Default Help front lower control arm swap

After lifting the ZJ I ran into some death wobble. As you can see on the front arm the bushings are shot, and the arms were maxed out at just shy of 7* of caster. So I figured I should get some longer ones and heard about the JK rear UCA swap. The rear swap went fine I have some clunking but I think that is my rear swaybar that is not connected as of yet. I digress. So the front arms bushings are shot and I am in the middle of swapping out my front control arms and ran into a slight snag.

Click the image to open in full size.

The top arm is a rear upper JK arm 17 1/2"
The middle arm is factory ZJ rear LCA 16 3/4"
The bottom arm is factory ZJ front LCA 15 3/4"

My original plan was to use the JK arm until I saw the three together. I am afraid the JK arm will be two long and mess my front drive line angle up and cause vibrations. I am leaving the front factory UCA in place. Any thoughts. I am thinking I should probably used the rear arm but was hoping for some input.
__________________
265/75/R17 BFG MT's, 4" OME cusom, WJ knuckle conversion, KOR LP Sliders, KOR track bar conversion, JKS disco's, 4.0, K&N FIPK2, 62MM Throttlebody and hesco spacer, 01 WJ intake manifold, Doug Thorley headers 2.5" exhaust mandrel bent from cat back, Magnaflow cat, flowmaster 70 muffler, Firepower ignition with E3 plugs, Neon 703 injectors, Hypertech Max energy tunner, FloCooler waterpump. Stillen rotors on rear.
gully369 is offline   Reply With Quote
Old 03-12-2011, 03:43 PM   #2
Member

gully369's Avatar

Join Date: Jul 2009
Location: Fort Collins, CO
Posts: 103

View gully369's Photo Album My Photos
98 Grand Cherokee
Send a message via MSN to gully369
Default

Already bumped off the first page in 35min...crazy

I need some opinions here
__________________
265/75/R17 BFG MT's, 4" OME cusom, WJ knuckle conversion, KOR LP Sliders, KOR track bar conversion, JKS disco's, 4.0, K&N FIPK2, 62MM Throttlebody and hesco spacer, 01 WJ intake manifold, Doug Thorley headers 2.5" exhaust mandrel bent from cat back, Magnaflow cat, flowmaster 70 muffler, Firepower ignition with E3 plugs, Neon 703 injectors, Hypertech Max energy tunner, FloCooler waterpump. Stillen rotors on rear.
gully369 is offline   Reply With Quote
Old 03-12-2011, 04:50 PM   #3
CF Veteran


Gorillaxj's Avatar

Join Date: Sep 2010
Location: Salt Lake City, UT
Posts: 4,959

View Gorillaxj's Photo Album My Photos
2000 Cherokee
Default

did a little goggle search, and found this,

Control Arm Length Application Chart
factory control arm lengths according to Tera-flex
•all front upper control arms- 15 1/8”
•all rear upper control arms- 13 1/4”
•all TJ lower and ZJ front lower arms- 15 3/4”
•XJ front lower control arms- 16 1/4” - However my stock front lower arms measure 15 3/4 (same a tj/ZJ)
•ZJ rear lower control arms- 16 11/16”
•WJ front lower control arms- 16”
•WJ rear lower control arms- 19”

Maximum adjustment from factory length is +/- 3/4”.
Adjustments can be made to the front arms to adjust the caster, and to the rear to adjust the pinion angle.
Flex Arms may be lengthened or shortened if necessary.
Adjusting the arms in or out more than 3/4” from factory settings will void any warranty.

Control Arm Length Application Chart
For Jeep Cherokee (XJ)

Lift|Lower Control Arms||Upper Control Arms
|Decimal|Fraction|Decimal|Fraction
Stock|15.75 |15 3/4|15.00 |15
2” |15.92 |16 |14.88 |15
3” |16.09 |16 |14.92 |15
4” |16.33 |16 3/8 |15.03 |15
4.5”|16.47 |16 1/2 |15.11 |15
5” |16.62 |16 5/8 |15.21 |15 1/4
6” |16.97 |17 |15.44 |15 1/2
7” |17.36 |17 3/8 |15.74 |15 3/4
8” |17.81 |17 3/4 |16.09 |16
9” |18.30 |18 1/4 |16.50 |16 1/2
10” |18.82 |18 3/4 |16.96 |17



don't know if it helps you much as its based on a XJ, but based on this and the fact you have 4" lift (in sig) I would go with the middle arm...
__________________
Drove it, wheeled it, left it, and SOLD it
Gorillaxj is offline   Reply With Quote
Old 03-14-2011, 01:36 PM   #4
AOR
Cherokee Forum Vendor

AOR's Avatar

Join Date: Mar 2011
Location: Mount Aukum
Posts: 867

View AOR's Photo Album My Photos
Cherokee
Default

Crown Automotive Adjustable lower control arm kit.

