Modified XJ Cherokee Tech XJ (84-01)
All modified tech questions. If it modifies your XJ beyond stock parts ask it here.

4:56 Gears

Old 03-06-2019, 08:41 PM
  #1
Junior Member
Thread Starter

Join Date: Jul 2014
Location: YAY AREA
Posts: 74
Likes: 0
Received 0 Likes on 0 Posts
Year: 1997
Model: Cherokee (XJ)
Engine: 4.0
Default 4:56 Gears

I just ordered 4:56 gears for front and rear axle. I plan to run 33x12.50 tires and wondering who else runs this set up and also what rpms you are getting with auto tranny (AW-4).

I would also like to hear from those running 35s. Thanx!

Last edited by X1997J; 03-06-2019 at 08:43 PM.
X1997J is offline
Old 03-06-2019, 10:07 PM
  #2
Newbie

Join Date: Mar 2017
Location: Los Angeles
Posts: 18
Likes: 0
Received 0 Likes on 0 Posts
Year: 2001
Model: Cherokee
Engine: 4.6 Russ motor
Default

My 2001 has 4.56 gears and 10.50 X 33-15 KO2s.
At 60 MPH, reading off the GPS, it's turning 2300 RPM, read with a ScanGuage. This is similar to stock gearing.
Due to the extra weight, it didn't feel that fast, It would be interesting to run 4.88s with the 33"s. With the 4.56s, it was a lot of fun to drive when it still had 31"s.
It's more interesting to drive now, with a little help from Russ Pottenger .
lazyxj is offline
Old 03-06-2019, 10:41 PM
  #3
CF Veteran

00t444e's Avatar

Join Date: Nov 2015
Location: Southern OH
Posts: 1,991
Received 9 Likes on 8 Posts
Year: 1997
Model: Cherokee(XJ)
Engine: 4.0
Default

Use this to find out your what your rpms will be, http://www.grimmjeeper.com/gears.html or use the formula and do the math yourself.
00t444e is online now
Old 03-07-2019, 07:50 AM
  #4
Senior Member

TRCM's Avatar

Join Date: Jan 2016
Location: Newport News, VA
Posts: 962
Likes: 0
Received 3 Likes on 3 Posts
Year: 96 & 88 4 dr Cherokees
Default

Originally Posted by lazyxj View Post
My 2001 has 4.56 gears and 10.50 X 33-15 KO2s.
At 60 MPH, reading off the GPS, it's turning 2300 RPM, read with a ScanGuage. This is similar to stock gearing.
Due to the extra weight, it didn't feel that fast, It would be interesting to run 4.88s with the 33"s. With the 4.56s, it was a lot of fun to drive when it still had 31"s.
It's more interesting to drive now, with a little help from Russ Pottenger .

Stock gearing & tire size would be 1900-2000 @ 60 mph......
TRCM is online now
Old 03-07-2019, 08:24 AM
  #5
CF Veteran

SatiricalHen's Avatar

Join Date: Oct 2013
Location: Greenville, SC
Posts: 5,478
Likes: 0
Received 6 Likes on 5 Posts
Year: 1999
Model: Cherokee(XJ)
Engine: 4.0
Default

I've had 4.56 with 31s, 33s, and now I'm on 35s. I don't remember exact rpms, but it did fine on the highway with all of the tire sizes above. My 4.0 seems a little tired though so it would probably do even better with a strong motor.
SatiricalHen is online now
Old 03-07-2019, 11:25 AM
  #6
Junior Member
Thread Starter

Join Date: Jul 2014
Location: YAY AREA
Posts: 74
Likes: 0
Received 0 Likes on 0 Posts
Year: 1997
Model: Cherokee (XJ)
Engine: 4.0
Default

Thanx for the replies. I have stock gearing now with 31s and I'm getting about 2100 rpm at 60mph. I'm just curious to see what the rpms will actually be with the new setup.
X1997J is offline
Old 03-07-2019, 11:35 AM
  #7
CF Veteran

00t444e's Avatar

Join Date: Nov 2015
Location: Southern OH
Posts: 1,991
Received 9 Likes on 8 Posts
Year: 1997
Model: Cherokee(XJ)
Engine: 4.0
Default

Have you changed your speedometer gear for the larger tires? With 31s and 3.55s, at 2100 rpm you would be going faster than 60 mph with 31s.
00t444e is online now
Old 03-07-2019, 11:38 AM
  #8
Senior Member

TRCM's Avatar

Join Date: Jan 2016
Location: Newport News, VA
Posts: 962
Likes: 0
Received 3 Likes on 3 Posts
Year: 96 & 88 4 dr Cherokees
Default

Originally Posted by X1997J View Post
Thanx for the replies. I have stock gearing now with 31s and I'm getting about 2100 rpm at 60mph. I'm just curious to see what the rpms will actually be with the new setup.

Have you checked you speed vs gps ? or mile markers on the highway ??

I ask, cuz I found out my speedo was off by a lot from the factory....enough so, that with stock gears and 31's, it is only off by ~2 mph @ 60 on the speedo.....as in 60 on speedo is 61.5 by gps.

and about the same rpm as you say you are getting.
TRCM is online now
Old 03-07-2019, 06:14 PM
  #9
Junior Member
Thread Starter

Join Date: Jul 2014
Location: YAY AREA
Posts: 74
Likes: 0
Received 0 Likes on 0 Posts
Year: 1997
Model: Cherokee (XJ)
Engine: 4.0
Default

I will have to do a gps check next time I drive it.
X1997J is offline
