PingPong

87 XJ Limited Chop Top
Drivetrain
4.0
AX15 (98 TJ external slave)
231/231 Doubler Box 4 rocks kit clocked flat A/A SYE Twin sticked using cables
Home made driveshafts

Front Axle
73 ford hpd44 T&T truss
Arb 5.13's
Nitro Shafts w/300M Ujoints
Reid Chevy Knuckles
Waggy spindles and Brake stands
Solid drive flanges
Solid High steer arms
ARB Diff cover

Rear Axle
73 Ford 9"
Detriot 5.14
T&T UBE's
Barnes 4wd Disc brak brackets
Barnes 4wd Pinion guard
3/4 chevy calipers, with 89 rotors.
Dutchman alloy shafts with 6x5.5 bolt pattern


Suspension
RK 3 link
Rusty's 808 coils
RE HD trac bar Custom 1.5 trac bar Flex joint both ends
Steering is 3/4 Heim joints with 1.5x.25 tubing

Rear is a bastard pack with JKS shackle

Tires
36x12.5x15 TSL Bias Ply W/ custom tire grooving
Soft 8 cragars, w DIY 32 bolt Beadlocks


Misc
10 gallon RCI fuel cell e200 fuel pump
Battery relocated to the rear, 200amp battery kill switch
8pt roll cage with seat mounts built into cage
Toyota Cellica seatsw/4pt RCI harness
Custom tube flat skid
Proto fab copied tube bumper w/8XRC sythetic winch
Copied AJ rock Rails






Still to do
MJ rear leaf spring Stretch
Shackle relocation boxes
Antiwrap Bar
Hydo assist Using West Texas Offroad Ported Box, Psc 8"x1.25 ram and a TC pump

MUDRUNNER AZ

1992 4 dr
Base model

ENGINE
4.0L stock internals
K&N air intake with 62 MM throttle body.
Hesco high flow water pump and T-stat housing

FRONT AXLE
D30 with Detroit True Trac 4.88 gears (soon to be swapped with D44)
Tera Flex High steer setup.

Transmission
Stock AW4

T-CASE
Tera low 4 to 1
with Advanced Adapters SYE
Driveshaft by Precision Products

REAR AXLE
Swapped in D60 5.38 gear/powerlock upgrade to moser 35spline axles and detroit soon)

SUSPENSION
About 10.5 in with combo of ACOS adjustable spacers, Skyjacker 8in coils, rear full spring pack and Tera flex shackle, and 2in block.
Stainless steel brakelines all around Ter LCA, Rubicon UCA, Skyjacker axle cradle, riddler rear diff cover, Ballistic front cover (soon for sale)
LCA drop brackets.
RS 9000 shocks all around

BUMPERS/SLIDERS
Front is a Warn combo winch bumper modified to fit with a Warn 12k in it.
Rear is custom built out of 2x5 1/4 in rectangle tubing and diamond plate.
Tire carrier swing away in the works but not done.
Slders are JKS with an extra 2x2 added to make a better step.

Exterior
Home made roof rack
Lund moon visor
Bushwacker fender flares
7 in HID lights up front
8 1 in LED rock lights underneath

INTERIOR
Cloth seats
Pioneer head unit with boston acoustics speakers
2 amps in custom box with 1 10 in sub
Cobra 148 cb with 100 watts added
LED rear cargo lighting

TIRES/WHEELS
36 in Super Swamper Irok radials
Combo of Mickey Thompson classic 15x10 alum wheels and some painted steelies. (due to axle swap.

N20jeep

- 1992
- Base
- 4.0, ax15, np231, d30, 8.8

-FRONT SUSPENSION/AXLE
homebrew control arms
4.5"rustys springs
rustys double sheer track bar
rustys HD steering
rustys steering stabilizer
JK brake lines
12" shocks with stud eliminator
d30 w/ 4.10's

-REAR SUSPENSION/ AXLE
Coil conversion 4 link
double triangulated control arms
LJ coil springs
Home fabbed shock hoop through floorboard
14" gas charged shocks
22" limiting straps
braced rear frame
high clearence axle brackets
custom brake lines
8.8 with 4.10's, trussed, locked

-DRIVETRAIN and ENGINE
NP231 w/ SYE
custom built driveshafts
3/4" transfercase LIFT
solid 4wd shifter linkage
01 wj intake manifold
01 wj tensioner setup

-WHEELS AND TIRES
35x12.5x15 procomp MT's
15x10 AR aluminum wheels

-EXTERIOR and INTERIOR and ACCESORIES
trimmed fenders
rear quarter panel cut n fold
homebrew 2 tone with khaki top and bedlined bottom
removeable doors
speakers mounted in dash
el-cheapo cd/mp3/usb player
Bedlined Floorboard w/ drainholes
KC lights mounted on hood
Kayak rack
Rugged Ridge seat covers

-Recovery
Class 3 hitch
Rear Warn D-ring reciever for hitch
tow rope
front bumper (came with jeep, getting replaced with a homebrew one soon!)
Driver mod

-Much more to come!

SHANE 87

Shane 87

1993 Jeep Cherokee 4door

miles: 254,556
Engine: 4.0 high output oil burner
Transmition: AW4 automatic
Transfercase:NP242
Front Axle: Dana 30 open carrier
Rear Axle: Dana 35 worn out factory lsd
Tires:31in bfg km's

Hurculined interior
Cobra 19 cb with manetic mount anttenna

Factory rear tire carrier that sags
Factory roof rails added: my jeep did not come with them
Surco roof rack:mounts to the factory roof rails
Offroad lights: mounted to the front of the surco rack but not wired up yet
Olive green and gloss black rattle can paint job

Lift front: 2-3in budget boost not sure the actual amount of lift
Rear lift: 3in with aal and shackle
Front swaybar: disconected
Rear swaybar: removed

havok 327

1988
4.0 straight 6,5 speed tranny

misc:fabbed bumpers, random tow hooks,piaa xtreme whites,remote starter in glove box (passenger can quick fire if stalled,no need for driver to remove hands from shifter) newer seats,winch rollers,a strap to tie hatch down,flares that are too small anyway,and a large helping of love dents

suspension:4 ply leafs all around,rough country gas shocks
exhaust: whats that?
tires:38" toyo m/t open country
lift total:10 inches
axels:dana 60 and 14 bolt gm free floater 4.56 10.5"
brakes:discs all around from a schmevy 2500
color:rustoleum satin in spruce green
newest addition:iwo jima sticker

in a nutshell shes a go jeep not a show jeep,shes not much to look at some say...but i see my favorite gal.

96_xj

Best of luck to all of you!

Gee oh Dee

Tough choices this month.

N20jeep

wow, stacked competition this month.

good luck everyone!

no rdplz

Wow, this was a tough one! Nice rigs to all of you!

4x4cherokeexj

Whoa. Tough competition this month!

96_xj

my vote was to the 2 door, long arm/linked front and rear N20 jeep

CatBassin

Impossible to choose between all these sexy rigs.

War Eagle

front leaf fail! lol sweet rig havok and ur from pa

nitro450exp

Got to give the 2 door, rear coil sprung, love.

Nitro

Bustedknuckle

why can't this be Facebook?? I wanna "Like" all of them.
