Replacing Battery Cables - Any Tips??......
#16
CF Veteran
Making cables is something you can easily do yourself, it isn't rocket science. Get some good quality cable, lugs and if you have a vise, you're all set. You can fill the crimped lugs with solder for completeness if you want and that's it. And plenty of Youtubes for the visually needy.
#17
Senior Member
Join Date: Jan 2015
Location: Anderson, SC
Posts: 641
Likes: 0
Received 1 Like
on
1 Post
Year: 1999
Model: Cherokee
Engine: 4.0
Anybody heard from 5-90? I ordered some cables - a while ago. He typically responds to my emails but I haven't heard from him recently. I'm not nervous but if I need to order from elsewhere I will.
#18
Seasoned Member
Join Date: Dec 2013
Location: Eastern Michigan
Posts: 320
Likes: 0
Received 0 Likes
on
0 Posts
Year: 2001
Model: Cherokee
Engine: 4.0
I don't have any insight into what he's up to, but it's really not hard to make your own battery cables. Get some 1/0 welding cable, the proper sized lugs (following KWIP specs for sizes), and instead of crimping them with a vice, get solder pellets. The pellets are crazy easy to use. Torch the lug, drop in the pellet, insert cable, and ta-da! Great connections. There are also lugs that have solder built in, so look around a little bit. You'll pretty much have to get all this stuff online or find a local welding shop. Hell, a shop may even be willing to crimp for you using their crazy expensive die crimpers. Then you wouldn't need anything special, just cable and lugs.
#19
CF Veteran
Join Date: Aug 2010
Location: Canton, MI
Posts: 8,357
Likes: 0
Received 82 Likes
on
67 Posts
Year: 1999
Model: Cherokee
Engine: 4.0
I don't have any insight into what he's up to, but it's really not hard to make your own battery cables. Get some 1/0 welding cable, the proper sized lugs (following KWIP specs for sizes), and instead of crimping them with a vice, get solder pellets. The pellets are crazy easy to use. Torch the lug, drop in the pellet, insert cable, and ta-da! Great connections. There are also lugs that have solder built in, so look around a little bit. You'll pretty much have to get all this stuff online or find a local welding shop. Hell, a shop may even be willing to crimp for you using their crazy expensive die crimpers. Then you wouldn't need anything special, just cable and lugs.
A pause for the cause...
I must ask: Why 1/0 welding cable? What is the need for this overkill? Are you installing an arc welder in your Jeep?
If you are an OEM DD there is absolutely no need for these ridiculous sized cables. The Jeep XJ came from the factory with + - 6 AWG cables and have worked well for many years. I do, however, recommend renewing the 6 AWG cables after about 15 years.
Actually, I'm amused by these "Cable Upgrade" posts...keep it up.
5-90 is getting rich off you guys. LOL
#20
Senior Member
I went to Oreilly auto parts and got 4AG cables for about $40. Some were a little longer than stock but I was looking for functional at a reasonable price. to each his own.
#22
Seasoned Member
Thread Starter
Join Date: Dec 2010
Location: Masonville, NY
Posts: 482
Likes: 0
Received 0 Likes
on
0 Posts
Year: 1999
Model: Cherokee
If you are an OEM DD there is absolutely no need for these ridiculous sized cables. The Jeep XJ came from the factory with + - 6 AWG cables and have worked well for many years. I do, however, recommend renewing the 6 AWG cables after about 15 years.
#23
I wonder if those beefier battery cables will somehow get you better fuel economy? Or make your rig a little quicker from 0-60? Or reduce the pain and itching of hemorrhoids?
This is amusing.
This is amusing.
#25
CF Veteran
Join Date: Aug 2010
Location: Canton, MI
Posts: 8,357
Likes: 0
Received 82 Likes
on
67 Posts
Year: 1999
Model: Cherokee
Engine: 4.0
With using 4 gauge, or larger, wire, how are you addressing the fusible link in the wire that goes from the alternator to the buss bar at the end of the PDC - the green 10 gauge wire?
Read this:
http://www.whiteproducts.com/fusible-faqs.shtml
Read this:
http://www.whiteproducts.com/fusible-faqs.shtml
#26
Senior Member
Join Date: Jun 2014
Location: Eagle River, Alaska
Posts: 925
Likes: 0
Received 6 Likes
on
6 Posts
Year: 1999
Model: Cherokee (XJ)
With using 4 gauge, or larger, wire, how are you addressing the fusible link in the wire that goes from the alternator to the buss bar at the end of the PDC - the green 10 gauge wire?
Read this:
http://www.whiteproducts.com/fusible-faqs.shtml
Read this:
http://www.whiteproducts.com/fusible-faqs.shtml
#27
CF Veteran
Join Date: Jan 2015
Location: Oregon Coast
Posts: 1,508
Likes: 0
Received 4 Likes
on
4 Posts
Year: 1999
Model: Cherokee
Engine: 4.0L I6
With using 4 gauge, or larger, wire, how are you addressing the fusible link in the wire that goes from the alternator to the buss bar at the end of the PDC - the green 10 gauge wire?
Read this:
http://www.whiteproducts.com/fusible-faqs.shtml
Read this:
http://www.whiteproducts.com/fusible-faqs.shtml
#28
CF Veteran
Join Date: May 2012
Location: Lost in the wilds of Virginia
Posts: 7,964
Received 952 Likes
on
767 Posts
Year: 1998 Classic (I'll get it running soon....) and 02 Grand
Model: Cherokee (XJ)
Engine: 4.0
The need is for bragging rights, Ken. Oh, and bigger is ALWAYS better, right?
Right.
Folks, Ken is (mostly) right on this one. There is nothing but wasted money in using 1/0 welding cable. For crying out loud, folks, that stuff is rated for 350 amps at fifty feet! Why do you think you need it to run far less than half of that current for less than a tenth of the distance?
Go one size up from factory to 4 gauge and you have a great cable. If you are running a winch, MAYBE you need something bigger, and of course, you need an upsized alternator, too, but NOBODY has any reason to be running welding cable. No, not even if you are running a rear mounted winch!
It's just a stupid waste of copper. It's doing NOTHING useful.
#29
CF Veteran
Join Date: May 2012
Location: Lost in the wilds of Virginia
Posts: 7,964
Received 952 Likes
on
767 Posts
Year: 1998 Classic (I'll get it running soon....) and 02 Grand
Model: Cherokee (XJ)
Engine: 4.0
Very true. There are also the, "I read it on the Internet", and the "bigger is always better"n and the "mine is bigger than yours" factors.
That's how you get from 6 gauge (adequate for just about anybody) to 1/0 welding cable.
Exactly right. 1/0 welding cable is waaaay beyond the point of non-existent returns.
Upgrade the factory connectors and use a good quality 6 gauge cable, and you've got a great setup.
Upgrade the factory connectors and use a good quality 4 gauge cable, and you've got a fabulous setup.
Any more than that and you've got a waste of money.
