Budget Builds: What Junkyard Parts Will Fit Cherokee?
CF Veteran
Joined: Aug 2019
Posts: 1,467
Likes: 267
From: Littleton, CO
Year: '96
Model: Cherokee (XJ)
Engine: 4.0 HO
^^^^^^ Another good reason for the junkyard parts list to be updated to be a little more specific about what it will fit, how it fits, what its for, why its beneficial, is it for improvement of just for replacement.....????? ^^^^^^^^^^^^^^^^^^
I would love to update that list. but I dont know enough about our jeeps and the donor vehicles to do a good job with it....
I would love to update that list. but I dont know enough about our jeeps and the donor vehicles to do a good job with it....
CF Veteran
Joined: Oct 2013
Posts: 5,924
Likes: 203
From: Greenville, SC
Year: 1999
Model: Cherokee(XJ)
Engine: 4.0
Originally Posted by Cruisingram
Over 2000 responses here? wow- does one of them talk about what brackets will swap out the electric seat base for the XJ? Mine is stuck all the way forward, and the motor is frozen solid.
Junior Member
Joined: Apr 2013
Posts: 41
Likes: 5
Model: Cherokee
CF Veteran
Joined: Aug 2019
Posts: 1,467
Likes: 267
From: Littleton, CO
Year: '96
Model: Cherokee (XJ)
Engine: 4.0 HO
That list is really old and the people that put it together mostly aren't around here anymore, and no one wants to take the time to add to it for details, or make corrections to it. I was told this when I complained about how old it is, and that it lacks good information about swapping parts. I would try and update it, but I'm not the SME for XJ's.
Newbie
Joined: Sep 2021
Posts: 2
Likes: 0
Model: Cherokee (XJ)
Hey guys for the sake of everyone doing budget junkyard builds I was wondering what parts from other vehicles will fit an XJ with little or no modification that will help the performance/offroad capabilities of the XJ....feel free to post your mods and links to build threads if you have them.....this thread is to help new guys on a budget get started
***note that these are not all bolt in mods, but can be done by most who are mechanically inclined with the right tools
Here is the latest re-cap of what we have found:
Suspension & Lift:
1. ZJ V8 Upcountry Coils = 1-1.5" lift
2. F-150/Bronco Coils ('70s-ish) = 4-4.5" lift
3. S10 (P/U or Blazer) leaf packs (cut eyes off S10 main and bolt pack under XJ main) = 3-4" lift (may require use of degree shims)
4. Dakota Bastard Pack (do same as with S10 pack) = ~4" lift
5. JK shocks = slight mod to fit 2-4" lift (some dispute)
6. MJ Shackles = 1/2" lift
7. Camaro Spring Isolators = 1.5" lift
8. Full size Blazer Bastard Pack (do same as S10 pack) = 4-4.5" lift (may require use of shims) may be stiffer than S10 leafs
9. ZJ spring isolators = stronger, metal core, can be stacked
10. GM fullsize pickup shackles ('95-99) = 1.5" lift, better shackle angle
11. Thunderbird Front Coils ('83-97) = 3-4" lift (varies in lift and softness by year and trim package), will need top plate from strut too
12. Any 2.5" wide leaf spring can be used between to make a bastard pack (they may differ in stiffness and lift)
13. S10 Shocks (Rear only) = good for the lift you will get when you do a bastard pack
14. TJ Lift Coils (front only) = provide 1" less lift on an XJ than on a TJ
Brakes:
1. WJ brake booster
2. WJ Master Cylinder
3. YJ Brake Lines = 3-4" longer
4. Dodge Ram Van Brake Lines = 10-12" longer (for big lifts)
5. WJ Rotors/Calipers = bigger brakes and more stopping power (will fit 15" rims)
6. ZJ brake booster, master cylinder, proportioning valve = may need for disc conversion
7. XJ '95+ brake booster and master cylinder = dual diaphragm
8. Dakota Rear Softlines ('95-00) = 6" longer
9. GM C/K1500 Front Softlines ('90-95) = 6" longer