Click the image to open in full size.

These fit 0-6" short arm lift kits and come with new greaseable bolts. Fits Cherokee XJ and Grand Cherokee ZJ model fronts. They are 1.25" tubing with .25" wall.

They have a 12 month/12,000 mile mfg warranty.

Namaste,

Allen
__________________
Allen Kurtz
Allen's Offroad
530-620-1100

Never miss a great opportunity to shut up!
Be careful what you ask for, you will get it!
AOR is offline   Reply With Quote
Old 10-01-2011, 09:26 PM   #5
Member

angelsman's Avatar

Join Date: Jun 2010
Location: Otisville, MI
Posts: 119

View angelsman's Photo Album My Photos
1999 Cherokee
Default

Did this work? I'm gonna try this next week. I'll post pics.
__________________
Project 1KXJ
angelsman is offline   Reply With Quote
Old 10-04-2011, 05:19 PM   #6
Seasoned Member

lonewolf411's Avatar

Join Date: Jan 2009
Location: Central NJ
Posts: 260

View lonewolf411's Photo Album My Photos
2000 Cherokee
Default

Quote:
Originally Posted by angelsman View Post
Did this work? I'm gonna try this next week. I'll post pics.
Im interested if this worked! Please post pics and advice
lonewolf411 is offline   Reply With Quote
Old 10-09-2011, 06:59 PM   #7
Member

angelsman's Avatar

Join Date: Jun 2010
Location: Otisville, MI
Posts: 119

View angelsman's Photo Album My Photos
1999 Cherokee
Default

It worked great! Pushed the axle forward where it should be and it rides so much better. The bushings on the ZJ lcas were in good shape so I left them alone. Did the swap in an hour. Used a small bottle jack to push axle forward. I picked up the arms for $50 at a local salvage yard.
__________________
Project 1KXJ
angelsman is offline   Reply With Quote
Old 10-09-2011, 07:02 PM   #8
Member

angelsman's Avatar

Join Date: Jun 2010
Location: Otisville, MI
Posts: 119

View angelsman's Photo Album My Photos
1999 Cherokee
Default

With 4.5" of lift, the rear ZJ lcas work good on the XJ front. Cheap and easy!
__________________
Project 1KXJ
angelsman is offline   Reply With Quote
Old 10-29-2011, 08:18 PM   #9
Member

angelsman's Avatar

Join Date: Jun 2010
Location: Otisville, MI
Posts: 119

View angelsman's Photo Album My Photos
1999 Cherokee
Default

Actually rolls pinion down to far. Need adj uppers to twist pinion back up.
__________________
Project 1KXJ
angelsman is offline   Reply With Quote
Old 05-13-2012, 11:48 AM   #10
Newbie

Join Date: May 2012
Location: Ozark AR
Posts: 8

View ZJ_Joe's Photo Album My Photos
1995 Grand Cherokee
Default

Ive got a 95 ZJ and my buddy has a set of short arms off is TJ that hes gonna give me.. by the chart above the frotns are the same right? but what about the rear it looked like the tl wjere a lil shorter than the zj is there anyway to still make this work?
ZJ_Joe is offline   Reply With Quote
Old 05-15-2012, 10:29 AM   #11
Member

angelsman's Avatar

Join Date: Jun 2010
Location: Otisville, MI
Posts: 119

View angelsman's Photo Album My Photos
1999 Cherokee
Default

Front lowers should be the same. Not sure about ZJ to TJ rears. ZJ rears are about an inch longer than TJ, XJ fronts.
__________________
Project 1KXJ
angelsman is offline   Reply With Quote
Old 05-15-2012, 03:53 PM   #12
Member

gully369's Avatar

Join Date: Jul 2009
Location: Fort Collins, CO
Posts: 103

View gully369's Photo Album My Photos
98 Grand Cherokee
Send a message via MSN to gully369
Default

The JK arms are definitely on the long side, and gave me caster of around 14 with all of the adjust ability taken out of the cam bolts in the lower arms. They make the pinion angle ridiculously stupid. When I had it aligned after the owner of the shop told me not to take it offroad or I would tear the pinion out of my front axle. You must have adjustable uppers if you want to flex at all. I have run it this way for nearly a year though and am now getting the adjustable UCA's and extended brake lines for an upcoming trip.

On mallcrawlin they recomended using WJ arms to replace the lowers. It looks like a much better solution.

Joe, if the rears are factory length they probably wont be of much good to you.
