyard for 6 bucks and spent that on beer.
Trending Topics
05-27-2015, 06:38 PM
#8
Junior Member
Thread Starter
Join Date: Apr 2015
Location: Prescott, AZ
Posts: 67
Likes: 0
Received 1 Like
on
1 Post
Year: 1997
Model: Cherokee (XJ)
Engine: 4.0
according to this manual all but the police models had 9" drums whether they had the dana 35 or chrysler 8.25.
Last edited by Pinoy59; 05-27-2015 at 06:42 PM.
05-27-2015, 06:40 PM
#9
CF Veteran
Join Date: Jan 2013
Location: west chester, pa
Posts: 19,216
Likes: 0
Received 39 Likes
on
35 Posts
Year: 1999
Engine: 4.0
according to this manual all but the police models had 9" drums whether they had the dana 35 or chrysler 8.25. http://www.jeep4x4center.com/jeep-pa...ts-Catalog.pdf
05-27-2015, 07:30 PM
#14
CF Veteran
Join Date: Feb 2012
Location: Hamburg, NY
Posts: 1,258
Likes: 0
Received 0 Likes
on
0 Posts
Year: 2001
Model: Cherokee
Looks like a great time to do a WJ Disk brake swap or the Tera Flex kit. Not sure if everything can swap, I did a brake conversion when I swapped in my 8.25.