10. KJ disc brake set-ups can be used for a conversion on your XJ axle
Axles:
1. Ford 8.8 inch ('97+) = need spring & shock mounts (3.55, 3.73, or 4.10, maybe LSD, Disc Brakes)
2. XJ I-4 & some V6 = may have 3.73, 4.10, or 4.56 gears may have vacuum discos
3. XJ C8.25 ('97+) = bolt in and upgrades to 29 spline (strength comparable to D44)
4. XJ D44 = found in some but not all '87-'89 XJ's with Towing Package
5. Lincoln Lockers = welded spider gears, operates like a spool, must be a GOOD welder
6. MJ D44 = need new spring perches and shock mounts
7. XJ D30 = ('95-'99) non-disconnect, larger u-joints, high pinion, bolt in
8. Homebrew posi-locks for '84-90 vacuum disconnect D30s, eliminates vacuum actuation (use search function)
Front End & Steering:
1. ZJ V8 Tierods = beefier & bolt in
2. WJ Knuckles/Tierods/Draglinks = beefier and crossover steering
3. Durango Steering Box = beefier
4. 350 or 351 Power Steering Pump = helps with oversize tires (requires welding)
5. WJ LCA's = more tire clearance (some grinding required)
6. ZJ pitman arm = 1 inch drop over stock
7. WJ rear LCA's = replace XJ front LCA's, 2" longer to accommodate a lift, some grinding required
8. WJ power steering pump (fits '96+, plug return hole, and use XJ pulley)
9. V8 ZJ front sway-bar
10. JK rear UCA = use as XJ LCA, its about 1-2" longer
Engine/Transmission/T-case:
1. Newer XJ intakes (may require some modification)
2. Mustang 5.0 Injectors = near bolt in (have 4 holes instead of 1, more fuel, better spray)
3. ZJ V8 alternator = more power to run accessories (some grinding required) 136A (for 1991 and newer XJ's).
4. Ford Electric Fan ('90-95 3.8L Taurus, '87-93 5.0L Mustang) = replaces mechanical fan, more cooling (8C607)
5. 2.5L Dakota Alternator = bolt in, upgrades to 117A
6. Dodge Neon Injectors = better throttle response
7. '94+ V6 Dakota AX-15 = bolt in (but must use XJ bellhousing)
8. ZJ and WJ stock tranny coolers with stacked plates (even an upgrade for us with the stock fin style)
9. 5spd crossmembers give 3/4 inch t-case drop on autos with no loss in ground clearance
10. Hoodvents (i.e. Lebaron, Laser, Turbo Thunderbird etc.) = help keep ur 4.0 cool at low speeds
11. You can convert the closed system to open without replacing your radiator by using the fill cap from a 4.7 durango or dakota, cutting it into your upper hose, and replace your bottle with an MJ overflow tank or any that fit. Then cap off or eliminate the T'ed lines in the heater core.
12. Homebrew Slip Yoke Eliminator (use search function)
Body/Interior/Armor:
1. 97+ mirrors are direct bolt in to older XJ's and allow you to fold them in on tight trails.
2. MJ/2 Door XJ Bucket seats = tilt forward, bolt in
3. ZJ gas tank skid = can be modified to fit 97+
4. GM power antennas replace your broken XJ's with little modification
5. XJ '97+ doors onto older cherokees = one piece windows and better mirrors
6. XJ overhead console = most commonly found in '00-01 or higher trim level, provides space for switches etc.
7. '97+ center console = can be made to fit '96 and older, gives you cupholders!
8.'96-00 Ford Explorer hatch shocks = lift your hatch about 3" lower but are beef (ever see one that doesn't work?) need modification for '97+
9. OEM skid plates (Front, Tranny, T-case, gas tank, found on "up-country" package XJ's)
10. OEM swing-out tire carriers, get the bumper with it, found mainly on '84-'90 XJ's
*feel free to ask questions about any of these mods
**Also Blazin Den has made a list of links to build threads for us! Recap with Links!
***Here is the Link to the thread on Jeepforum.com where most of this info came from Budget Builds: What Junkyard parts will fit an XJ?
***note that these are not all bolt in mods, but can be done by most who are mechanically inclined with the right tools
Here is the latest re-cap of what we have found:
Suspension & Lift:
1. ZJ V8 Upcountry Coils = 1-1.5" lift
2. F-150/Bronco Coils ('70s-ish) = 4-4.5" lift
3. S10 (P/U or Blazer) leaf packs (cut eyes off S10 main and bolt pack under XJ main) = 3-4" lift (may require use of degree shims)
4. Dakota Bastard Pack (do same as with S10 pack) = ~4" lift
5. JK shocks = slight mod to fit 2-4" lift (some dispute)
6. MJ Shackles = 1/2" lift
7. Camaro Spring Isolators = 1.5" lift
8. Full size Blazer Bastard Pack (do same as S10 pack) = 4-4.5" lift (may require use of shims) may be stiffer than S10 leafs
9. ZJ spring isolators = stronger, metal core, can be stacked
10. GM fullsize pickup shackles ('95-99) = 1.5" lift, better shackle angle
11. Thunderbird Front Coils ('83-97) = 3-4" lift (varies in lift and softness by year and trim package), will need top plate from strut too
12. Any 2.5" wide leaf spring can be used between to make a bastard pack (they may differ in stiffness and lift)
13. S10 Shocks (Rear only) = good for the lift you will get when you do a bastard pack
14. TJ Lift Coils (front only) = provide 1" less lift on an XJ than on a TJ
Brakes:
1. WJ brake booster
2. WJ Master Cylinder
3. YJ Brake Lines = 3-4" longer
4. Dodge Ram Van Brake Lines = 10-12" longer (for big lifts)
5. WJ Rotors/Calipers = bigger brakes and more stopping power (will fit 15" rims)
6. ZJ brake booster, master cylinder, proportioning valve = may need for disc conversion
7. XJ '95+ brake booster and master cylinder = dual diaphragm
8. Dakota Rear Softlines ('95-00) = 6" longer
9. GM C/K1500 Front Softlines ('90-95) = 6" longer
10. KJ disc brake set-ups can be used for a conversion on your XJ axle
Axles:
1. Ford 8.8 inch ('97+) = need spring & shock mounts (3.55, 3.73, or 4.10, maybe LSD, Disc Brakes)
2. XJ I-4 & some V6 = may have 3.73, 4.10, or 4.56 gears may have vacuum discos
3. XJ C8.25 ('97+) = bolt in and upgrades to 29 spline (strength comparable to D44)
4. XJ D44 = found in some but not all '87-'89 XJ's with Towing Package
5. Lincoln Lockers = welded spider gears, operates like a spool, must be a GOOD welder
6. MJ D44 = need new spring perches and shock mounts
7. XJ D30 = ('95-'99) non-disconnect, larger u-joints, high pinion, bolt in
8. Homebrew posi-locks for '84-90 vacuum disconnect D30s, eliminates vacuum actuation (use search function)
Front End & Steering:
1. ZJ V8 Tierods = beefier & bolt in
2. WJ Knuckles/Tierods/Draglinks = beefier and crossover steering
3. Durango Steering Box = beefier
4. 350 or 351 Power Steering Pump = helps with oversize tires (requires welding)
5. WJ LCA's = more tire clearance (some grinding required)
6. ZJ pitman arm = 1 inch drop over stock
7. WJ rear LCA's = replace XJ front LCA's, 2" longer to accommodate a lift, some grinding required
8. WJ power steering pump (fits '96+, plug return hole, and use XJ pulley)
9. V8 ZJ front sway-bar
10. JK rear UCA = use as XJ LCA, its about 1-2" longer
Engine/Transmission/T-case:
1. Newer XJ intakes (may require some modification)
2. Mustang 5.0 Injectors = near bolt in (have 4 holes instead of 1, more fuel, better spray)
3. ZJ V8 alternator = more power to run accessories (some grinding required) 136A (for 1991 and newer XJ's).
4. Ford Electric Fan ('90-95 3.8L Taurus, '87-93 5.0L Mustang) = replaces mechanical fan, more cooling (8C607)
5. 2.5L Dakota Alternator = bolt in, upgrades to 117A
6. Dodge Neon Injectors = better throttle response
7. '94+ V6 Dakota AX-15 = bolt in (but must use XJ bellhousing)
8. ZJ and WJ stock tranny coolers with stacked plates (even an upgrade for us with the stock fin style)
9. 5spd crossmembers give 3/4 inch t-case drop on autos with no loss in ground clearance
10. Hoodvents (i.e. Lebaron, Laser, Turbo Thunderbird etc.) = help keep ur 4.0 cool at low speeds
11. You can convert the closed system to open without replacing your radiator by using the fill cap from a 4.7 durango or dakota, cutting it into your upper hose, and replace your bottle with an MJ overflow tank or any that fit. Then cap off or eliminate the T'ed lines in the heater core.
12. Homebrew Slip Yoke Eliminator (use search function)
Body/Interior/Armor:
1. 97+ mirrors are direct bolt in to older XJ's and allow you to fold them in on tight trails.
2. MJ/2 Door XJ Bucket seats = tilt forward, bolt in
3. ZJ gas tank skid = can be modified to fit 97+
4. GM power antennas replace your broken XJ's with little modification
5. XJ '97+ doors onto older cherokees = one piece windows and better mirrors
6. XJ overhead console = most commonly found in '00-01 or higher trim level, provides space for switches etc.
7. '97+ center console = can be made to fit '96 and older, gives you cupholders!
8.'96-00 Ford Explorer hatch shocks = lift your hatch about 3" lower but are beef (ever see one that doesn't work?) need modification for '97+
9. OEM skid plates (Front, Tranny, T-case, gas tank, found on "up-country" package XJ's)
10. OEM swing-out tire carriers, get the bumper with it, found mainly on '84-'90 XJ's
*feel free to ask questions about any of these mods
**Also Blazin Den has made a list of links to build threads for us! Recap with Links!
***Here is the Link to the thread on Jeepforum.com where most of this info came from Budget Builds: What Junkyard parts will fit an XJ?
Newbie
Joined: Sep 2021
Posts: 2
Likes: 0
Model: Cherokee (XJ)
Newbie
Joined: Feb 2021
Posts: 9
Likes: 0
From: Lake city, fl
Year: 1999
Model: Cherokee (XJ)
Engine: 4.0
Senior Member
Joined: Apr 2013
Posts: 781
Likes: 2
From: Dawson Springs, KY
Year: 1985
Model: Cherokee
Engine: 2.5L
I think the top plate is to reduce the opening at the top of the spring to a size that will set against the spring isolator and not just rest on the inner fender, since I believe the Thunderbird springs are a larger diameter or are simply missing the smaller curl on the end to reduce the diameter.
Newbie
Joined: May 2023
Posts: 1
Likes: 0
Help me
you can always weld two stock sets of xj coils... cheaper than cheap in any junkyard... i used to bust them but have figured out the perfect technique...
Junior Member
Joined: Oct 2017
Posts: 30
Likes: 1
From: troutman, NC
Year: 1987
Model: Cherokee(XJ)
Engine: 4.0
has anyone tried the gladiator control arms on the XJ for LCA's or are they too long, have a 4.5 inch lift going on and possibly have some available to me.
CF Veteran
Joined: Aug 2019
Posts: 1,467
Likes: 267
From: Littleton, CO
Year: '96
Model: Cherokee (XJ)
Engine: 4.0 HO
http://www.lunghd.com/Tech_Articles/..._Arm_Chart.htm
Found this. It's handy for me as well since I need upper control arms to fix my slightly off castor. I'm at 4.5" also but only changed my lower control arms, hence my jeep looks like it is nosed down by about an inch or so.
Found this. It's handy for me as well since I need upper control arms to fix my slightly off castor. I'm at 4.5" also but only changed my lower control arms, hence my jeep looks like it is nosed down by about an inch or so.
Last edited by RockyMtn96XJ; Nov 1, 2023 at 12:22 PM.
